Marantz SD4050 /N1B - Page 19

25
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST, N:EUROPE)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST, N:EUROPE)
R350 nsp 47k nsp
R351 nsp 22k nsp
R352 nsp 4.7k nsp
R353 nsp 18k nsp
R354 nsp 18k nsp
R355 nsp 10k nsp
R356 nsp 2.7k nsp
R357 nsp 1k nsp
R358 nsp 27k nsp
R359 nsp 27k nsp
R360 nsp 47k nsp
R361 nsp 47k nsp
R367 nsp 22k nsp
R368 nsp 22k nsp
R370 nsp 1k nsp
R371 nsp 330 nsp
R373 nsp 470 nsp
R374 nsp 470 nsp
R375 nsp 2.7k nsp
R376 nsp 3.3k nsp
R378 nsp 68 nsp
R381 nsp 47k nsp
R382 nsp 47k nsp
R383 nsp 560 nsp
R384 nsp 4.7k nsp
R385 nsp 6.8 1/4W nsp
R386 nsp 6.8 1/4W nsp
R387 nsp 100k nsp
R388 nsp 100k nsp
R391 nsp 270 nsp
R11 9965 000 01140 VSemi-fixed 10k (B) *RA000780R
R21 9965 000 01140 VSemi-fixed 10k (B) *RA000780R
R12 9965 000 01140 VSemi-fixed 10k (B) *RA000780R
R22 9965 000 01140 VSemi-fixed 10k (B) *RA000780R
R13 9965 000 01141 VSemi-fixed 22k (B) *RA000920R
R23 9965 000 01141 VSemi-fixed 22k (B) *RA000920R
R14 9965 000 01140 VSemi-fixed 10k (B) *RA000780R
R24 9965 000 01140 VSemi-fixed 10k (B) *RA000780R
COILS
L102 9965 000 01143 22mH *LC107240R
L202 9965 000 01143 22mH *LC107240R
L103 9965 000 01144 STEP UP *TC000310R
L203 9965 000 01144 STEP UP *TC000310R
L301 9965 000 01145 Bias SM-10F *TC000330R
L302 9965 000 01146 220 H *LC106610R
L303 9965 000 01146 220 H *LC106610R
MISCELLANEOUS
L101 9965 000 01142 Filter Low Pass MPX *TC000300R
L201 9965 000 01142 Filter Low Pass MPX *TC000300R
J32 9965 000 01147 Jack RCA 4P *YT001790R
P304 nsp Plug 5P nsp
P305 nsp Plug 3P nsp
P306 nsp Plug 3P nsp
P307 nsp Plug 12P nsp
P308 nsp Plug 9P nsp
P309 nsp Plug 6P nsp
TR ASSY CIRCUIT BOARD
INTEGRATED CIRCUITS
U7 4822 209 31631 IC NJM7805FA HC3890509F
TRANSISTOR
Q307 9965 000 01148 2SB1655E *HT200360R
SLIDE CIRCUIT BOARD
SW21 9965 000 01149 Switch Slide AXA 2-3 *SS000600R
SW26 9965 000 01149 Switch Slide AXA 2-3 *SS000600R
SW27 9965 000 01149 Switch Slide AXA 2-3 *SS000600R
KEY CIRCIT BOARD
CAPACITOR
C11 nsp ELECT 47 F 16V nsp
DIODES
D9
4822 130 32778 1SS133 HD20015210
D12
D13A 4822 130 32778 1SS133 HD20015210
D15
4822 130 32778 1SS133 HD20015210
D19
D20A 4822 130 32778 1SS133 HD20015210
D22 4822 130 32778 1SS133 HD20015210
D23 4822 130 32778 1SS133 HD20015210
D25 4822 130 32778 1SS133 HD20015210
D26 4822 130 32778 1SS133 HD20015210
D27A 4822 130 32778 1SS133 HD20015210
D29 4822 130 32778 1SS133 HD20015210
D33 4822 130 32778 1SS133 HD20015210
D34 4822 130 32778 1SS133 HD20015210
D35 4822 130 32778 1SS133 HD20015210
D41 4822 130 32778 1SS133 HD20015210
INTEGRATED CIRCUIT
U56 9965 000 01150 IR Sensor SBX1976-52 *HW100340R
RESISTORS
R80
nsp 22k 5% 1/8W nsp
R83
R95 nsp 470 5% 1/8W nsp
MISCELLANEOUS
FL1 9965 000 01151 Display SVA-06SM14 *HQ300370R
SW1
9965 000 01153 Switch Tact SKQSAB HMR-187 *SP000750R
SW4
SW7
9965 000 01153 Switch Tact SKQSAB HMR-187 *SP000750R
SW11
SW14
9965 000 01153 Switch Tact SKQSAB HMR-187 *SP000750R
SW18
SW22
9965 000 01153 Switch Tact SKQSAB HMR-187 *SP000750R
SW25 9965 000 01153 Switch Tact SKQSAB HMR-187 *SP000750R
CONTROL CIRCUIT BOARD
CAPACITOS
C1 nsp ELECT 100 F 35V nsp
C2 nsp ELECT 220 F 35V nsp
C3 nsp ELECT 330 F 25V nsp
C4 nsp Mylar 0. 047 F 100V nsp
C5 nsp ELECT
10 F 16V
nsp
C6 nsp ELECT
10 F 16V
nsp
C7 9965 000 01154 ELECT 220 F 25V *EA000660R
C8 nsp CER. 0.01 F 50V nsp
C9 nsp Mylar 0.022 F 100V nsp
C10 nsp ELECT
1000 F 25V
nsp
