NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
86
P.C.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
POS. NO.
MAIN RN57 90M-BW000390R 90M-BW000390R RES. COMPO. RES, ARRAY, 100R
(
1608
)
CRJ104DJ101
T
MAIN RN58 90M-BW000390R 90M-BW000390R RES. COMPO. RES, ARRAY, 100R
(
1608
)
CRJ104DJ101
T
MAIN RN59 90M-BW000400R 90M-BW000400R RES. COMPO. RES,4ARRAY CRJ104DJ220
T
MAIN RN60 90M-BW000400R 90M-BW000400R RES. COMPO. RES,4ARRAY CRJ104DJ220
T
MAIN RN61 90M-BW000400R 90M-BW000400R RES. COMPO. RES,4ARRAY CRJ104DJ220
T
MAIN RN62 90M-BW000400R 90M-BW000400R RES. COMPO. RES,4ARRAY CRJ104DJ220
T
MAIN RN63 90M-BW000400R 90M-BW000400R RES. COMPO. RES,4ARRAY CRJ104DJ220
T
MAIN RN91 90M-BW000400R 90M-BW000400R RES. COMPO. RES,4ARRAY CRJ104DJ220
T
MAIN RN92 90M-BW000400R 90M-BW000400R RES. COMPO. RES,4ARRAY CRJ104DJ220
T
MAIN SW34 90M-SS000710R 90M-SS000710R SLIDE SW SWITCH , SLIDE KSS2B016Z
MAIN X101 90M-JX001210R 90M-JX001210R X'TAL CRYSTAL , 4MHZ HOX04000E150C
SMPS PWB
(
CUP11780Z
)
SMPS C901 ns
p
90M-OA000360R ELECT. CAP. CAP , ELECT
(
400V , 150 UF
)
CCET400VHE151NH
SMPS C902 ns
p
90M-OA000340R ELECT. CAP. 50V/47UF CCEA1HH470TS
SMPS C903 ns
p
90M-OA000320R ELECT. CAP. 50V/22UF/105'C CCEA1HH220TS
SMPS C904 ns
p
90M-OA000320R ELECT. CAP. 50V/22UF/105'C CCEA1HH220TS
SMPS C905 ns
p
ns
p
CER. CAP. 2200PF CCKT3A222KBL
SMPS C906 ns
p
ns
p
CER. CAP. 2200PF CCKT3A222KBL
SMPS C907 ns
p
ns
p
CER. CAP. 104 50V CCUMT1H104KB
SMPS C908 ns
p
ns
p
CER. CAP. 104 50V CCUMT1H104KB
SMPS C910 ns
p
ns
p
CER. CAP. EKR3A102K05FK5 CCKT3A102KBL
SMPS C911 ns
p
90M-OA000280R ELECT. CAP. 16V/470UF CCEA1CH471TS
SMPS C912 ns
p
90M-OA000340R ELECT. CAP. 50V/47UF CCEA1HH470TS
SMPS C913 ns
p
90M-OA000310R ELECT. CAP. 50V/1.0UF/105'C CCEA1HH1R0TS
SMPS C914 ns
p
ns
p
CER. CAP. 104 50V CCUMT1H104KB
SMPS C915 ns
p
90M-OA000300R ELECT. CAP. 50V/100UF CCEA1HH101TS
SMPS C916 ns
p
90M-OA000340R ELECT. CAP. 50V/47UF CCEA1HH470TS
SMPS C917 ns
p
ns
p
CER. CAP. 104 50V CCUMT1H104KB
SMPS C918 ns
p
ns
p
CER. CAP. EKR3A102K05FK5 CCKT3A102KBL
SMPS C919 ns
p
90M-OA000270R ELECT. CAP. 1500UF CCEA1ARD152EHS
SMPS C920 ns
p
90M-OA000350R ELECT. CAP. 35V/470UF/105'C CCEA1VH471ES
SMPS C921 ns
p
90M-OA000310R ELECT. CAP. 50V/1.0UF/105'C CCEA1HH1R0TS
SMPS C922 ns
p
ns
p
CER. CAP. EKR3A102K05FK5 CCKT3A102KBL
SMPS C923 ns
p
90M-OA000350R ELECT. CAP. 35V/470UF/105'C CCEA1VH471ES
SMPS C924 ns
p
90M-OA000290R ELECT. CAP. 330UF 25V 105DEG. CCEA1EH331TS
SMPS C925 ns
p
90M-OA000350R ELECT. CAP. 35V/470UF/105'C CCEA1VH471ES
SMPS C926 ns
p
90M-OA000280R ELECT. CAP. 16V/470UF CCEA1CH471TS
SMPS C927 ns
p
90M-OA000350R ELECT. CAP. 35V/470UF/105'C CCEA1VH471ES
SMPS C928 ns
p
90M-OA000280R ELECT. CAP. 16V/470UF CCEA1CH471TS
SMPS C929 ns
p
90M-OA000290R ELECT. CAP. 330UF 25V 105DEG. CCEA1EH331TS
SMPS C930 ns
p
90M-OA000290R ELECT. CAP. 330UF 25V 105DEG. CCEA1EH331TS
SMPS C931 ns
p
90M-OA000340R ELECT. CAP. 50V/47UF CCEA1HH470TS
SMPS C932 ns
p
90M-OA000340R ELECT. CAP. 50V/47UF CCEA1HH470TS
SMPS C934 ns
p
ns
p
CER. CAP. EKR3A102K05FK5 CCKT3A102KBL
SMPS C935 ns
p
ns
p
CER. CAP. 104 50V CCUMT1H104KB
SMPS C936 ns
p
90M-OA000310R ELECT. CAP. 50V/1.0UF/105'C CCEA1HH1R0TS
SMPS CN91 00MYP04000760 00MYP04000760 PLUG 7.92MM
(
YUNHO
)
KJP02KA060Z
Y
SMPS CN92 ns
p
ns
p
JACK WAFER, STRAIGHT, 6PIN CJP06GA19Z
Y
SMPS CN93 ns
p
ns
p
JACK WAFER, STRAIGHT, 6PIN CJP12GA19Z
Y
SMPS CX91 90M-OF100500R 90M-OF100500R FILM CAP. POLYPROPYLENE FILM HCQF2E104KZE
SMPS CX92 90M-OF100500R 90M-OF100500R FILM CAP. POLYPROPYLENE FILM HCQF2E104KZE
SMPS CY91 90M-DK100930R 90M-DK100930R CER. CAP. CERAMIC
(
400V Y-CAP
)
CCKDHS102ME
SMPS CY92 90M-DK100930R 90M-DK100930R CER. CAP. CERAMIC
(
400V Y-CAP
)
CCKDHS102ME
SMPS CY94 90M-DK100870R 90M-DK100870R CER. CAP. SDE2G222M10FF7 CCKDHS222ME
SMPS D901 ns
p
90M-HD201970R DIODE RL207T HVDRL207T
SMPS D902 ns
p
90M-HD201970R DIODE RL207T HVDRL207T
SMPS D903 ns
p
90M-HD201970R DIODE RL207T HVDRL207T
SMPS D904 ns
p
90M-HD201970R DIODE RL207T HVDRL207T
SMPS D905 ns
p
90M-HD201870R DIODE UF4007 SCHOTTKY HVDUF4007T
SMPS D906 ns
p
90M-HD201960R DIODE 1N4937T RECTIFIERS HVD1N4937T
SMPS D907 ns
p
90M-HD201960R DIODE 1N4937T RECTIFIERS HVD1N4937T
SMPS D908 ns
p
90M-HD201960R DIODE 1N4937T RECTIFIERS HVD1N4937T
SMPS D909 ns
p
90M-HD201870R DIODE UF4007 SCHOTTKY HVDUF4007T
SMPS D921 ns
p
90M-HD201950R DIODE 11EQ06T SCHOTTKY
(
60V/1A
)
HVD11EQ06T
SMPS D922 ns
p
90M-HD201950R DIODE 11EQ06T SCHOTTKY
(
60V/1A
)
HVD11EQ06T
SMPS D923 ns
p
90M-HD201960R DIODE 1N4937T RECTIFIERS HVD1N4937T
SMPS D924 ns
p
90M-HD201990R DIODE 31DQ06 HVD31DQ06H
