CONNECTING VIDEO COMPONENTS
BASIC CONNECTIONS
VIDEO COMPONENT JACKS
There are 2 types of video jacks on the rear panel.
VIDEO JACK
The video signal for the VIDEO jacks is the
conventional composite video signal.
COMPONENT JACK
Make component video connections to a TV or
monitor with component inputs to produce higher
quality video images. Use a component video cable
or 3 video cords to connect the component video
out jacks on the unit to the monitor.
Notes
• Be sure to connect the left and right audio
channels properly.
Red connectors are for the R (right) channel, and
white connectors are for the L (left) channel.
• Be sure to connect the inputs and outputs of the
video signals properly.
• The unit has a video convert function. For details
on video input/output, refer to page 29.
• You may need to setup the digital audio output
format of your DVD player, or other digital
source components. Refer to the instructions of
the each component connected to the digital input
jacks.
