NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
73
P.C.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
POS. NO.
HDMI CT57 90M-EY000410R 90M-EY000410R TANTL.CAP CHIP CAP , ELEC
(
SMD
)
47UF/16
V
HCEC1CRV2470T
HDMI CT58 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
HDMI CW01 90M-EY000420R 90M-EY000420R TANTL.CAP CHIP CAP , CHIP ELECT HCEC0JRV2101
T
HDMI CW02 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
HDMI CW03 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
HDMI CW04 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
HDMI CW05 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
HDMI CW06 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
HDMI CW07 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
HDMI CW08 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
HDMI CW09 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
HDMI CW10 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
HDMI CW11 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
HDMI CW12 90M-EY000420R 90M-EY000420R TANTL.CAP CHIP CAP , CHIP ELECT HCEC0JRV2101
T
HDMI CW13 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
HDMI CW14 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
HDMI CW15 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
HDMI CW16 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
HDMI CW17 90M-EY000420R 90M-EY000420R TANTL.CAP CHIP CAP , CHIP ELECT HCEC0JRV2101
T
HDMI CW18 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
HDMI CW19 ns
p
ns
p
CER. CAP. 0.33F, 3216 SIZE BCUP1H334KC
HDMI CW20 ns
p
90M-DK900060R CER. CAP. 0.033UF HCUS1E333KC
HDMI CW21 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
HDMI CW22 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
HDMI CW23 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
HDMI CW81 90M-EY000440R 90M-EY000440R TANTL.CAP CHIP TANTAL CAP 10UF/16
V
HCSIA1C100B
HDMI CW82 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
HDMI CW83 90M-EY000420R 90M-EY000420R TANTL.CAP CHIP CAP , CHIP ELECT HCEC0JRV2101
T
HDMI CW84 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
HDMI CW85 90M-EY000440R 90M-EY000440R TANTL.CAP CHIP TANTAL CAP 10UF/16
V
HCSIA1C100B
HDMI CW86 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
HDMI CW87 90M-EY000420R 90M-EY000420R TANTL.CAP CHIP CAP , CHIP ELECT HCEC0JRV2101
T
HDMI CW88 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
HDMI CW89 90M-EY000440R 90M-EY000440R TANTL.CAP CHIP TANTAL CAP 10UF/16
V
HCSIA1C100B
HDMI CW90 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
HDMI CW91 90M-EY000420R 90M-EY000420R TANTL.CAP CHIP CAP , CHIP ELECT HCEC0JRV2101
T
HDMI CW92 ns
p
00MDK96104300 CER. CAP. 0.1UF HCUS1H104ZF
HDMI JT01 90M-YT004470R 90M-YT004470R TERMINAL HDMI JACK
(
SMD TYPE
)
KJJ9H002Z
HDMI JT02 ns
p
ns
p
BRACKET BRACKET , PWB CMD1A387
HDMI JT51 90M-YT004380R 90M-YT004380R TERMINAL CINCH+OPT. GL YKC22-0748N HJS9U003Z
HDMI JW01 90M-YJ002850R 90M-YJ002850R JACK FPC WAFER 0.5MM PITCH KJP40GA195ZM
HDMI JW02 90M-YU001930R 90M-YU001930R FPC CARD CABLE WAFER
(
10022HS
)
KJP15GA193Z
Y
HDMI JW03 ns
p
ns
p
BRACKET BRACKET , PWB CMD1A387
HDMI LT01 90M-LU000220R 90M-LU000220R CHIP INDUCTOR 10UH
(
3225 PKG
)
HLQ10E100KRZ
HDMI LT02 90M-FC900400R 90M-FC900400R FERRITE CORE BEAD CHIP 60
(
1608 SIZE
)
HLZ9R005Z
HDMI LT03 90M-LU000220R 90M-LU000220R CHIP INDUCTOR 10UH
(
3225 PKG
)
HLQ10E100KRZ
HDMI LT04 90M-FC900400R 90M-FC900400R FERRITE CORE BEAD CHIP 60
(
1608 SIZE
)
HLZ9R005Z
HDMI LT05 90M-FC900400R 90M-FC900400R FERRITE CORE BEAD CHIP 60
(
1608 SIZE
)
HLZ9R005Z
HDMI LT06 90M-FC900410R 90M-FC900410R FERRITE CORE BEAD CHIP 90 OHM
(
2012 SIZE
)
BLZ9R004Z
HDMI LT07 90M-FC900410R 90M-FC900410R FERRITE CORE BEAD CHIP 90 OHM
(
2012 SIZE
)
BLZ9R004Z
HDMI LT08 90M-FC900410R 90M-FC900410R FERRITE CORE BEAD CHIP 90 OHM
(
2012 SIZE
)
BLZ9R004Z
HDMI LT09 90M-FC900410R 90M-FC900410R FERRITE CORE BEAD CHIP 90 OHM
(
2012 SIZE
)
BLZ9R004Z
HDMI LT51 90M-FC900400R 90M-FC900400R FERRITE CORE BEAD CHIP 60
(
1608 SIZE
)
HLZ9R005Z
HDMI LW01 90M-FC900400R 90M-FC900400R FERRITE CORE BEAD CHIP 60
(
1608 SIZE
)
HLZ9R005Z
HDMI LW02 90M-FC900400R 90M-FC900400R FERRITE CORE BEAD CHIP 60
(
1608 SIZE
)
HLZ9R005Z
HDMI LW03 90M-LU000220R 90M-LU000220R CHIP INDUCTOR 10UH
(
3225 PKG
)
HLQ10E100KRZ
HDMI QT01 90M-HC109390R 90M-HC109390R IC HDMI TRANSMITTER HVISII9190CT64
HDMI QT02 00MHC008905K0 00MHC008905K0 IC S HI-SPEED INPUT AND GATE HVIKIC7SZ08FU
HDMI QT03 90M-HY200040R 90M-HY200040R CHIP FET F.E.T , SMD HN1K05FU HVTHN1K05FU
HDMI QT05 90M-HC300820R 90M-HC300820R IC REGULATOR 3.3V
(
SOT-23-5
)
HVIRN5RZ33BA
HDMI QT06 90M-HC300830R 90M-HC300830R IC REGULATOR 5V
(
SOT-23-5
)
HVIRN5RZ50BA
HDMI QT51 90M-HT800110R 90M-HT800110R TRS. KTC4075GR HVTKTC4075GR
HDMI QW01 00MHC10020660 00MHC10020660 IC SCALER IC
(
LQFP-120
)
HVIPD0280B
HDMI QW81 90M-HZ300060R 90M-HZ300060R CHIP DIODE REGULATOR 3.3V
(
TO252-5
)
BVIBA033CC0WFP
HDMI QW82 90M-HC300820R 90M-HC300820R IC REGULATOR 3.3V
(
SOT-23-5
)
HVIRN5RZ33BA
HDMI QW83 00MHC10228210 00MHC10228210 IC REGULATOR 2.5V
(
TO252-5
)
BVIBA25BC0WFPE2
HDMI RT01 ns
p
00MNN05000610 CHIP RES. 0 OHM CRJ10DJ0R0
T
