1. TECHNICAL SPECIFICATIONS
2. SERVICE HINTS
3. SERVICE TOOLS
Audio signals disc 4822 397 30184
Disc without errors (SBC444)+
Disc with DO errors, black spots and fingerprints (SBC444A) 4822 397 30245
Disc (65 min 1kHz) without no pause 4822 397 30155
Max. diameter disc (58.0 mm) 4822 397 60141
Torx screwdrivers
Set (straight) 4822 395 50145
Set (square) 4822 395 50132
13th order filter 4822 395 30204
PMD330 PMD331 / PMD340
General specifications
System Compact Disc - Digital Audio
Number of channels 2
Compatible discs CD-DA, CD-R, CD-RW (12 cm, 8 cm)
Audio characteristics
Channels 2 channels
Frequency characteristics 20 Hz to 20 kHz +/- 0.3 dB
Dynamic range ≥ 90 dB (1 kHz)
S/N ratio ≥ 100 dB (1 kHz)
Total harmonic distortion (THD) 0.005 % (1 kHz)
Wow and flutter Quartz precision
Error correction method Cross-interleave Read-Solomon code (CIRC)
Analog output Pin jack,unbalanced (RCA) 2.0V RMS Stereo
XLR jack,balanced (XLR) +16 dBu /600 Ω, @ 0 dB FS
(variable range) (-11 dBu to +21 dBu, variable)
Digital output Pin jack (SPDIF) 0.5 Vp-p/75 Ω
XLR jack (SPDIF) 3.5 Vp-p/110 Ω
optical connector -19 dBm
Search precision 1 frame
Pitch control Maximum: +/-12% in 0.1% steps
Pitch bend control +/- 8 %
Strat timing 20 ms
Remote control
Infrared remote control input IN (IR sensor)
RC5 remote control input/output RCA IN (INT/EXT switch)/OUT
Remote control input/output D-SUB 25-Pin female
Optical anning method
Laser AlGaAs semiconductor
Wavelength 780 nm
Signal system
Sampling frequency 44.1 kHz
Quantization 16-bit linear/channel
Power supply section
AC power supply /F : 100V, AC 50/60Hz, /N : 230V, AC 50Hz, /U : 120V, AC 60Hz
Power consumption 12 W 17 W
Cabinet, etc.
External dimensions (W x H x D) 483 x 100 x 325 mm (19 x 3-15/16 x 12- 13/16 inches)
Weight 4.8 kg (10.6 lbs) 4.9 kg (10.8 lbs)
Operating temperature range + 5°C to + 35°C
Operating humidity range 5% to 90% (without dew)
Due to our continuing efforts to improve our products, the specifications and appearance of this product are subject to change without
prior notice.
