99
Audio
Analog Outputs Output Level (balanced XLR): +4 dBu
Output Level
(unbalanced RCA): 2.0 Vrms
Digital Output
Output Level
(coaxial): 0.5V, 75 Ω
Signal Format: AES/EBU
Output Level
(optical): -21 dBm to -15 dBm (660 nm ± 30 nm)
Frequency Response
10 Hz – 20 kHz (±1.0 dB)
Signal-to-Noise Ratio
> 100 dB
(1 kHz, 0 dB, A-weighted)
Total Harmonic Distortion
< 0.05%
(1 kHz, 0 dB, A-weighted)
Dynamic Range
> 106 dB
(10–20,000 Hz, A-weighted)
Headroom
6 dB
Channel Separation
> 90 dB
(1 kHz, 0 dB, A-weighted)
Communication
Remote Control
Infrared protocol, > 200 mV transmission output level
Serial Remote Connector: 9-pin D-Sub female, RS-232C
Mode: Full duplex
Baud Rate: 9600
Other / General
Connections
(2) XLR audio outputs
(L/R, balanced)
(2) RCA audio outputs
(L/R, unbalanced)
(1) Optical audio output
(1) Coaxial digital audio output
(1) HDMI audio/visual output
(1) RCA Composite video output
(3) RCA Component video outputs
(Y/Pb/Pr)
(1) 9-pin D-Sub female RS-232C port
(1) IEC power connection
Power Connection: IEC
Requirement: 100–240 VAC, 50/60 Hz
Consumption: 10 W
Environmental Conditions Operating temperature: 41 – 95 °F (5 – 35 °C)
Operating humidity: 25 – 85%, no condensation
Dimensions
(width x depth x height, with rack ears)
19.00” x 10.75” x 1.73”
483 mm x 273 mm x 44 mm
Weight
(with rack ears)
5.9 lbs.
2.7 kg
