Marantz DV7600 - Page 72

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
87
P.C.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
POS. NO.
SMPS D925 ns
p
90M-HD201990R DIODE 31DQ06 HVD31DQ06H
SMPS D926 ns
p
90M-HD201890R DIODE UF5404H 15MM FORMING HVDUF5404H
SMPS D927 ns
p
90M-HD201990R DIODE 31DQ06 HVD31DQ06H
SMPS D928 ns
p
90M-HD201960R DIODE 1N4937T RECTIFIERS HVD1N4937T
SMPS D929 ns
p
90M-HD201960R DIODE 1N4937T RECTIFIERS HVD1N4937T
SMPS D932 ns
p
90M-HD201990R DIODE 31DQ06 HVD31DQ06H
SMPS D933 ns
p
90M-HD201950R DIODE 11EQ06T SCHOTTKY
(
60V/1A
)
HVD11EQ06T
SMPS ET91 ns
p
ns
p
TERMINAL MET37-0002 HJT1A025
SMPS ET92 ns
p
ns
p
TERMINAL MET37-0002 HJT1A025
SMPS ET93 ns
p
ns
p
TERMINAL MET37-0002 HJT1A025
SMPS FH91 ns
p
ns
p
HOLDER HOLDER , FUSE KJCFC5S
SMPS FH92 ns
p
ns
p
HOLDER HOLDER , FUSE KJCFC5S
SMPS IC91 90M-HC109410R 90M-HC109410R IC I.C , VIPER HVIVIPER12ADIP
SMPS IC92 90M-HC109430R 90M-HC109430R IC IC , POWER SW HVIKA5M0365RYD
T
SMPS IC93 90M-HC300770R 90M-HC300770R IC I.C , REGULATOR HVIKIA431BAT
SMPS IC94 90M-HC300770R 90M-HC300770R IC I.C , REGULATOR HVIKIA431BAT
SMPS IC95 90M-HC300700R 90M-HC300700R IC KA278R12TU HVIKA278R12
SMPS IC96 90M-HC300790R 90M-HC300790R IC REGULATOR
(
5V LOW DROP
)
HVIKIA78R05PI
SMPS IC97 90M-HC300780R 90M-HC300780R IC REGULATOR, +8V HVIKIA7808API
SMPS IC98 00MHC3990809
F
00MHC3990809
F
IC REGULATOR -8V HVINJM7908F
A
SMPS J901 ns
p
ns
p
CONN. CORD SN95/PB5 , 0.6 C3A206
SMPS J902 ns
p
ns
p
CONN. CORD SN95/PB5 , 0.6 C3A206
SMPS J903 ns
p
ns
p
CONN. CORD SN95/PB5 , 0.6 C3A206
SMPS J904 ns
p
ns
p
CONN. CORD SN95/PB5 , 0.6 C3A206
SMPS J905 ns
p
ns
p
CONN. CORD SN95/PB5 , 0.6 C3A206
SMPS J906 ns
p
ns
p
CONN. CORD SN95/PB5 , 0.6 C3A206
SMPS J907 ns
p
ns
p
CONN. CORD SN95/PB5 , 0.6 C3A206
SMPS J908 ns
p
ns
p
CONN. CORD SN95/PB5 , 0.6 C3A206
SMPS J909 ns
p
ns
p
CONN. CORD SN95/PB5 , 0.6 C3A206
SMPS J910 ns
p
ns
p
CONN. CORD SN95/PB5 , 0.6 C3A206
SMPS J911 ns
p
ns
p
CONN. CORD SN95/PB5 , 0.6 C3A206
SMPS J912 ns
p
ns
p
CONN. CORD SN95/PB5 , 0.6 C3A206
SMPS J913 ns
p
ns
p
CONN. CORD SN95/PB5 , 0.6 C3A206
SMPS J914 ns
p
ns
p
CONN. CORD SN95/PB5 , 0.6 C3A206
SMPS J915 ns
p
ns
p
CONN. CORD SN95/PB5 , 0.6 C3A206
SMPS J916 ns
p
ns
p
CONN. CORD SN95/PB5 , 0.6 C3A206
SMPS J917 ns
p
ns
p
CONN. CORD SN95/PB5 , 0.6 C3A206
SMPS J918 ns
p
ns
p
CONN. CORD SN95/PB5 , 0.6 C3A206
SMPS L901 ns
p
ns
p
COIL CHOKE
(
6.8UH
)
CLZ9Z040Z
SMPS L902 ns
p
ns
p
COIL CHOKE
(
6.8UH
)
CLZ9Z040Z
SMPS LF91 90M-FN000250R 90M-FN000250R EMI FILTER LINE FILTER CLZ9Z060Z
SMPS LF92 90M-FN000250R 90M-FN000250R EMI FILTER LINE FILTER CLZ9Z060Z
SMPS PC91 90M-HW100710R 90M-HW100710R PHOTO UNIT PC-17L1CB HVIPC17L1CB
SMPS PC92 90M-HW100710R 90M-HW100710R PHOTO UNIT PC-17L1CB HVIPC17L1CB
SMPS PC93 90M-HW100710R 90M-HW100710R PHOTO UNIT PC-17L1CB HVIPC17L1CB
SMPS Q901 90M-HT600060R 90M-HT600060R TRS. KSA708Y HVTKSA708YT
SMPS Q902 90M-HT600060R 90M-HT600060R TRS. KSA708Y HVTKSA708YT
SMPS Q903 90M-HT800130R 90M-HT800130R TRS. KSC1008Y HVTKSC1008YT
SMPS Q910 90M-HT800130R 90M-HT800130R TRS. KSC1008Y HVTKSC1008YT
SMPS Q913 00MBA10001000 00MBA10001000 TRS. KRA102M HVTKRA102MT
SMPS Q914 00MBA20001000 00MBA20001000 TRS. KRC102M HVTKRC102MT
SMPS Q932 90M-HT800130R 90M-HT800130R TRS. KSC1008Y HVTKSC1008YT
SMPS Q933 90M-HT800130R 90M-HT800130R TRS. KSC1008Y HVTKSC1008YT
SMPS R901 ns
p
ns
p
RES. 1/2W , 1M OHM KROS1TJ105V
SMPS R902 ns
p
ns
p
RES. 2W 68K OHM MINI KRG2SANJ683H
SMPS R903 ns
p
ns
p
RES. 2W 68K OHM MINI KRG2SANJ683H
SMPS R904 ns
p
ns
p
CONN. CORD SN95/PB5 , 0.6 C3A206
SMPS R905 ns
p
ns
p
CONN. CORD SN95/PB5 , 0.6 C3A206
SMPS R906 ns
p
ns
p
RES. 56 OHM 1/4W J CRD25TJ560
T
SMPS R907 ns
p
ns
p
RES. 15 OHM 1/4W J CRD25TJ150
T
SMPS R908 ns
p
ns
p
RES. 100 OHM 1/4W J CRD25TJ101
T
SMPS R909 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103
T
SMPS R910 ns
p
ns
p
RES. 1K OHM 1/5W J CRD20TJ102
T
SMPS R911 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103
T
SMPS R912 ns
p
ns
p
RES. 22K OHM 1/5W J CRD20TJ223
T
SMPS R913 ns
p
ns
p
RES. 4.7 OHM 1/5W J CRD20TJ4R7T
SMPS R914 ns
p
ns
p
RES. 1K OHM 1/5W J CRD20TJ102
T
