75
5. AnalogVideo出力確認
5.1 VIDEO(Composite)、S 端子出力出ず
OK
NG
OK
NG OK
NG
OK
OK
NG
NG
Connector(JV05)の電圧確認E+6V
QV01 1、3 、5 、16pinの電圧確認 
+5V
QV014pin(Video)、6pin(S:Y)、2pin(S:C)
入力波形確認
QV0113pin(Video)、10pin(S:Y)、
15pin(S:C)出力波形確認
1.POWERSUPPLYPCBへ
QV91(Regulater)出力電圧(+5VV)確認
QV911pin(VPSW)の確認1pin="H"?
3.1PaneluPの動作確認へ
QV91交換
3.4DigitalVideo出力の動作確認項目へ
QV01交換
