NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
2.1 EXPLODED VIEW AND PARTS LIST
2-1
POS. NO
VERS.
COLOR
PART NO.
(FOR EUR)
DESCRIPTION
PART NO.
(MJI)
1 nsp nsp CHASSIS MAIN CHASSIS ASSY 9KC 1A01 7
2 13AK160210 13AK160210 BRAKET CLAMPER BRACKET 9KA 7P08 5
3 nsp nsp BRAKET GUIDE CLAMP BRACKET 9KA 2P84 1
4 *MM001290R *MM001290R MOTOR LOADING MOTOR ASSY 9KC 2A00 3
5 13AK058230 13AK058230 GEAR LOADING GEAR 9KC 2G02 9
6 13AK058210 13AK058210 GEAR LOADING GEAR 2ND 9KB 9G03 0
7 13AK058220 13AK058220 GEAR LOADING GEAR 3RD 9KB 9G03 1
8 13AK105210 13AK105210 CHASSIS SUB CHASSIS-L 9KA 2G41 7
9 13AK105220 13AK105220 CHASSIS SUB CHASSIS-R 9KA 2G41 8
10 13AK163210 13AK163210 TRAY TRAY-D4 9KA 2G778
11 13AK054210 13AK054210 CAM SLIDE-CAM 9KC 1G00 3
12 13AK002210 13AK002210 ARM TRAVERSE ARM 9KC 1G00 4
14 13AK005210 13AK005210 CLAMPER CLAMPER H 9KA 7G20 2
15 13AK005220 13AK005220 CLAMPER CLAMPER L 9KA 7G20 3
16 13AK264210 13AK264210 BELT LOADING BELT 9KB 9G01 5
17 nsp nsp PCB ASSY SWITCH P.W.B. 9KC 1P01 4
18 nsp nsp CORD 5P PH WIRE 9KC 2G04 3
19 *SP001260R *SP001260R SWITCH SWITCH ESE22MH21 9KS 01W2 04
20 *SP001270R *SP001270R SWITCH SWITCH ESE22MH23 9KS 01W2 05
21 13AK012210 13AK012210 WASHER POLY.SLIT WASHER 2.6X6X0.25C 9KP 26C6 25
22 nsp nsp CLAMPER WIRE CLAMPER 445 8004 007
23 nsp nsp SCREW PRECISION SCREW 1.7X2.2 TYPE3 9KS 17N0 22
24 nsp nsp SCREW SCREW 2.6X6 CBTS(B)-Z 9KB 26BK 06
25 nsp nsp SCREW PRECISION SCREW 2X3(S) TYPE3 9KS 20TK 33
26 nsp nsp SCREW SCREW 2X6 CBTS(P)-Z 9KB 20PK 06
27A 13AK304210 13AK304210 MECHA TRAVERSE TRAVERSE MECHA (FEED) ASSY 9KC 2A06 3A
27 nsp nsp CHASSIS PU CHASSIS ASSY -
28 nsp nsp HOLDER SHAFT HOLDER L -
29 nsp nsp HOLDER SHAFT HOLDER R -
30 nsp nsp BRAKET SHAFT TILT BASE -
31 nsp nsp RETAINER SHAFT TILT PLATE -
32 nsp nsp SPRING TILT SPRING -
33 nsp nsp SHAFT MAIN SHAFT -
34 nsp nsp SHAFT SUB SHAFT -
35 nsp nsp GEAR PU RACK GEAR -
36 nsp nsp GEAR FEED GEAR 2ND ASSY -
37 nsp nsp MECHANISM PICK UP HOP-1200R -
38 nsp nsp SPRING PU SPRING -
39 nsp nsp SPRING SHAFT SPRING -
40 nsp nsp SPRING RACK GEAR SPRING -
41 nsp nsp MOTOR FEED MOTOR ASSY -
42 nsp nsp MOTOR T/T MOTOR ASSY -
43 nsp nsp SCREW SCREW 2.6X6 CBTS(S)-Z -
44 nsp nsp SCREW SCREW 2.6X4 CBTS(S)-Z -
46 nsp nsp SCREW SCREW 2.6X15 CFTS(S)-Z -
47 nsp nsp SCREW SCREW 3X4 BSS -
48 nsp nsp SCREW SCREW 3X8 BSS (A) -
49 13AK130210 13AK130210 DAMPER DAMPER-SI25-LB 9KA 2G643
50 nsp nsp WASHER POLY.SLIT WASHER 2.1X4X0.25C -
51 nsp nsp SCREW SPECIAL SCREW (FRONT) -
52 nsp nsp SCREW SPECIAL SCREW (REAR) -
54 13AK116210 13AK116210 LEAF SPRING TRAY-SPRING-VXF 9KB 7P02 4
53 nsp nsp GEAR FEED GEAR 3RD -
60 13AK104210 13AK104210 RETAINER PLATE-RE-2HPC 9KC 2P03 1
61 13AK104220 13AK104220 RETAINER WF-PLATE-RE-2HPC 9KC 2P03 2
62 nsp nsp SCREW PRECISION SCREW 2X4(P) TYPE1 9KS 20P1 04
