Appendix (English)
Technical Specifications
Connectors
(4) XLR+1/4” (6.35 mm) inputs
(2) 1/4” TRS (6.35 mm) inputs
(2) 1/8” (3.5 mm) inputs
(3) 1/8” (3.5 mm) outputs
(1) Micro-USB port, Type B
Power
Via 4 AA batteries (Alkaline or NI-MH), USB bus power, or a USB power adapter.
Consumption: 2 W (with phantom power off), 4 W (with 6 channels and phantom
power on)
Operating Humidity: 25–85%, non-condensing
Operating Temperature: 41–140°F / 5–60°C
Battery Life
Up to 5.5 hours (with phantom power off)
Supported SD Media
SD card (64 MB – 2 GB)
SDHC card (4 – 32 GB)
SDXC card (48 – 128 GB)
Recording Channels
6-channels (stereo × 3, mono × 6), 4-channels in Dual Stereo mode, 4 channels max
with 96 kHz sampling rate
Recording Formats WAV (44.1, 48, or 96 kHz; 16- or 24-bit)
BWF (44.1, 48, or 96 kHz; 16- or 24-bit)
Recording Modes
Mono, Stereo, Dual Mono, Dual Stereo, Mid/Side Recording, Mix
Audio Performance Signal to Noise:
93 dB (Line in -> Line Out)
88-90 dB (Mic in -> Line Out)
93 dB (Ext In -> Line Out)
93 dB (Camera In -> Line Out)
92 dB (Line In -> Phone Out)
92 dB (Line In -> Camera Out)
Frequency Response: 20 Hz–20 kHz (+1.0 dB)
Input Impedance: 2 KΩ
Phantom Power: 48 V (+4 V, 10 mA/channel), 24 V (+4 V, 10 mA/channel)
Audio Channels Inputs 1, 2, 3, 4 (set to Mic or Mic + phantom power)
Input Impedance: 4.7 KΩ
Maximum Input Level: -8 dBu
Mic Input Gain: +28 dB (Low), +47 dB (Mid), +59 dB (High), +64 dB (Hi Plus)
Inputs 1, 2, 3, 4, 5, 6 (set to Line)
Input Impedance: 4.7 KΩ
Standard Input Level: 0 dBu
Maximum Input Level: +12 dBu
Line Input Gain: +0 dB (Low), +10 dB (Mid), +20 dB (High), +30 dB (Hi Plus)
