16
Example 3 – Stereo and Mix Recording
This example shows:
- condenser microphones on Inputs 1 and 2 (using +48V phantom power)
- a dynamic microphone on Input 3
- an audio device on Input 4
The menu options are configured to record 4 mono files from Inputs 1-4 and a mix of Inputs 1-4 on
tracks 5/6 with CH1 going to the left, CH2 to the right, and CH3 and CH4 mono.
The recorded files will be named as follows:
PMD706_0001_CH1_M.WAV
PMD706_0001_CH2_M.WAV
PMD706_0001_CH3M.WAV
PMD706_0001_CH4_M.WAV
PMD706_0001_CH56_MIX.WAV
