Marantz DV9500 - Page 173

171
NOTE : “nsp” PARTS IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
PV01 JY01 00MYT02030700 00MYT02030700 TERMINAL YKC21-4076 1L3 FS AU
PV01 JY02 /F1B ns
p
00MYJ11000680 JACK YKF45-3007
(
D CONNECTOR GOLD
)
PV01 JY02 /F1N ns
p
00MYJ11000680 JACK YKF45-3007
(
D CONNECTOR GOLD
)
PV01 JY02 /L1G ns
p
00MYJ11000680 JACK YKF45-3007
(
D CONNECTOR GOLD
)
PV01 JY02 /S1G ns
p
00MYJ11000680 JACK YKF45-3007
(
D CONNECTOR GOLD
)
PV01 LE01 /N1B 00MLU12472010 00MLU12472010 CHIP INDUCTANCE NL322522-4R7M
PV01 LE01 /N1S 00MLU12472010 00MLU12472010 CHIP INDUCTANCE NL322522-4R7M
PV01 LE02 /N1B 00MLU12472010 00MLU12472010 CHIP INDUCTANCE NL322522-4R7M
PV01 LE02 /N1S 00MLU12472010 00MLU12472010 CHIP INDUCTANCE NL322522-4R7M
PV01 LE03 /N1B 00MLU12472010 00MLU12472010 CHIP INDUCTANCE NL322522-4R7M
PV01 LE03 /N1S 00MLU12472010 00MLU12472010 CHIP INDUCTANCE NL322522-4R7M
PV01 LE05 /N1B ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
PV01 LE05 /N1S ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
PV01 LE08 /N1B ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
PV01 LE08 /N1S ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
PV01 LE90 /N1B ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
PV01 LE90 /N1S ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
PV01 LE91 /N1B ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
PV01 LE91 /N1S ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
PV01 LT81 00MFN31010060 00MFN31010060 EMI FILTER EMI FILTER BLM11P600S
PV01 LT82 00MFN31000020 00MFN31000020 EMI FILTER BLM11B252SD
PV01 LT83 00MFN31000020 00MFN31000020 EMI FILTER BLM11B252SD
PV01 LT84 00MFN31000020 00MFN31000020 EMI FILTER BLM11B252SD
PV01 LT85 00MFN31000020 00MFN31000020 EMI FILTER BLM11B252SD
PV01 LV01 00MLU12472010 00MLU12472010 CHIP INDUCTANCE NL322522-4R7M
PV01 LY01 00MLU12102010 00MLU12102010 CHIP INDUCTANCE NL322522-1ROM
PV01 LY02 00MLU12392010 00MLU12392010 CHIP INDUCTANCE NL322522-3R9M
PV01 LY03 00MLU12102010 00MLU12102010 CHIP INDUCTANCE NL322522-1ROM
PV01 LY04 00MLU12392010 00MLU12392010 CHIP INDUCTANCE NL322522-3R9M
PV01 LY05 00MLU12102010 00MLU12102010 CHIP INDUCTANCE NL322522-1ROM
PV01 LY06 00MLU12392010 00MLU12392010 CHIP INDUCTANCE NL322522-3R9M
PV01 LY07 00MLU12472010 00MLU12472010 CHIP INDUCTANCE NL322522-4R7M
PV01 LY08 00MLU12472010 00MLU12472010 CHIP INDUCTANCE NL322522-4R7M
PV01 QE01
/N1B 00MHC12244090 00MHC12244090 IC NJM2584M 50MHZ VIDEO S
W
PV01 QE01 /N1S 00MHC12244090 00MHC12244090 IC NJM2584M 50MHZ VIDEO S
W
PV01 QE02 /N1B 00MHC10102550 00MHC10102550 IC MM1623XFBE VIDEO AMP
PV01 QE02 /N1S 00MHC10102550 00MHC10102550 IC MM1623XFBE VIDEO AMP
PV01 QE03 /N1B 00MBA20035210 00MBA20035210 SEMICON.COMP DTC114EU
PV01 QE03 /N1S 00MBA20035210 00MBA20035210 SEMICON.COMP DTC114EU
PV01 QE04 /N1B 00MHX100012A0 00MHX100012A0 CHIP TR. 2SA1586
(
Y,GR
)
2SA1576A
(
Q,R
)
PV01 QE04 /N1S 00MHX100012A0 00MHX100012A0 CHIP TR. 2SA1586
(
Y,GR
)
2SA1576A
(
Q,R
)
PV01 QE05 /N1B 00MBA20035210 00MBA20035210 SEMICON.COMP DTC114EU
PV01 QE05 /N1S 00MBA20035210 00MBA20035210 SEMICON.COMP DTC114EU
PV01 QE06 /N1B 00MHX300012A0 00MHX300012A0 CHIP TR. 2SC4081
(
Q,R
)
2SC4116
(
Y,GR
)
PV01 QE06 /N1S 00MHX300012A0 00MHX300012A0 CHIP TR. 2SC4081
(
Q,R
)
2SC4116
(
Y,GR
)
PV01 QT81 00MHC10248990 00MHC10248990 IC ISL83384ECA-
T
PV01 QV01 00MHC10103550 00MHC10103550 IC MM1566AJBE VIDEO AMP WITH LP
F
PV01 QV02 00MBA20035210 00MBA20035210 SEMICON.COMP DTC114EU
PV01 QV03 00MHX100012A0 00MHX100012A0 CHIP TR. 2SA1586
(
Y,GR
)
2SA1576A
(
Q,R
)
PV01 QV04 00MBA20035210 00MBA20035210 SEMICON.COMP DTC114EU
PV01 QV91 00MHC91905210 00MHC91905210 IC BA05SFP-E2
PV01 QY01 00MHX100012A0 00MHX100012A0 CHIP TR. 2SA1586
(
Y,GR
)
2SA1576A
(
Q,R
)
PV01 QY02 00MHX300012A0 00MHX300012A0 CHIP TR. 2SC4081
(
Q,R
)
2SC4116
(
Y,GR
)
PV01 QY03 00MHX100012A0 00MHX100012A0 CHIP TR. 2SA1586
(
Y,GR
)
2SA1576A
(
Q,R
)
PV01 QY04 00MHX300012A0 00MHX300012A0 CHIP TR. 2SC4081
(
Q,R
)
2SC4116
(
Y,GR
)
PV01 QY05 00MHX100012A0 00MHX100012A0 CHIP TR. 2SA1586
(
Y,GR
)
2SA1576A
(
Q,R
)
PV01 QY06 00MHX300012A0 00MHX300012A0 CHIP TR. 2SC4081
(
Q,R
)
2SC4116
(
Y,GR
)
PV01 QY07 00MHC10231090 00MHC10231090 IC NJM2580M
PV01 QY08 00MBA20035210 00MBA20035210 SEMICON.COMP DTC114EU
PV01 QY09 00MBA20035210 00MBA20035210 SEMICON.COMP DTC114EU
PV01 RE01 /N1B ns
p
00MNN05390610 CHIP RESISTOR 39 OHM +- 5% 1/16
W
PV01 RE01 /N1S ns
p
00MNN05390610 CHIP RESISTOR 39 OHM +- 5% 1/16
W
PV01 RE02 /N1B ns
p
00MNN05330610 CHIP RESISTOR 33 OHM +- 5% 1/16
W
PV01 RE02 /N1S ns
p
00MNN05330610 CHIP RESISTOR 33 OHM +- 5% 1/16
W
PV01 RE03 /N1B ns
p
00MNN05390610 CHIP RESISTOR 39 OHM +- 5% 1/16
W
PV01 RE03 /N1S ns
p
00MNN05390610 CHIP RESISTOR 39 OHM +- 5% 1/16
W
PV01 RE04 /N1B ns
p
00MNN05330610 CHIP RESISTOR 33 OHM +- 5% 1/16
W
DESCRIPTION
P.C.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(FOR EUR)
PART NO.
(MJI)
PART NAME
