26
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST, N:EUROPE)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST, N:EUROPE)
DIODES
D1 4822 130 80598 Zener Diode MTZJ22C *HD301680R
D2 4822 130 31878 1N4003 HD200010AR
D3 4822 130 31878 1N4003 HD200010AR
D4 4822 130 32778 1SS133 HD20015210
D5 4822 130 31878 1N4003 HD200010AR
D8 9965 000 01155 Zener Diode MTZJ3.9B *HD301410R
D50 4822 130 31878 1N4003 HD200010AR
D51 4822 130 31878 1N4003 HD200010AR
INTEGRATED CIRCUITS
U41 5322 209 73891 TA78L005AP *HC300180R
U42 9965 000 01156 CXP82940 *HC105100R
U45 4822 209 61973 BU4066BC HC406621B0
TRANSISTORS
U43 4822 130 42683 DTC124ES BA20024210
U44 4822 130 42683 DTC124ES BA20024210
U47
4822 130 42683 DTC124ES BA20024210
U50
U51 4822 130 42593 DTA124ES BA10016210
U52
4822 130 42683 DTC124ES BA20024210
U55
Q1 4822 130 11101 T2SA1015GR HT110151C0
Q2 4822 130 41306 T2SC1815GR HT318151C0
Q3
9965 000 01157 T2SB1237TV2Q *HT200310R
Q6
Q7 4822 130 41306 T2SC1815GR HT318151C0
RESISTORS
All resistor are rated 5%
tolerance and 1/8 watt.
R41 nsp 820 nsp
R42 nsp 22k nsp
R43 nsp 10k nsp
R44 nsp 22k nsp
R45 nsp 22k nsp
R46 nsp 1k nsp
R47 nsp 22k nsp
R48 nsp 15k nsp
R49 nsp 27k nsp
R50 nsp 4.7k nsp
R51 nsp 1k nsp
R52 nsp 4.7k nsp
R53 nsp 1k nsp
R54 nsp 4.7k nsp
R55 nsp 1k nsp
R56 nsp 4.7k nsp
R57 nsp 1k nsp
R62 nsp 1k nsp
R63 nsp 10k nsp
R64 nsp 22k nsp
R72 nsp 22k nsp
R73 nsp 22k nsp
R74 nsp 22k nsp
R77 nsp 82k nsp
R78 nsp 82k nsp
R84 nsp 22k nsp
R85 nsp 22k nsp
R86 nsp 22k nsp
R87 nsp 100 1/4W nsp
R88 nsp 100 1/4W nsp
R89 nsp 5.6k nsp
R90 nsp 1k nsp
R91 nsp 10k nsp
R92 nsp 22k nsp
R93 nsp 22k nsp
R94 nsp 22k nsp
VR1 9965 000 01140 VSemi-fixed 10k (B) *RA000780R
VR2 9965 000 01140 VSemi-fixed 10k (B) *RA000780R
VR3 9965 000 01140 VSemi-fixed 10k (B) *RA000780R
VR4 9965 000 01140 VSemi-fixed 10k (B) *RA000780R
MISCELLANEOUS
P318 nsp Plug 2P nsp
P503 nsp Plug 3P nsp
P504 nsp Plug 2P nsp
X1 9965 000 01158 Resonator Ceramic 8MHz *FQ000400R
VR CIRCUIT BOARD
RESISTORS
R410 nsp 9.1k 5% 1/8W nsp
R411 nsp 27k 5% 1/8W nsp
R31 9965 000 01159 Variable Resistor 50k (A)*2 *RM000380R
R32 9965 000 01160 Variable Resistor 10k (B) *RM000390R
PHONE CIRCUIT BOARD
C403 nsp CER. CAP 0.047 F 50V nsp
J31 9965 000 01161 Jack JY-6317-01-030G *YT001780R
TRANS A CIRCUIT BOARD
AC2 nsp Terminal Lapping 2P nsp
W170 nsp Jumper 10mm
N
F
U
nsp
W171
N
nsp Jumper 10mm nsp
W172 nsp Jumper 10mm nsp
TRANS B CIRCUIT BOARD
C901 nsp CER. CAP 0.1 F 50V nsp
S401 9965 000 01162 Switch Push SPUN-12 *SP000740R
L901 9965 000 01163 COIL 3.3 H *LC107250R
L902 9965 000 01163 COIL 3.3 H *LC107250R
REMOTE CIRCUIT BOARD
C450 nsp CER. CAP 0.1 F 50V nsp
R450 nsp RES. 47 5% 1/8W nsp
J33 9965 000 01164 Jack RCA 2P (ORANGE) *YT001800R
47 9965 000 01128 MAINS TRANSFORMER *TS001060R
