NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
26
PM4001
P.C.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
INPUT C373 ns
p
ns
p
FILM CAP. 0.01UF 50V J HCQI1H103JZT
INPUT C374 ns
p
ns
p
FILM CAP. 0.01UF 50V J HCQI1H103JZT
INPUT C379 ns
p
00MOA47405020 ELECT CAP. 0.47UF 50V CCEA1HHR47T
INPUT C385 ns
p
ns
p
CER. CAP. 0.01UF 50V ZF CCKT1H103ZF
INPUT C391
/
N1B ns
p
ns
p
FILM CAP. 0.01UF 50V J HCQI1H103JZT
INPUT C391
/
N1G ns
p
ns
p
FILM CAP. 0.01UF 50V J HCQI1H103JZT
INPUT C391
/
N1S ns
p
ns
p
FILM CAP. 0.01UF 50V J HCQI1H103JZT
INPUT C392
/
N1B ns
p
ns
p
FILM CAP. 0.01UF 50V J HCQI1H103JZT
INPUT C392
/
N1G ns
p
ns
p
FILM CAP. 0.01UF 50V J HCQI1H103JZT
INPUT C392
/
N1S ns
p
ns
p
FILM CAP. 0.01UF 50V J HCQI1H103JZT
INPUT C393
/
N1B ns
p
ns
p
FILM CAP. 0.01UF 50V J HCQI1H103JZT
INPUT C393
/
N1G ns
p
ns
p
FILM CAP. 0.01UF 50V J HCQI1H103JZT
INPUT C393
/
N1S ns
p
ns
p
FILM CAP. 0.01UF 50V J HCQI1H103JZT
INPUT C394
/
N1B ns
p
ns
p
FILM CAP. 0.01UF 50V J HCQI1H103JZT
INPUT C394
/
N1G ns
p
ns
p
FILM CAP. 0.01UF 50V J HCQI1H103JZT
INPUT C394
/
N1S ns
p
ns
p
FILM CAP. 0.01UF 50V J HCQI1H103JZT
INPUT C395
/
N1B ns
p
ns
p
FILM CAP. 0.022UF 50V J HCQI1H223JZT
INPUT C395
/
N1G ns
p
ns
p
FILM CAP. 0.022UF 50V J HCQI1H223JZT
INPUT C395
/
N1S ns
p
ns
p
FILM CAP. 0.022UF 50V J HCQI1H223JZT
INPUT C396
/
N1B ns
p
ns
p
FILM CAP. 0.022UF 50V J HCQI1H223JZT
INPUT C396
/
N1G ns
p
ns
p
FILM CAP. 0.022UF 50V J HCQI1H223JZT
INPUT C396
/
N1S ns
p
ns
p
FILM CAP. 0.022UF 50V J HCQI1H223JZT
INPUT C901 ns
p
ns
p
FILM CAP. 0.1UF 50V ZF CCFT1H104ZF
INPUT C902 ns
p
ns
p
FILM CAP. 0.1UF 50V ZF CCFT1H104ZF
INPUT C903 ns
p
ns
p
FILM CAP. 0.1UF 50V ZF CCFT1H104ZF
INPUT C905 F B ns
p
90M-OA000450R ELECT CAP. ! 6800UF 50
V
CCET50VKL4682N
K
INPUT C905 F N ns
p
90M-OA000450R ELECT CAP. ! 6800UF 50
V
CCET50VKL4682N
K
INPUT C905
/
N1B 90M-OA000450R 90M-OA000450R ELECT CAP. ! 6800UF 50
V
CCET50VKL4682N
K
INPUT C905
/
N1G 90M-OA000450R 90M-OA000450R ELECT CAP. ! 6800UF 50
V
CCET50VKL4682N
K
INPUT C905
/
N1S 90M-OA000450R 90M-OA000450R ELECT CAP. ! 6800UF 50
V
CCET50VKL4682N
K
INPUT C906 F B ns
p
90M-OA000450R ELECT CAP. ! 6800UF 50
V
CCET50VKL4682N
K
INPUT C906 F N ns
p
90M-OA000450R ELECT CAP. ! 6800UF 50
V
CCET50VKL4682N
K
INPUT C906
/
N1B 90M-OA000450R 90M-OA000450R ELECT CAP. ! 6800UF 50
V
CCET50VKL4682N
K
INPUT C906
/
N1G 90M-OA000450R 90M-OA000450R ELECT CAP. ! 6800UF 50
V
CCET50VKL4682N
K
INPUT C906
/
N1S 90M-OA000450R 90M-OA000450R ELECT CAP. ! 6800UF 50
V
CCET50VKL4682N
K
INPUT C911 ns
p
ns
p
FILM CAP. 0.01UF 50V J HCQI1H103JZT
INPUT C912 ns
p
ns
p
FILM CAP. 0.01UF 50V J HCQI1H103JZT
INPUT C914 ns
p
00MOA33505020 ELECT CAP. 3.3UF 50V CCEA1HH3R3T
INPUT C917 F B ns
p
00MOA22802520 ELECT CAP. 2200UF 25
V
CCEA1EH222E
INPUT C917 F N ns
p
00MOA22802520 ELECT CAP. 2200UF 25
V
CCEA1EH222E
INPUT C917
/
N1B ns
p
00MOA22802520 ELECT CAP. 2200UF 25
V
CCEA1EH222E
INPUT C917
/
N1G ns
p
00MOA22802520 ELECT CAP. 2200UF 25
V
CCEA1EH222E
INPUT C917
/
N1S ns
p
00MOA22802520 ELECT CAP. 2200UF 25
V
CCEA1EH222E
INPUT C918 F B ns
p
00MOA22802520 ELECT CAP. 2200UF 25
V
CCEA1EH222E
INPUT C918 F N ns
p
00MOA22802520 ELECT CAP. 2200UF 25
V
CCEA1EH222E
INPUT C918
/
N1B ns
p
00MOA22802520 ELECT CAP. 2200UF 25
V
CCEA1EH222E
INPUT C918
/
N1G ns
p
00MOA22802520 ELECT CAP. 2200UF 25
V
CCEA1EH222E
INPUT C918
/
N1S ns
p
00MOA22802520 ELECT CAP. 2200UF 25
V
CCEA1EH222E
INPUT C919 ns
p
00MOA47602520 ELECT CAP. 47UF 25V CCEA1EH470T
INPUT C920 ns
p
00MOA47602520 ELECT CAP. 47UF 25V CCEA1EH470T
INPUT C921 ns
p
00MOA10702520 ELECT CAP. 100UF 25V CCEA1EH101T
INPUT C922 ns
p
00MOA10702520 ELECT CAP. 100UF 25V CCEA1EH101T
INPUT C923 ns
p
00MOA47602520 ELECT CAP. 47UF 25V CCEA1EH470T
INPUT C926 ns
p
00MOA22605020 ELECT CAP. 22UF 25V CCEA1EH220T
INPUT C927 ns
p
00MOA47602520 ELECT CAP. 47UF 25V CCEA1EH470T
INPUT C928 ns
p
ns
p
CER. CAP. 0.047UF 50V ZF CCKT1H473ZF
INPUT C929 ns
p
ns
p
CER. CAP. 0.022UF 50V
Z
HCBS1H223ZFT
INPUT CN12 ns
p
ns
p
CONN. STRAIGHT 4PIN CJP04GA01Z
Y
INPUT CN33 ns
p
ns
p
CONN. 00906-0027 4P STRAIGH
T
CJP04GA19Z
Y
INPUT CN35 ns
p
ns
p
CONN. 00906-0027 4P STRAIGH
T
CJP04GA19Z
Y
INPUT CN37 ns
p
ns
p
CONN. STRAIGHT, 2PIN CJP02GA01Z
Y
INPUT CN38 ns
p
ns
p
CONN. STRAIGHT, 2PIN CJP02GA01Z
Y
INPUT CN55 ns
p
ns
p
CONN. STRAIGHT, 2PIN CJP02GA01Z
Y
INPUT CN95 ns
p
ns
p
CONN. 10P STRAIGHT CJP10GA19Z
Y
INPUT D251 ns
p
00MHD20015210 DIODE 1SS133T-77 HVD1SS133M
T
INPUT D252 ns
p
00MHD20015210 DIODE 1SS133T-77 HVD1SS133M
T
INPUT D301 ns
p
00MHD20015210 DIODE 1SS133T-77 HVD1SS133M
T
