NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
27
POS.
NO
VERS.
COLOR
PART NO.
(FOR EUR)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR EUR)
DESCRIPTION
PART NO.
(MJI)
R911 nsp 33Ω ±5% 1/6W GD05330160
R912 nsp 33Ω ±5% 1/6W GD05330160
R913 nsp 33Ω ±5% 1/6W GD05330160
R914 nsp 33Ω ±5% 1/6W GD05330160
R915 nsp 100kΩ ±5% 1/6W GD05104160
R916 nsp 100kΩ ±5% 1/6W GD05104160
R917 nsp 100Ω ±5% 1/6W GD05101160
R918 nsp 100Ω ±5% 1/6W GD05101160
R919 nsp 8.2kΩ ±5% 1/6W GD05822160
R920 nsp 8.2kΩ ±5% 1/6W GD05822160
R921 nsp 4.7kΩ ±5% 1/6W GD05472160
R922 nsp 4.7kΩ ±5% 1/6W GD05472160
R923 nsp 4.7kΩ ±5% 1/6W GD05472160
R924 nsp 4.7kΩ ±5% 1/6W GD05472160
R925 nsp 4.7kΩ ±5% 1/6W GD05472160
R926 nsp 4.7kΩ ±5% 1/6W GD05472160
R930 RM01031220 VARIABLE RK09L12B0 10K B
D-CUT NORMAL
RM01031220
PR16-SEMICONDUCTORS
D901
nsp DIODE HD20002000
D904 1SS176 MA165 1SS254 30V 0.1A
Q901 HC10111090 IC NJM2114D
DUAL LOW NOISE OP-AMP
HC10111090
Q903 HT321201B0 TRS. 2SC2120 Y HT321201B0
Q904 HT321201B0 TRS. 2SC2120 Y HT321201B0
Q905 HT109501A0 TRS. 2SA950 GR OR R HT109501A0
Q906 HT109501A0 TRS. 2SA950 GR OR R HT109501A0
Q907 HT328782A0 TRS. 2SC2878 A OR B HT328782A0
Q908 HT328782A0 TRS. 2SC2878 A OR B HT328782A0
Q909 HT328782A0 TRS. 2SC2878 A OR B HT328782A0
Q910 HT328782A0 TRS. 2SC2878 A OR B HT328782A0
PR16-MISCELLANEOUS
J903 YJ01003870 H.P JACK HLJ0540-01-410 BLK YJ01003870
L901 FC90050130 FERRITE BEAD BL02RN2-R62T2 FC90050130
L902 FC90050130 FERRITE BEAD BL02RN2-R62T2 FC90050130
PY16-DISPLAY SW
CIRCUIT BOARD
PY16-CAPACITORS
CY01 nsp ELECT. 47 µF M 25V RA-2 OA47602520
CY02 nsp CER. 0.1 µF Z 50V F DK98104200
CY03 nsp ELECT. 47 µF M 25V RA-2 OA47602520
CY04 nsp CER. 0.047µF Z 50V F DK98473300
CY05 nsp ELECT. 220 µF M 10V RA-2 OA22701020
CY06 nsp CER. 0.1 µF Z 25V F DK98104200
CY07 nsp CER. 330 pF K 50V B DK96331300
PY16-RESISTORS
RY01 NI05271110 CHIP 270Ω ±5% 1/10W NI05271110
RY02 NI05271110 CHIP 270Ω ±5% 1/10W NI05271110
RY03 NI05391110 CHIP 390Ω ±5% 1/10W NI05391110
RY04 NI05181110 CHIP 180Ω ±5% 1/10W NI05181110
RY05 NI05181110 CHIP 180Ω ±5% 1/10W NI05181110
RY06 NI05151110 CHIP 150Ω ±5% 1/10W NI05151110
RY09 NI05391110 CHIP 390Ω ±5% 1/10W NI05391110
RY10 NI05151110 CHIP 150Ω ±5% 1/10W NI05151110
RY13 NI05102110 CHIP 1kΩ ±5% 1/10W NI05102110
RY14 NI05103110 CHIP 10kΩ ±5% 1/10W NI05103110
RY15 NI05332110 CHIP 3.3kΩ ±5% 1/10W NI05332110
RY16 NI05333110 CHIP 33kΩ ±5% 1/10W NI05333110
RY17 NI05271110 CHIP 270Ω ±5% 1/10W NI05271110
RY18 NI05471110 CHIP 470Ω ±5% 1/10W NI05471110
RY22 NI05101110 CHIP 100Ω ±5% 1/10W NI05101110
RY23 NI05102110 CHIP 1kΩ ±5% 1/10W NI05102110
RY24 NI05681110 CHIP 680Ω ±5% 1/10W NI05681110
RY25 NI05154110 CHIP 150kΩ ±5% 1/10W NI05154110
PY16-SEMICONDUCTORS
DY02 HI10062320 L.E.D. LT3D8B RED 3O HI10062320
DY07 HZ30024050 CHIP DIODE ZENER 02CZ3.9Ω HZ30024050
QY01 HC10471260 IC FL DRIVER ML9207-01 HC10471260
QY02 HX327121A0 CHIP TR. 2SC2712 G PKG TE85L HX327121A0
QY03 BA10006050 DIG. TRS. RN2402 CHIP BA10006050
QY04 BA10006050 DIG. TRS. RN2402 CHIP BA10006050
QY05 BA10006050 DIG. TRS. RN2402 CHIP BA10006050
PY16-MISCELLANEOUS
LY01 FC90050130 FERRITE BEAD BL02RN2-R62T2 FC90050130
LY02 FC90050130 FERRITE BEAD BL02RN2-R62T2 FC90050130
LY03 FC90050130 FERRITE BEAD BL02RN2-R62T2 FC90050130
LY04 FC90050130 FERRITE BEAD BL02RN2-R62T2 FC90050130
SY01
SP01013310 PUSH SWITCH SP01013310
SY10 SKQNAE H/5MM 160GF
VX01 HQ31302920 DISPLAY UNIT VFD CH2099C
NORITAKE
HQ31302920
XY01 FQ04004030 CERAMIC VIB. CERALOCK
CST4.00MGW
FQ04004030
ZY01
HW10004210 PHOTO UNIT RPM6936-V4
IR SENSOR
HW10004210
PY26-ILMINATION
CIRCUIT BOARD
CY10 nsp CER. 0.1µF GRM39F104Z16 DK98104200
DY01 HI10162320 L.E.D. GL3BC802B0SC B-TAPING HI10162320
RY27 NI05103110 CHIP 10kΩ ±5% 1/10W NI05103110
