Marantz SR5002N1B - Page 105

127
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.W.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
MAIN Q902 90M-BA001530R 90M-BA001530R TRS. KTC114M HVTKRC114MT
MAIN Q903 90M-BA001460R 90M-BA001460R TRS. KRC107M HVTKRC107MT
MAIN Q904 00MHT600111B0 00MHT600111B0 TRS. KTA1267Y HVTKTA1267YT
MAIN Q905 90M-HT800050R 90M-HT800050R TRS. KTC3198Y HVTKTC3198YT
MAIN Q906 00MHT600111B0 00MHT600111B0 TRS. KTA1267Y HVTKTA1267YT
MAIN Q911 00MHT600111B0 00MHT600111B0 TRS. KTA1267Y HVTKTA1267YT
MAIN Q912 90M-HT800050R 90M-HT800050R TRS. KTC3198Y HVTKTC3198YT
MAIN Q913 90M-HT800050R 90M-HT800050R TRS. KTC3198Y HVTKTC3198YT
MAIN Q915 90M-BA001450R 90M-BA001450R TRS. KRA107M HVTKRA107MT
MAIN Q916 90M-HT800050R 90M-HT800050R TRS. KTC3198Y HVTKTC3198YT
MAIN Q917 90M-BA001460R 90M-BA001460R TRS. KRC107M HVTKRC107MT
MAIN Q918 00MHT600111B0 00MHT600111B0 TRS. KTA1267Y HVTKTA1267YT
MAIN Q919 90M-HT800050R 90M-HT800050R TRS. KTC3198Y HVTKTC3198YT
MAIN Q920 90M-HT800050R 90M-HT800050R TRS. KTC3198Y HVTKTC3198YT
MAIN Q921 90M-BA001450R 90M-BA001450R TRS. KRA107M HVTKRA107MT
MAIN Q925 90M-HT800050R 90M-HT800050R TRS. KTC3198Y HVTKTC3198YT
MAIN Q926 00MHT600111B0 00MHT600111B0 TRS. KTA1267Y HVTKTA1267YT
MAIN Q927 90M-BA001460R 90M-BA001460R TRS. KRC107M HVTKRC107MT
MAIN Q928 90M-BA001460R 90M-BA001460R TRS. KRC107M HVTKRC107MT
MAIN Q929 90M-HT600030R 90M-HT600030R TRS. KTA1024Y HVTKTA1024YT
MAIN Q960 90M-BA001460R 90M-BA001460R TRS. KRC107M HVTKRC107MT
MAIN Q961 90M-HT600030R 90M-HT600030R TRS. KTA1024Y HVTKTA1024YT
MAIN Q997 90M-BA001460R 90M-BA001460R TRS. KRC107M HVTKRC107MT
MAIN Q998 00MHT600111B0 00MHT600111B0 TRS. KTA1267Y HVTKTA1267YT
MAIN R501 ns
p
ns
p
RES. 43K OHM 1/5W J CRD20TJ433T
MAIN R502 ns
p
ns
p
RES. 43K OHM 1/5W J CRD20TJ433T
MAIN R503 ns
p
ns
p
RES. 43K OHM 1/5W J CRD20TJ433T
MAIN R506 ns
p
ns
p
RES. 33K OHM 1/5W J CRD20TJ333T
MAIN R507 ns
p
ns
p
RES. 33K OHM 1/5W J CRD20TJ333T
MAIN R508 ns
p
ns
p
RES. 33K OHM 1/5W J CRD20TJ333T
MAIN R509 ns
p
ns
p
RES. 33K OHM 1/5W J CRD20TJ333T
MAIN R510 ns
p
ns
p
RES. 33K OHM 1/5W J CRD20TJ333T
MAIN R511 ns
p
ns
p
RES. 1.5K OHM 1/5W J CRD20TJ152T
MAIN R512 ns
p
ns
p
RES. 1.5K OHM 1/5W J CRD20TJ152T
MAIN R513 ns
p
ns
p
RES. 1.5K OHM 1/5W J CRD20TJ152T
MAIN R514 ns
p
ns
p
RES. 1.5K OHM 1/5W J CRD20TJ152T
MAIN R515 ns
p
ns
p
RES. 1.5K OHM 1/5W J CRD20TJ152T
MAIN R516 ns
p
ns
p
RES. 1.5K OHM 1/5W J CRD20TJ152T
MAIN R517 ns
p
ns
p
RES. 1.5K OHM 1/5W J CRD20TJ152T
MAIN R518 ns
p
ns
p
RES. 1.5K OHM 1/5W J CRD20TJ152T
MAIN R519 ns
p
ns
p
RES. 1.5K OHM 1/5W J CRD20TJ152T
MAIN R520 ns
p
ns
p
RES. 1.5K OHM 1/5W J CRD20TJ152T
MAIN R521 ns
p
ns
p
RES. 470 OHM 1/5W J CRD20TJ471T
MAIN R522 ns
p
ns
p
RES. 470 OHM 1/5W J CRD20TJ471T
MAIN R523 ns
p
ns
p
RES. 470 OHM 1/5W J CRD20TJ471T
MAIN R524 ns
p
ns
p
RES. 470 OHM 1/5W J CRD20TJ471T
MAIN R525 ns
p
ns
p
RES. 470 OHM 1/5W J CRD20TJ471T
MAIN R531 ns
p
ns
p
RES. 150 OHM 1/6W J CRD20TJ151T
MAIN R532 ns
p
ns
p
RES. 150 OHM 1/6W J CRD20TJ151T
MAIN R533 ns
p
ns
p
RES. 150 OHM 1/6W J CRD20TJ151T
MAIN R534 ns
p
ns
p
RES. 150 OHM 1/6W J CRD20TJ151T
MAIN R535 ns
p
ns
p
RES. 150 OHM 1/6W J CRD20TJ151T
MAIN R536 ns
p
ns
p
RES. 150 OHM 1/6W J CRD20TJ151T
MAIN R537 ns
p
ns
p
RES. 150 OHM 1/6W J CRD20TJ151T
MAIN R538 ns
p
ns
p
RES. 150 OHM 1/6W J CRD20TJ151T
MAIN R539 ns
p
ns
p
RES. 150 OHM 1/6W J CRD20TJ151T
MAIN R540 ns
p
ns
p
RES. 150 OHM 1/6W J CRD20TJ151T
MAIN R541 ns
p
ns
p
RES. 270 OHM 1/5W J CRD20TJ271T
MAIN R542 ns
p
ns
p
RES. 270 OHM 1/5W J CRD20TJ271T
MAIN R543 ns
p
ns
p
RES. 270 OHM 1/5W J CRD20TJ271T
MAIN R544 ns
p
ns
p
RES. 270 OHM 1/5W J CRD20TJ271T
MAIN R545 ns
p
ns
p
RES. 270 OHM 1/5W J CRD20TJ271T
MAIN R546 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473T
MAIN R547 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473T
MAIN R556 ns
p
ns
p
RES. 33K OHM 1/4W J CRD25TJ333T
MAIN R557 ns
p
ns
p
RES. 33K OHM 1/4W J CRD25TJ333T
MAIN R558 ns
p
ns
p
RES. 33K OHM 1/4W J CRD25TJ333T
