NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
71
P.C.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
POS. NO.
AUDIO R862 ns
p
00MNN05101610 CHIP RES. 100 OHM CRJ10DJ101
T
AUDIO R863 ns
p
00MNN05222610 CHIP RES. 2.2 KOHM CRJ10DJ222
T
AUDIO R864 ns
p
00MNN05104610 CHIP RES. 100 KOHM CRJ10DJ104
T
AUDIO R865 ns
p
00MNN05101610 CHIP RES. 100 OHM CRJ10DJ101
T
AUDIO R866 ns
p
00MNN05102610 CHIP RES. 1 KOHM CRJ10DJ102
T
AUDIO R867 ns
p
00MNN05102610 CHIP RES. 1 KOHM CRJ10DJ102
T
AUDIO R868 ns
p
00MNN05102610 CHIP RES. 1 KOHM CRJ10DJ102
T
AUDIO R869 ns
p
00MNN05102610 CHIP RES. 1 KOHM CRJ10DJ102
T
AUDIO R870 ns
p
00MNN05102610 CHIP RES. 1 KOHM CRJ10DJ102
T
AUDIO R871 ns
p
00MNN05332610 CHIP RES. 3.3 KOHM CRJ10DJ332
T
AUDIO R872 ns
p
00MNN05103610 CHIP RES. 10 KOHM CRJ10DJ103
T
AUDIO R873 ns
p
00MNN05332610 CHIP RES. 3.3 KOHM CRJ10DJ332
T
AUDIO R874 ns
p
00MNN05103610 CHIP RES. 10 KOHM CRJ10DJ103
T
AUDIO R875 ns
p
00MNN05332610 CHIP RES. 3.3 KOHM CRJ10DJ332
T
AUDIO R876 ns
p
00MNN05222610 CHIP RES. 2.2 KOHM CRJ10DJ222
T
AUDIO R877 ns
p
00MNN05332610 CHIP RES. 3.3 KOHM CRJ10DJ332
T
AUDIO R878 ns
p
00MNN05222610 CHIP RES. 2.2 KOHM CRJ10DJ222
T
AUDIO R879 ns
p
00MNN05123610 CHIP RES. 12 KOHM CRJ10DJ123
T
AUDIO R880 ns
p
00MNN05153610 CHIP RES. 15 KOHM CRJ10DJ153
T
AUDIO R881 ns
p
00MNN05222610 CHIP RES. 2.2 KOHM CRJ10DJ222
T
AUDIO R882 ns
p
00MNN05123610 CHIP RES. 12 KOHM CRJ10DJ123
T
AUDIO R883 ns
p
00MNN05153610 CHIP RES. 15 KOHM CRJ10DJ153
T
AUDIO R884 ns
p
00MNN05222610 CHIP RES. 2.2 KOHM CRJ10DJ222
T
AUDIO R885 ns
p
00MNN05151610 CHIP RES. 150 OHM 1/10W J CRJ10DJ151
T
AUDIO R886 ns
p
00MNN05151610 CHIP RES. 150 OHM 1/10W J CRJ10DJ151
T
AUDIO R887 ns
p
00MNN05101610 CHIP RES. 100 OHM CRJ10DJ101
T
AUDIO R888 ns
p
00MNN05561610 CHIP RES. 560 OHM CRJ10DJ561
T
AUDIO R889 ns
p
00MNN05101610 CHIP RES. 100 OHM CRJ10DJ101
T
AUDIO R890 ns
p
00MNN05101610 CHIP RES. 100 OHM CRJ10DJ101
T
AUDIO R891 ns
p
00MNN05333610 CHIP RES. 33 KOHM CRJ10DJ333
T
AUDIO R892 ns
p
00MNN05561610 CHIP RES. 560 OHM CRJ10DJ561
T
AUDIO R893 ns
p
ns
p
RES. 10 OHM 1/5W J CRD20TJ100
T
AUDIO R894 ns
p
ns
p
RES. 10 OHM 1/5W J CRD20TJ100
T
AUDIO R895 ns
p
00MNN05101610 CHIP RES. 100 OHM CRJ10DJ101
T
AUDIO R896 ns
p
00MNN05473610 CHIP RES. 47 KOHM CRJ10DJ473
T
AUDIO R897 ns
p
00MNN05224610 CHIP RES. 220 KOHM CRJ10DJ224
T
AUDIO R898 ns
p
00MNN05101610 CHIP RES. 100 OHM CRJ10DJ101
T
AUDIO R899 ns
p
00MNN05222610 CHIP RES. 2.2 KOHM CRJ10DJ222
T
AUDIO R900 ns
p
00MNN05101610 CHIP RES. 100 OHM CRJ10DJ101
T
AUDIO R901 ns
p
00MNN05101610 CHIP RES. 100 OHM CRJ10DJ101
T
AUDIO R902 ns
p
00MNN05220610 CHIP RES. 22 OHM 1/10W J CRJ10DJ220
T
AUDIO R903 ns
p
00MNN05220610 CHIP RES. 22 OHM 1/10W J CRJ10DJ220
T
AUDIO R904 ns
p
00MNN05220610 CHIP RES. 22 OHM 1/10W J CRJ10DJ220
T
AUDIO R905 ns
p
00MNN05220610 CHIP RES. 22 OHM 1/10W J CRJ10DJ220
T
AUDIO R906 ns
p
00MNN05220610 CHIP RES. 22 OHM 1/10W J CRJ10DJ220
T
AUDIO R907 ns
p
00MNN05220610 CHIP RES. 22 OHM 1/10W J CRJ10DJ220
T
AUDIO R908 ns
p
00MNN05220610 CHIP RES. 22 OHM 1/10W J CRJ10DJ220
T
AUDIO R909 ns
p
00MNN05220610 CHIP RES. 22 OHM 1/10W J CRJ10DJ220
T
AUDIO R911 ns
p
00MNN05000610 CHIP RES. 0 OHM CRJ10DJ0R0
T
AUDIO R912 ns
p
00MNN05000610 CHIP RES. 0 OHM CRJ10DJ0R0
T
AUDIO X101 90M-JX001180R 90M-JX001180R X'TAL 12288HZ HOX12288E320TF
FRONT PWB
(
CUP11778Z-2
)
FRONT C401 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
FRONT C402 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
FRONT C403 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
FRONT C404 ns
p
00MDD95330300 CER. CAP. 33PF 50V JA 1608SIZE HCUS1H330JA
FRONT C405 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
FRONT C423 ns
p
00MOA10701620 ELECT. CAP. 100UF 16V ZF CCEA1CH101T
FRONT C430 ns
p
00MDD95471300 CER. CAP. 470PF 50V JA 1608SIZE HCUS1H471JA
FRONT C431 ns
p
00MDD95471300 CER. CAP. 470PF 50V JA 1608SIZE HCUS1H471JA
FRONT C432 ns
p
00MDD95471300 CER. CAP. 470PF 50V JA 1608SIZE HCUS1H471JA
FRONT C433 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
FRONT CN41 ns
p
ns
p
JACK GF102-17S-TS KJP17GA117ZG
FRONT CN42 ns
p
ns
p
JACK WAFER KJP04GA19ZM
FRONT D401 90M-HI101040R 90M-HI101040R L.E.D. SLR342VCTB7T089 HVD342VCTB7T089
FRONT D402 90M-HI101110R 90M-HI101110R L.E.D. L.E.D , GREEN HVD342MCTB7T089
FRONT D403 90M-HI101040R 90M-HI101040R L.E.D. SLR342VCTB7T089 HVD342VCTB7T089
