NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
72
P.C.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
POS. NO.
FRONT F401 90M-HQ300690R 90M-HQ300690R DISPLAY FLT, DISPLAY HFLCH2099CB
FRONT IC42 90M-HC109370R 90M-HC109370R IC VFD DRIVER IC
(
QFP64E PKG
)
HVILC75712E-E
FRONT IC44 00MHW10004210 00MHW10004210 PHOTO UNIT RPM6936-V4 BRVRPM6936V4
FRONT PB41 ns
p
ns
p
BRACKET BRACKET , FLT CMD1A468
FRONT PB42 ns
p
ns
p
BRACKET BRACKET , FLT CMD1A468
FRONT Q401 90M-HX800050R 90M-HX800050R CHIP TRS. KRC402 HVTKRC402
FRONT Q402 90M-HX800050R 90M-HX800050R CHIP TRS. KRC402 HVTKRC402
FRONT Q403 90M-HX800050R 90M-HX800050R CHIP TRS. KRC402 HVTKRC402
FRONT R401 ns
p
00MNN05121610 CHIP RES. 120 OHM CRJ10DJ121
T
FRONT R402 ns
p
00MNN05100610 CHIP RES. 10 OHM 1/10W J CRJ10DJ100
T
FRONT R408 ns
p
00MNN05681610 CHIP RES. 680 OHM CRJ10DJ681
T
FRONT R409 ns
p
00MNN05821610 CHIP RES. 820 OHM/1608/5% 00200-010
2
CRJ10DJ821
T
FRONT R410 ns
p
00MNN05272610 CHIP RES. 2.7 KOHM CRJ10DJ272
T
FRONT R411 ns
p
00MNN05152610 CHIP RES. 1.5 KOHM CRJ10DJ152
T
FRONT R412 ns
p
00MNN05222610 CHIP RES. 2.2 KOHM CRJ10DJ222
T
FRONT R413 ns
p
00MNN05331610 CHIP RES. 330 OHM/1608/5% 00200-011
7
CRJ10DJ331
T
FRONT R414 ns
p
00MNN05331610 CHIP RES. 330 OHM/1608/5% 00200-011
7
CRJ10DJ331
T
FRONT R415 ns
p
00MNN05331610 CHIP RES. 330 OHM/1608/5% 00200-011
7
CRJ10DJ331
T
FRONT R417 ns
p
00MNN05103610 CHIP RES. 10 KOHM CRJ10DJ103
T
FRONT R418 ns
p
00MNN05121610 CHIP RES. 120 OHM CRJ10DJ121
T
FRONT R419 ns
p
00MNN05121610 CHIP RES. 120 OHM CRJ10DJ121
T
FRONT R420 ns
p
00MNN05121610 CHIP RES. 120 OHM CRJ10DJ121
T
FRONT R421 ns
p
00MNN05101610 CHIP RES. 100 OHM CRJ10DJ101
T
FRONT R436 ns
p
00MNN05822610 CHIP RES. 8.2 KOHM CRJ10DJ822
T
FRONT R437 ns
p
00MNN05223610 CHIP RES. 22 KOHM CRJ10DJ223
T
FRONT S402 90M-SP001210R 90M-SP001210R PUSH SW SKHV10910G TAC
T
CST1A012Z
T
FRONT S403 90M-SP001210R 90M-SP001210R PUSH SW SKHV10910G TAC
T
CST1A012Z
T
FRONT S404 90M-SP001210R 90M-SP001210R PUSH SW SKHV10910G TAC
T
CST1A012Z
T
FRONT S405 90M-SP001210R 90M-SP001210R PUSH SW SKHV10910G TAC
T
CST1A012Z
T
FRONT S406 90M-SP001210R 90M-SP001210R PUSH SW SKHV10910G TAC
T
CST1A012Z
T
FRONT S407 90M-SP001210R 90M-SP001210R PUSH SW SKHV10910G TAC
T
CST1A012Z
T
FRONT S408 90M-SP001210R 90M-SP001210R PUSH SW SKHV10910G TAC
T
CST1A012Z
T
HDMI PWB
(
CUP11779Z
)
HDMI CT01 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
HDMI CT02 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
HDMI CT03 ns
p
00MDK96102300 CER. CAP. 1000PF 50V KC 1608SIZE HCUS1H102KC
HDMI CT04 ns
p
00MDD95470300 CER. CAP. 47PF 50V J HCUS1H470JA
HDMI CT05 ns
p
00MDD95470300 CER. CAP. 47PF 50V J HCUS1H470JA
HDMI CT06 ns
p
00MDK96102300 CER. CAP. 1000PF 50V KC 1608SIZE HCUS1H102KC
HDMI CT07 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
HDMI CT08 90M-EY000440R 90M-EY000440R TANTL.CAP CHIP TANTAL CAP 10UF/16
V
HCSIA1C100B
HDMI CT09 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
HDMI CT10 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
HDMI CT11 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
HDMI CT12 90M-EY000430R 90M-EY000430R TANTL.CAP CHIP TANTAL CAP 22UF/6.3
V
HCSIA0J220B
HDMI CT13 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
HDMI CT14 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
HDMI CT15 90M-EY000440R 90M-EY000440R TANTL.CAP CHIP TANTAL CAP 10UF/16
V
HCSIA1C100B
HDMI CT16 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
HDMI CT17 ns
p
00MDK96102300 CER. CAP. 1000PF 50V KC 1608SIZE HCUS1H102KC
HDMI CT18 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
HDMI CT19 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
HDMI CT20 90M-EY000430R 90M-EY000430R TANTL.CAP CHIP TANTAL CAP 22UF/6.3
V
HCSIA0J220B
HDMI CT21 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
HDMI CT22 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
HDMI CT24 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
HDMI CT25 90M-EY000440R 90M-EY000440R TANTL.CAP CHIP TANTAL CAP 10UF/16
V
HCSIA1C100B
HDMI CT26 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
HDMI CT27 90M-EY000420R 90M-EY000420R TANTL.CAP CHIP CAP , CHIP ELECT HCEC0JRV2101
T
HDMI CT28 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
HDMI CT29 90M-EY000440R 90M-EY000440R TANTL.CAP CHIP TANTAL CAP 10UF/16
V
HCSIA1C100B
HDMI CT30 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
HDMI CT31 90M-EY000440R 90M-EY000440R TANTL.CAP CHIP TANTAL CAP 10UF/16
V
HCSIA1C100B
HDMI CT32 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
HDMI CT51 ns
p
00MDD95101300 CER. CAP. 100PF 50V JA 1608SIZE HCUS1H101JA
HDMI CT52 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
HDMI CT54 ns
p
90M-DK900050R CER. CAP. 1UF HCUS1E105ZF
