NJU3716 NJU3719
Pin No. Data output pin NJU3716 Pin No. Data output pin NJU3719
*17 P1 NON *20 P1 LED3b
*19 P2 TAPE LED *21 P2 LED3c
*20 P3 LINE-2 LED *22 P3 LED3-DP
*21 P4 LINE-1 LED *23 P4 LED3d
*22 P5 SACD/CD LED *24 P5 LED3e
*23 P6 BALANCED LED *25 P6 LED3g
*1 P7 POWER LED *26 P7 LED3f
*2 P8 ATT LED *27 P8 LED3a
*3 P9 B-CH LED *28 P9 NON
*4 P10 A-CH LED *29 P10 LED1g
*5 P11 SYNK-RED LED *1 P11 LED2a
*7 P12 SYNK-GR LED *2 P12 LED2f
*8 P13 DISPLAY LED *3 P13 LED2g
*9 P14 LIGHT-A *4 P14 LED2e
*10 P15 LIGHT-B *5 P15 LED2d
*11 P16 NON *6 P16 LED2c
*12 SO *7 P17 LED2b
*9 P18 LED4a
*10 P19 LED4f
*11 P20 LED4g
*12 P21 LED4e
*13 P22 LED4d
*14 P23 LED4c
*15 P24 LED4b
DATA SO DATA
LED1 LED2 LED3 LED4
a
b
c
g
d
e
f
D.P
