Marantz RC3200/A - Partslist

8-1
PARTSLIST - EXPLODED VIEW
2 3104 207 79200 TOPPART ASSY
3 3104 204 18820 BOTTOMPART ASSY
4 3104 204 18830 BATTERYLID
5 3104 207 79180 LCD BUTTON ASSY
6 3104 207 79190 SIDE BUTTON ASSY
7 3104 204 18740 EL-FOIL
8 3104 204 18780 IR-WINDOW
9 3104 204 18870 JACK COVER
11 3104 207 79170 KEYMAT ASSY
15 3104 200 51640 LCD DISPLAY
16 3104 200 04550 LABEL
3104 207 14360 PCB - MOTHER BOARD RC3200/A (3104 207 12710)
3104 207 14370 PCB - MOTHER BOARD RC3200/U1S/M1S (3104 207 13330)
Note: Only the parts mentioned in this list are normal service parts
