Specifications
0
RMS Power output (20 Hz – 20 kHz simultaneous drive of both
channels) :
70 W x 2 (8 Ω/ohms load)
100 W x 2 (4 Ω/ohms load)
0
Total harmonic distortion (20 Hz – 20 kHz simultaneous drive of
both channels, 8 Ω/ohms load) :
0.02 %
0
Frequency response (CD, 1 W, 8 Ω/ohms load) : 5 Hz – 100 kHz ±3 dB
0
Damping factor (8 Ω/ohms load, 20 Hz – 20 kHz) : 100 and over
0
Input sensitivity/impedance: PHONO (MM): 1.4 mV / 47 kΩ/kohms
CD, TUNER, LINE, RECORDER: 185 mV/16 kΩ/kohms
POWER AMP IN: 1.5 V/15 kΩ/kohms
0
Output voltage: PRE OUT: 1.5 V
SUBWOOFER OUT: 220 mV
0
Maximum allowable PHONO input level (1 kHz) MM : 80 mV
0
RIAA deviation (20 Hz – 20 kHz) : ±0.5 dB
0
S/N (IHF-A, 8 Ω/ohms load) : PHONO (MM): 87 dB (5 mV input)
CD, TUNER, LINE, RECORDER: 113 dB (rated output)
POWER AMP IN: 125 dB (rated output)
0
Tone Control : BASS (50 Hz): ±10 dB
TREBLE (15 kHz): ±10 dB
0
Operating temperature: +5 ℃ - +35 ℃
0
Power supply : AC 230 V, 50/60 Hz
0
Power consumption : 220 W
0
Power consumption in standby mode : 0.3 W
For the purpose of improvement, the specifications and design are subject to change without notice.
