NOTE : “nsp” PARTS IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
POS.
NO.
VERS.
COLOR
PART NO.
PART NO.
PART NAME DESCRIPTION
(FOR EUR)
1 nsp CHASSIS MAIN CHASSIS ASSY 9KC 1A01 7
2 90M13AK160210 BRAKET CLAMPER BRACKET 9KA 7P08 5
3 nsp BRAKET GUIDE CLAMP BRACKET
4 90M-MM001290R MOTOR LOADING MOTOR ASSY 9KC 2A00 3
5 90M13AK058230 GEAR LOADING GEAR 9KC 2G02 9
6 90M13AK058210 GEAR LOADING GEAR 2ND 9KB 9G03 0
7 90M13AK058220 GEAR LOADING GEAR 3RD 9KB 9G03 1
8 90M13AK105210 CHASSIS SUB CHASSIS-L 9KA 2G41 7
9 90M13AK105220 CHASSIS SUB CHASSIS-R 9KA 2G41 8
10 90M13AK163210 TRAY TRAY-D4 9KA 2G778
11 90M13AK054210 CAM SLIDE-CAM 9KC 1G00 3
12 90M13AK002210 ARM TRAVERSE ARM 9KC 1G00 4
14 90M13AK005210 CLAMPER CLAMPER H 9KA 7G20 2
15 90M13AK005220 CLAMPER CLAMPER L 9KA 7G20 3
16 90M13AK264210 BELT LOADING BELT 9KB 9G01 5
17 nsp PCB ASSY SWITCH P.W.B. 9KC 1P01 4
18 nsp CORD 5P PH WIRE 9KC 2G04 3
19 90M-SP001260R SWITCH SWITCH ESE22MH21 9KS 01W2 04
20 90M-SP001270R SWITCH SWITCH ESE22MH23 9KS 01W2 05
21 90M13AK012210 WASHER POLY.SLIT WASHER 2.6X6X0.25C 9KP 26C6 25
22 nsp CLAMPER WIRE CLAMPER 445 8004 00
7
23 nsp
SCREW PRECISION SCREW 1.7X2.2 TYPE3 9KS 17N0 22
24 nsp SCREW SCREW 2.6X6 CBTS(B)-Z 9KB 26BK 06
25 nsp SCREW PRECISION SCREW 2X3(S) TYPE3 9KS 20TK 33
26 nsp SCREW SCREW 2X6 CBTS(P)-Z 9KB 20PK 06
27A 90M13AK304210 MECHANISM TRAVERSE MECHA (FEED) ASSY 9KC 2A06 3
A
23 nsp
SCREW PRECISION SCREW 1.7X2.2 TYPE3
27 nsp
CHASSIS PU CHASSIS ASSY
28 nsp
HOLDER SHAFT HOLDER L
29 nsp
HOLDER SHAFT HOLDER R
30 nsp
BRAKET SHAFT TILT BASE
31 nsp
RETAINER SHAFT TILT PLATE
32 nsp
SPRING TILT SPRING
33 nsp
SHAFT MAIN SHAFT
34 nsp
SHAFT SUB SHAFT
35 nsp GEAR PU RACK GEAR
37 nsp MECHANISM PICK UP HOP-1200R
38 nsp SPRING PU SPRING
39 nsp SPRING SHAFT SPRING
40 nsp SPRING RACK GEAR SPRING
42 nsp MOTOR T/T MOTOR ASSY
43 nsp SCREW SCREW 2.6X6 CBTS(S)-Z
44 nsp SCREW SCREW 2.6X4 CBTS(S)-Z
46 nsp SCREW SCREW 2.6X15 CFTS(S)-Z
47 nsp SCREW SCREW 3X4 BSS
48 nsp SCREW SCREW 3X8 BSS (A)
63 nsp SCREW PRECISION SCREW 1.7X5 TYPE3
23 nsp SCREW PRECISION SCREW 1.7X2.2 TYPE3
36 nsp GEAR FEED GEAR 2ND ASSY
41 nsp MOTOR FEED MOTOR ASSY
50 nsp WASHER POLY.SLIT WASHER 2.1X4X0.25C
53 nsp GEAR FEED GEAR 3RD
49 90M13AK130210 DAMPER DAMPER-SI25-LB 9KA 2G643
51 nsp SCREW SPECIAL SCREW (FRONT)
52 nsp SCREW SPECIAL SCREW (REAR)
54 90M13AK116210 LEAF SPRING TRAY-SPRING-VXF 9KB 7P02 4
60 90M13AK104210 RETAINER PLATE-RE-2HPC 9KC 2P03 1
61 90M13AK104220 RETAINER WF-PLATE-RE-2HPC 9KC 2P03 2
62 nsp SCREW PRECISION SCREW 2X4(P) TYPE1 9KS 20P1 04
64 nsp CUSHION RUBBER CUSHION 9KC 1G04 2
66 90M-YU001350R FFC FFC-0.5-24 L=80 9KA 2P70 6
68 nsp TAPE TAPE W10X45 (NITTO NO.156)
70 nsp CUSHION CUSHION L 6X3Xt4 9KC 2G07 6
71 nsp
nsp
90M13AK160210
nsp
90M-MM001290R
90M13AK058230
90M13AK058210
90M13AK058220
90M13AK105210
90M13AK105220
90M13AK163210
90M13AK054210
90M13AK002210
90M13AK005210
90M13AK005220
90M13AK264210
nsp
nsp
90M-SP001260R
90M-SP001270R
90M13AK012210
nsp
nsp
nsp
nsp
nsp
90M13AK304210
nsp
nsp
nsp
nsp
nsp
nsp
nsp
nsp
nsp
nsp
nsp
nsp
nsp
nsp
nsp
nsp
nsp
nsp
nsp
nsp
nsp
nsp
nsp
nsp
nsp
nsp
90M13AK130210
nsp
nsp
90M13AK116210
90M13AK104210
90M13AK104220
nsp
nsp
90M-YU001350R
nsp
nsp
nsp CUSHION CUSHION R 6X3Xt2 9KC 2G07 7
(MJI)
