Marantz DV7010 - Page 40

1-52
POS.
NO
VERS.
COLOR
PART NO.
(PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(PCS)
DESCRIPTION
PART NO.
(MJI)
QP06 17 /S,/N 9965 000 07636 IC STR-G6551
SW.REGULATOR
HC10008080
QP06 18A
/A,/C,/K,/S
9965 000 07636 IC STR-G6551
SW.REGULATOR
HC10008080
QP06
7010
/A,/C,/N,/S
9965 000 07636 IC, STR-G6551 POWER IC HC10008080
QP07
17 /F
18A /L,/U
4822 130 10431 PHOTO UNIT
COUPLER PC-123F2
HW10032320
QP07
7010 /F,/L,/U 4822 130 10431 PHOTO UNIT
COUPLER PC-123F2
HW10032320
QP08 4822 130 10431 PHOTO UNIT
COUPLER PC-123F2
HW10032320
QP09 9965 000 06384 IC TL431CZ HC33036590
QP10
17 /F
18A /L,/U
4822 130 61906 SEMICON.COMP
DTC114EU
BA20035210
QP10
7010 /F,/L,/U 4822 130 61906 SEMICON.COMP
DTC114EU
BA20035210
QP11 9965 000 00399 IC SI-3033C
+3.3V 1.5A WITH SW
HC36903080
QP12 9965 000 07637 IC PQ2TZ15
+2.5V 1A WITH SW
HC98903320
QP13 4822 130 62548 TRS. 2SB1185(E F) HT211852B0
QP14 4822 130 61906 SEMICON.COMP
DTC114EU
BA20035210
QP15 17 /N 7010 /N 4822 209 80655 IC NJM78M08 HC38508090
QP16 9965 000 04991 IC SI-3050C
+5.0V 1.5A WITH SW
HC10006080
QP17 4822 130 62548 TRS. 2SB1185(E F) HT211852B0
QP18 4822 130 10698 CHIP TRS. 2SA1586(Y GR)
2SA1576(Q R)
HX100012A0
QP22 4822 130 61903 SEMICON.COMP
DTA114EUA
BA10026210
QP23 4822 130 62548 TRS. 2SB1185(E F) HT211852B0
QP24 4822 130 61906 SEMICON.COMP
DTC114EU
BA20035210
QS01 4822 130 61906 SEMICON.COMP
DTC114EU
BA20035210
QS02 4822 130 61903 SEMICON.COMP
DTA114EUA
BA10026210
QS03 4822 130 60669 CHIP TRS. 2SC4081(Q R)
2SC4116(Y GR)
HX300012A0
QS04
17 18A 4822 130 42836 FET 2SK246(GR) HF202461C0
QS05
17 18A 4822 130 42836 FET 2SK246(GR) HF202461C0
QS06 4822 130 11604 TRS. 2SB1020 HT21020100
QS07 4822 130 11605 TRS. 2SD1415 HT41415100
QS08 4822 130 61903 SEMICON.COMP
DTA114EUA
BA10026210
QS09 4822 130 61903 SEMICON.COMP
DTA114EUA
BA10026210
QS11 5322 130 41844 FET 2SK170 V HF201701H0
QS12 5322 130 41844 FET 2SK170 V HF201701H0
QS13 4822 130 62649 FET 2SJ74 V HF100741H0
QS14 4822 130 62649 FET 2SJ74 V HF100741H0
QS15
4822 130 63601 CHIP TRS. 2SC4213 HX342132A0
QS18
QS19 4822 209 71373 IC NJM78L05A HC38105090
QS20 4822 130 61903 SEMICON.COMP
DTA114EUA
BA10026210
QS21 4822 130 61903 SEMICON.COMP
DTA114EUA
BA10026210
QS52 4822 209 91012 IC 74HCT04AF HC700405Q0
QV01 4822 130 60669 CHIP TRS. 2SC4081(Q R)
2SC4116(Y GR)
HX300012A0
QV02 4822 130 60669 CHIP TRS. 2SC4081(Q R)
2SC4116(Y GR)
HX300012A0
QV03 4822 130 60669 CHIP TRS. 2SC4081(Q R)
2SC4116(Y GR)
HX300012A0
QV04 9965 000 07641 IC TK15420M HC10035420
QV05 9965 000 07641 IC TK15420M HC10035420
QV06
17 /F,/S 18A 4822 130 61903 SEMICON.COMP
DTA114EUA
BA10026210
QV06
7010 /A,/C,/F
/L,/S,/U
4822 130 61903 SEMICON.COMP
DTA114EUA
BA10026210
QV07 4822 130 60669 CHIP TRS. 2SC4081(Q R)
2SC4116(Y GR)
HX300012A0
QV08
17 /F,/S 18A 4822 130 61903 SEMICON.COMP
DTA114EUA
BA10026210
QV08
7010 /A,/C,/F
/L,/S,/U
4822 130 61903 SEMICON.COMP
DTA114EUA
BA10026210
QV09 4822 130 60669 CHIP TRS. 2SC4081(Q R)
2SC4116(Y GR)
HX300012A0
QV10 4822 130 10698 CHIP TRS. 2SA1586(Y GR)
2SA1576(Q R)
HX100012A0
QV11 4822 130 10698 CHIP TRS. 2SA1586(Y GR)
2SA1576(Q R)
HX100012A0
QV12 4822 130 10698 CHIP TRS. 2SA1586(Y GR)
2SA1576(Q R)
HX100012A0
QV13 4822 130 61906 SEMICON.COMP
DTC114EU
BA20035210
QV14 4822 130 61903 SEMICON.COMP
DTA114EUA
BA10026210
QV15 4822 130 61906 SEMICON.COMP
DTC114EU
BA20035210
QV16 4822 130 61903 SEMICON.COMP
DTA114EUA
BA10026210
QV17 4822 130 60669 CHIP TRS. 2SC4081(Q R)
2SC4116(Y GR)
HX300012A0
QV18 4822 130 60669 CHIP TRS. 2SC4081(Q R)
2SC4116(Y GR)
HX300012A0
QV50 9965 000 07642 IC TC74VHCT125AF HC712505Q0
QV51 9965 000 07643 IC TC74VHC125F HC007605K0
PM01-MISCELLANEOUS
FC01
17 /F,/S 18A 9965 000 04998 EMI FILTER
NFM41R01C221
FM31221020
FC01
7010 /A,/C,/F
/L,/S,/U
9965 000 04998 EMI FILTER
NFM41R01C221
FM31221020
FC02
17 /F,/S 18A 9965 000 04998 EMI FILTER
NFM41R01C221
FM31221020
FC02
7010 /A,/C,/F
/L,/S,/U
9965 000 04998 EMI FILTER
NFM41R01C221
FM31221020
FC03
17 /F,/S 18A 9965 000 04998 EMI FILTER
NFM41R01C221
FM31221020
FC03
7010 /A,/C,/F
/L,/S,/U
9965 000 04998 EMI FILTER
NFM41R01C221
FM31221020
FP02 4822 071 52501 FUSE T250MA/250V
TR5 NO.19372
FS20025200
FP03 4822 071 55001 FUSE T500MA/250V
TR5 NO.19372
FS20050200
FP04 4822 071 51602 FUSE T1.6A/250V
TR5 NO.19372
FS20160200
FP05 4822 071 52501 FUSE T250MA/250V
TR5 NO.19372
FS20025200
FP06 4822 071 52501 FUSE T250MA/250V
TR5 NO.19372
FS20025200
FP07 4822 071 51252 FUSE T1.25A/250V
TR5 NO.19372
FS20125200
FP08 4822 071 55001 FUSE T500MA/250V
TR5 NO.19372
FS20050200
FP09 4822 071 55001 FUSE T500MA/250V
TR5 NO.19372
FS20050200
FS01
FS06
4822 157 10416 BLM11B102S
1608 EMIFILTER
FN31010030
