NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
74
P.C.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
POS. NO.
HDMI RT02 ns
p
00MNN05000610 CHIP RES. 0 OHM CRJ10DJ0R0
T
HDMI RT03 ns
p
00MNN05000610 CHIP RES. 0 OHM CRJ10DJ0R0
T
HDMI RT07 ns
p
00MNN05220610 CHIP RES. 22 OHM 1/10W J CRJ10DJ220
T
HDMI RT08 ns
p
00MNN05220610 CHIP RES. 22 OHM 1/10W J CRJ10DJ220
T
HDMI RT09 ns
p
00MNN05472610 CHIP RES. 4.7 KOHM CRJ10DJ472
T
HDMI RT10 ns
p
00MNN05101610 CHIP RES. 100 OHM CRJ10DJ101
T
HDMI RT11 ns
p
00MNN05220610 CHIP RES. 22 OHM 1/10W J CRJ10DJ220
T
HDMI RT12 ns
p
00MNN05101610 CHIP RES. 100 OHM CRJ10DJ101
T
HDMI RT13 ns
p
00MNN05561610 CHIP RES. 560 OHM CRJ10DJ561
T
HDMI RT14 90M-BW000400R 90M-BW000400R RES. COMPO. RES,4ARRAY CRJ104DJ220
T
HDMI RT15 90M-BW000400R 90M-BW000400R RES. COMPO. RES,4ARRAY CRJ104DJ220
T
HDMI RT16 90M-BW000400R 90M-BW000400R RES. COMPO. RES,4ARRAY CRJ104DJ220
T
HDMI RT17 90M-BW000400R 90M-BW000400R RES. COMPO. RES,4ARRAY CRJ104DJ220
T
HDMI RT18 ns
p
00MNN05220610 CHIP RES. 22 OHM 1/10W J CRJ10DJ220
T
HDMI RT19 90M-BW000400R 90M-BW000400R RES. COMPO. RES,4ARRAY CRJ104DJ220
T
HDMI RT20 ns
p
00MNN05103610 CHIP RES. 10 KOHM CRJ10DJ103
T
HDMI RT21 ns
p
00MNN05473610 CHIP RES. 47 KOHM CRJ10DJ473
T
HDMI RT22 ns
p
00MNN05101610 CHIP RES. 100 OHM CRJ10DJ101
T
HDMI RT23 ns
p
00MNN05182610 CHIP RES. 1.8 KOHM CRJ10DJ182
T
HDMI RT24 ns
p
00MNN05182610 CHIP RES. 1.8 KOHM CRJ10DJ182
T
HDMI RT25 ns
p
00MNN05000610 CHIP RES. 0 OHM CRJ10DJ0R0
T
HDMI RT26 ns
p
00MNN05000610 CHIP RES. 0 OHM CRJ10DJ0R0
T
HDMI RT29 ns
p
00MNN05101610 CHIP RES. 100 OHM CRJ10DJ101
T
HDMI RT30 ns
p
00MNN05101610 CHIP RES. 100 OHM CRJ10DJ101
T
HDMI RT31 90M-NP000020R 90M-NP000020R CHIP RES. 51 OHM
(
1005 PACKAGE
)
CRJ06IJ510
T
HDMI RT32 90M-NP000020R 90M-NP000020R CHIP RES. 51 OHM
(
1005 PACKAGE
)
CRJ06IJ510
T
HDMI RT33 90M-NP000020R 90M-NP000020R CHIP RES. 51 OHM
(
1005 PACKAGE
)
CRJ06IJ510
T
HDMI RT34 90M-NP000020R 90M-NP000020R CHIP RES. 51 OHM
(
1005 PACKAGE
)
CRJ06IJ510
T
HDMI RT35 90M-NP000020R 90M-NP000020R CHIP RES. 51 OHM
(
1005 PACKAGE
)
CRJ06IJ510
T
HDMI RT36 90M-NP000020R 90M-NP000020R CHIP RES. 51 OHM
(
1005 PACKAGE
)
CRJ06IJ510
T
HDMI RT37 90M-NP000010R 90M-NP000010R CHIP RES. 22 OHM
(
1005 PACKAGE
)
CRJ06IJ220
T
HDMI RT38 90M-NP000010R 90M-NP000010R CHIP RES. 22 OHM
(
1005 PACKAGE
)
CRJ06IJ220
T
HDMI RT39 ns
p
00MNN05103610 CHIP RES. 10 KOHM CRJ10DJ103
T
HDMI RT51 ns
p
00MNN05220610 CHIP RES. 22 OHM 1/10W J CRJ10DJ220
T
HDMI RT52 ns
p
00MNN05000610 CHIP RES. 0 OHM CRJ10DJ0R0
T
HDMI RT53 ns
p
00MNN05222610 CHIP RES. 2.2 KOHM CRJ10DJ222
T
HDMI RT54 ns
p
00MNN05182610 CHIP RES. 1.8 KOHM CRJ10DJ182
T
HDMI RT55 ns
p
00MNN05392610 CHIP RES. 3.9K OHM 1/10W J CRJ10DJ392
T
HDMI RT56 ns
p
00MNN05221610 CHIP RES. 220 OHM CRJ10DJ221
T
HDMI RT57 ns
p
00MNN05680610 CHIP RES. 68 OHM CRJ10DJ680
T
HDMI RT58 ns
p
00MNN05104610 CHIP RES. 100 KOHM CRJ10DJ104
T
HDMI RT59 ns
p
00MNN05101610 CHIP RES. 100 OHM CRJ10DJ101
T
HDMI RT60 ns
p
00MNN05000610 CHIP RES. 0 OHM CRJ10DJ0R0
T
HDMI RT61 ns
p
00MNN05221610 CHIP RES. 220 OHM CRJ10DJ221
T
HDMI RW01 90M-BW000400R 90M-BW000400R RES. COMPO. RES,4ARRAY CRJ104DJ220
T
HDMI RW02 90M-BW000400R 90M-BW000400R RES. COMPO. RES,4ARRAY CRJ104DJ220
T
HDMI RW03 ns
p
00MNN05220610 CHIP RES. 22 OHM 1/10W J CRJ10DJ220
T
HDMI RW04 ns
p
00MNN05220610 CHIP RES. 22 OHM 1/10W J CRJ10DJ220
T
HDMI RW05 ns
p
00MNN05220610 CHIP RES. 22 OHM 1/10W J CRJ10DJ220
T
HDMI RW06 ns
p
00MNN05220610 CHIP RES. 22 OHM 1/10W J CRJ10DJ220
T
HDMI RW07 90M-BW000400R 90M-BW000400R RES. COMPO. RES,4ARRAY CRJ104DJ220
T
HDMI RW08 90M-BW000400R 90M-BW000400R RES. COMPO. RES,4ARRAY CRJ104DJ220
T
HDMI RW11 ns
p
00MNN05220610 CHIP RES. 22 OHM 1/10W J CRJ10DJ220
T
HDMI RW12 ns
p
00MNN05220610 CHIP RES. 22 OHM 1/10W J CRJ10DJ220
T
HDMI RW13 ns
p
00MNN05220610 CHIP RES. 22 OHM 1/10W J CRJ10DJ220
T
HDMI RW14 ns
p
00MNN05332610 CHIP RES. 3.3 KOHM CRJ10DJ332
T
HDMI RW15 ns
p
00MNN05821610 CHIP RES. 820 OHM/1608/5% 00200-010
2
CRJ10DJ821
T
HDMI RW16 ns
p
00MNN05103610 CHIP RES. 10 KOHM CRJ10DJ103
T
HDMI RW17 ns
p
00MNN05220610 CHIP RES. 22 OHM 1/10W J CRJ10DJ220
T
HDMI RW18 ns
p
00MNN05103610 CHIP RES. 10 KOHM CRJ10DJ103
T
HDMI RW20 ns
p
00MNN05000610 CHIP RES. 0 OHM CRJ10DJ0R0
T
HDMI RW21 ns
p
00MNN05000610 CHIP RES. 0 OHM CRJ10DJ0R0
T
MAIN PWB
(
CUP11777Z
)
MAIN BN12 ns
p
ns
p
CORD WIRE ASS'Y CWB1C907170GN
MAIN BN13 ns
p
ns
p
CORD WIRE ASS'Y CWZDV7500BN13
MAIN BN14 ns
p
ns
p
CORD WIRE ASS'Y CWZDV7500BN14
MAIN BN16 ns
p
ns
p
CORD WIRE ASS'Y CWZDV7500BN16
