3-5
No. Terminal Name I/O A/D Classifi cation Function PU PD SMT
164 TEST5 O D TEST/Monitor TEST I/O 5.
165 TEST6 O D TEST/Monitor TEST I/O 6.
166 TEST7 O D TEST/Monitor TEST I/O 7.
167 TEST8 O D TEST/Monitor TEST I/O 8.
168 TEST9 O D TEST/Monitor TEST I/O 9.
169 TEST10 O D TEST/Monitor TEST I/O 10.
170 TEST11 O D TEST/Monitor TEST I/O 11.
171 TEST12 O D TEST/Monitor TEST I/O 12.
172 TEST13 O D TEST/Monitor TEST I/O 13.
173 TEST14 O D TEST/Monitor TEST I/O 14.
174 TEST15 O D TEST/Monitor TEST I/O 15.
175 MODSEL0 I D TEST/Monitor TEST mode select 0. (GND, under normal conditions)
176 MODSEL1 I D TEST/Monitor TEST mode select 1. (GND, under normal conditions)
177 DVSS P VDD & GND Digital Ground.
178 MODSEL2 I D TEST/Monitor TEST mode select 2. (GND, under normal conditions)
179 GIO0 I/O D Multi-purpose Multi-purpose port 0. * *
180 GIO1 I/O D Multi-purpose Multi-purpose port 1. * *
181 GIO2 I/O D Multi-purpose Multi-purpose port 2. * *
182 GIO3 I/O D Multi-purpose Multi-purpose port 3. * *
183 DVDD33 P VDD & GND Digital 3.3V Power for I/O.
184 GIO4 I/O D General Port Multi-purpose port 4. * *
185 GIO5 I/O D General Port Multi-purpose port 5. * *
186 GIO6 I/O D General Port Multi-purpose port 6. * *
187 GIO7 I/O D General Port Multi-purpose port 7. * *
188 DVDD18 P VDD & GND Digital 1.8V Power for I/O. (for internal Logic system)
189 GIO8 I/O D General Port Multi-purpose port 8. * *
190 GIO9 I/O D General Port Multi-purpose port 9. * * *
191 GIO10 I/O D General Port Multi-purpose port 10. * *
192 GIO11 I/O D General Port Multi-purpose port 11. * *
193 GIO12 I/O D General Port Multi-purpose port 12. * * *
194 DVSS P VDD & GND Digital Ground.
195 GIO13 I/O D Multi-purpose Multi-purpose port 13. * * *
196 GIO14 I/O D General Port Multi-purpose port 14. * * *
197 GIO15 I/O D General Port Multi-purpose port 15. * * *
198 GIO16 I/O D General Port Multi-purpose port 16. * *
199 GIO17 I/O D General Port Multi-purpose port 17. * *
200 GIO18 I/O D General Port Multi-purpose port 18. * *
201 GIO19 I/O D General Port Multi-purpose port 19. * *
202 TRST I D JTAG I/F JTAG Reset input. * *
203 TMS I D JTAG I/F JTAG Mode Select input. * *
204 TDI I D JTAG I/F JTAG Data Input. * *
205 TCK I D JTAG I/F JTAG Clock input. *
206 TDO O D JTAG I/F JTAG Data output.
207 VMCHG I D MCU I/F VSTEM / external MCU access selection terminal of system
setting register for DSP. (L: VSTEM, H: external MCU)
208 DVDD18 P VDD & GND Digital 1.8V power for internal Logic system.
IC502 : CXD1885Q
