NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
25
PM4001
P.C.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
INPUT C264 F B ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
INPUT C264 F N ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
INPUT C264
/
N1B ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
INPUT C264
/
N1G ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
INPUT C264
/
N1S ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
INPUT C265 F B ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
INPUT C265 F N ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
INPUT C265
/
N1B ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
INPUT C265
/
N1G ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
INPUT C265
/
N1S ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
INPUT C269 ns
p
00MOA22701620 ELECT CAP. 220UF 16V CCEA1CH221T
INPUT C270 ns
p
00MOA22701620 ELECT CAP. 220UF 16V CCEA1CH221T
INPUT C281 ns
p
ns
p
CER. CAP. 0.01UF 50V ZF CCKT1H103ZF
INPUT C282 ns
p
ns
p
CER. CAP. 0.01UF 50V ZF CCKT1H103ZF
INPUT C283 ns
p
ns
p
CER. CAP. 0.022UF 50V
Z
HCBS1H223ZFT
INPUT C286 F B ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
INPUT C286 F N ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
INPUT C286
/
N1B ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
INPUT C286
/
N1G ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
INPUT C286
/
N1S ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
INPUT C287 F B ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
INPUT C287 F N ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
INPUT C287
/
N1B ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
INPUT C287
/
N1G ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
INPUT C287
/
N1S ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
INPUT C288 ns
p
ns
p
FILM CAP. 1500PF 50V J HCQI1H152JZT
INPUT C289 ns
p
ns
p
FILM CAP. 1500PF 50V J HCQI1H152JZT
INPUT C301 F B ns
p
ns
p
FILM CAP. 1000PF 50V J HCQI1H102JZT
INPUT C301 F N ns
p
ns
p
FILM CAP. 1000PF 50V J HCQI1H102JZT
INPUT C301
/
N1B ns
p
ns
p
FILM CAP. 1000PF 50V J HCQI1H102JZT
INPUT C301
/
N1G ns
p
ns
p
FILM CAP. 1000PF 50V J HCQI1H102JZT
INPUT C301
/
N1S ns
p
ns
p
FILM CAP. 1000PF 50V J HCQI1H102JZT
INPUT C302 F B ns
p
ns
p
FILM CAP. 1000PF 50V J HCQI1H102JZT
INPUT C302 F N ns
p
ns
p
FILM CAP. 1000PF 50V J HCQI1H102JZT
INPUT C302
/
N1B ns
p
ns
p
FILM CAP. 1000PF 50V J HCQI1H102JZT
INPUT C302
/
N1G ns
p
ns
p
FILM CAP. 1000PF 50V J HCQI1H102JZT
INPUT C302
/
N1S ns
p
ns
p
FILM CAP. 1000PF 50V J HCQI1H102JZT
INPUT C304 F B ns
p
00MOA47601640 ELECT CAP. 47UF 16V CCEA1CH470T
INPUT C304 F N ns
p
00MOA47601640 ELECT CAP. 47UF 16V CCEA1CH470T
INPUT C304
/
N1B ns
p
00MOA47601640 ELECT CAP. 47UF 16V CCEA1CH470T
INPUT C304
/
N1G ns
p
00MOA47601640 ELECT CAP. 47UF 16V CCEA1CH470T
INPUT C304
/
N1S ns
p
00MOA47601640 ELECT CAP. 47UF 16V CCEA1CH470T
INPUT C305 F B ns
p
00MOA47601640 ELECT CAP. 47UF 16V CCEA1CH470T
INPUT C305 F N ns
p
00MOA47601640 ELECT CAP. 47UF 16V CCEA1CH470T
INPUT C305
/
N1B ns
p
00MOA47601640 ELECT CAP. 47UF 16V CCEA1CH470T
INPUT C305
/
N1G ns
p
00MOA47601640 ELECT CAP. 47UF 16V CCEA1CH470T
INPUT C305
/
N1S ns
p
00MOA47601640 ELECT CAP. 47UF 16V CCEA1CH470T
INPUT C306 F B ns
p
ns
p
CER. CAP. 470PF 50V KB CCKT1H471KB
INPUT C306 F N ns
p
ns
p
CER. CAP. 470PF 50V KB CCKT1H471KB
INPUT C306
/
N1B ns
p
ns
p
CER. CAP. 470PF 50V KB CCKT1H471KB
INPUT C306
/
N1G ns
p
ns
p
CER. CAP. 470PF 50V KB CCKT1H471KB
INPUT C306
/
N1S ns
p
ns
p
CER. CAP. 470PF 50V KB CCKT1H471KB
INPUT C307 F B ns
p
ns
p
CER. CAP. 470PF 50V KB CCKT1H471KB
INPUT C307 F N ns
p
ns
p
CER. CAP. 470PF 50V KB CCKT1H471KB
INPUT C307
/
N1B ns
p
ns
p
CER. CAP. 470PF 50V KB CCKT1H471KB
INPUT C307
/
N1G ns
p
ns
p
CER. CAP. 470PF 50V KB CCKT1H471KB
INPUT C307
/
N1S ns
p
ns
p
CER. CAP. 470PF 50V KB CCKT1H471KB
INPUT C311 ns
p
ns
p
CER. CAP. 10PF 50V DC CCCT1H100DC
INPUT C312 ns
p
ns
p
CER. CAP. 10PF 50V DC CCCT1H100DC
INPUT C341 ns
p
00MOA22705020 ELECT CAP. 220UF 50V CCEA1HH221E
INPUT C342 ns
p
00MOA22705020 ELECT CAP. 220UF 50V CCEA1HH221E
INPUT C343 ns
p
00MOA22705020 ELECT CAP. 220UF 50V CCEA1HH221E
INPUT C344 ns
p
00MOA22705020 ELECT CAP. 220UF 50V CCEA1HH221E
INPUT C345 ns
p
00MOA47602520 ELECT CAP. 47UF 25V CCEA1EH470T
INPUT C346 ns
p
00MOA47602520 ELECT CAP. 47UF 25V CCEA1EH470T
INPUT C367 ns
p
ns
p
FILM CAP. 0.047UF 50V J HCQI1H473JZT
INPUT C368 ns
p
ns
p
FILM CAP. 0.047UF 50V J HCQI1H473JZT
