Marantz SR5002N1B - Page 109

131
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.W.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
MAIN R928 ns
p
ns
p
RES. 27K OHM 1/6W J CRD20TJ273T
MAIN R929 ns
p
ns
p
RES. 330 OHM 1/5W J CRD20TJ331T
MAIN R932 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103T
MAIN R937 ns
p
ns
p
RES. 15K OHM 1/5W J CRD20TJ153T
MAIN R938 ns
p
ns
p
RES. 33K OHM 1/5W J CRD20TJ333T
MAIN R939 ns
p
ns
p
RES. 33K OHM 1/5W J CRD20TJ333T
MAIN R941 ns
p
ns
p
RES. 68K OHM 1/4W J CRD25TJ683T
MAIN R942 ns
p
ns
p
RES. 68K OHM 1/5W J CRD20TJ683T
MAIN R943 ns
p
ns
p
RES. 68K OHM 1/5W J CRD20TJ683T
MAIN R944 ns
p
ns
p
RES. 68K OHM 1/4W J CRD25TJ683T
MAIN R945 ns
p
ns
p
RES. 68K OHM 1/5W J CRD20TJ683T
MAIN R946 ns
p
ns
p
RES. 68K OHM 1/5W J CRD20TJ683T
MAIN R947 ns
p
ns
p
RES. 68K OHM 1/4W J CRD25TJ683T
MAIN R948 ns
p
ns
p
RES. 2.2K OHM 1/5W J CRD20TJ222T
MAIN R949 ns
p
ns
p
RES. 15K OHM 1/5W J CRD20TJ153T
MAIN R950 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473T
MAIN R951 ns
p
ns
p
RES. 22K OHM 1/5W J CRD20TJ223T
MAIN R952 ns
p
ns
p
RES. 22K OHM 1/5W J CRD20TJ223T
MAIN R953 ns
p
ns
p
RES. 22K OHM 1/5W J CRD20TJ223T
MAIN R954 ns
p
ns
p
RES. 4.7K OHM 1/5W J CRD20TJ472T
MAIN R955 ns
p
ns
p
RES. 4.7 OHM 1/5W J CRD20TJ4R7T
MAIN R956 ns
p
ns
p
RES. 4.7 OHM 1/5W J CRD20TJ4R7T
MAIN R957 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103T
MAIN R958 ns
p
ns
p
RES. 4.7K OHM 1/5W J CRD20TJ472T
MAIN R959 ns
p
ns
p
RES. 4.7 OHM 1/5W J CRD20TJ4R7T
MAIN R960 ns
p
ns
p
RES. 4.7 OHM 1/5W J CRD20TJ4R7T
MAIN R961 ns
p
ns
p
RES. 330 OHM 1/5W J CRD20TJ331T
MAIN R962 ns
p
ns
p
RES. 27K OHM 1/6W J CRD20TJ273T
MAIN R963 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
MAIN R964 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
MAIN R970 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103T
MAIN R971 ns
p
ns
p
RES. 15K OHM 1/5W J CRD20TJ153T
MAIN R972 ns
p
ns
p
RES. 4.7K OHM 1/5W J CRD20TJ472T
MAIN R974 ns
p
ns
p
RES. 330 OHM 1/5W J CRD20TJ331T
MAIN R975 ns
p
ns
p
RES. 330 OHM 1/5W J CRD20TJ331T
MAIN R976 ns
p
ns
p
RES. 330 OHM 1/5W J CRD20TJ331T
MAIN R977 ns
p
ns
p
RES. 330 OHM 1/5W J CRD20TJ331T
MAIN R978 ns
p
ns
p
RES. 330 OHM 1/5W J CRD20TJ331T
MAIN R979 ns
p
ns
p
RES. 39K OHM 1/5W J CRD20TJ393T
MAIN R980 ns
p
ns
p
RES. 15K OHM 1/5W J CRD20TJ153T
MAIN R981 ns
p
ns
p
RES. 56 OHM 1/4W J CRD25TJ560T
MAIN R982 ns
p
ns
p
RES. 4.7 OHM 1/5W J CRD20TJ4R7T
MAIN R983 ns
p
ns
p
RES. 4.7 OHM 1/5W J CRD20TJ4R7T
MAIN R984 ns
p
ns
p
RES. 4.7K OHM 1/5W J CRD20TJ472T
MAIN R985 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103T
MAIN R990 ns
p
ns
p
RES. 10 OHM CRG1ANJ100H
MAIN R993 ns
p
ns
p
RES. 10 OHM CRG1ANJ100H
MAIN R994 ns
p
ns
p
RES. 10 OHM CRG1ANJ100H
MAIN R995 ns
p
ns
p
RES. 10 OHM CRG1ANJ100H
MAIN R996 ns
p
ns
p
RES. 10 OHM CRG1ANJ100H
MAIN R997 ns
p
ns
p
RES. 10 OHM CRG1ANJ100H
MAIN R999 ns
p
ns
p
RES. 10 OHM CRG1ANJ100H
MAIN RY94 90M-LY000340R 90M-LY000340R RELAY ! SDT-S-112DMR HSL1A008ZE
MAIN RY95 00MLY20240490 00MLY20240490 RELAY 5GPA-28 DC24 HSL3B013ZE
MAIN RY96 00MLY20240510 00MLY20240510 RELAY OSA-SS-224DM3 HSL4B017ZU
MAIN RY97 00MLY20240490 00MLY20240490 RELAY 5GPA-28 DC24 HSL3B013ZE
MAIN T902
/
N1B 90M-TS001940R 90M-TS001940R TRANSF. ! SUB SR5400
(
6400
)
/N1 CLT5I002ZE
MAIN T902
/
N1S 90M-TS001940R 90M-TS001940R TRANSF. ! SUB SR5400
(
6400
)
/N1 CLT5I002ZE
MAIN T902
/
U1B ns
p
90M-TS001970R TRANSF. ! SUB SR5400
(
6400
)
/U1 CLT5I002ZU
MAIN TH91 90M-HP000090R 90M-HP000090R VARISTOR POSISTOR ASSY CRTSYPSX06850JD
MICROPHONE PWB
MICRO P BN82 ns
p
ns
p
CORD WIRE ASSY CWB2B905080EN
MICRO P C896 ns
p
ns
p
CER. CAP. 0.1UF 50V Z HCBS1H104ZFT
MICRO P D815 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
MICRO P D816 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
MICRO P JK90
/
N1B 90M-YT004320R 90M-YT004320R TERMINAL HEADPHONE JACK HJJ2D003Z
MICRO P JK90
/
N1S 90M-YT004120R 90M-YT004120R TERMINAL HEADPHONE JACK SILVER HJJ2D003Y
