NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.W.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
VIDEO C755
/
N1B ns
p
00MDD91080300 CER. CAP. 8PF 50V CCUS1H080DA
VIDEO C755
/
N1S ns
p
00MDD91080300 CER. CAP. 8PF 50V CCUS1H080DA
VIDEO C756 ns
p
00MDD91100300 CER. CAP. 10PF 50V JA CCUS1H100JA
VIDEO C757 ns
p
90M-DK900110R CER. CAP. 0.22UF 16V CCUS1C224KC
VIDEO C758 ns
p
00MDK96222300 CER. CAP. 2200PF 50V KC CCUS1H222KC
VIDEO C759 ns
p
00MDK96103300 CER. CAP. 0.01UF 50V KC CCUS1H103KC
VIDEO C760 ns
p
00MOA22505020 ELECT CAP. 2.2UF 50V CCEA1HH2R2T
VIDEO C761 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
VIDEO C762 ns
p
00MDK98223300 CER. CAP. 0.022UF 50V KC CCUS1H223KC
VIDEO C763 ns
p
00MOA22505020 ELECT CAP. 2.2UF 50V CCEA1HH2R2T
VIDEO C764 ns
p
00MOA47602520 ELECT CAP. 47UF 25V CCEA1EH470T
VIDEO C765 ns
p
00MDK96103300 CER. CAP. 0.01UF 50V KC CCUS1H103KC
VIDEO C768 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
VIDEO C769 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
VIDEO C770 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
VIDEO C771 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
VIDEO C772 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
VIDEO C773 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
VIDEO C774 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
VIDEO CN24 ns
p
ns
p
CONN. 5P STRAIGHT CJP05GA19ZY
VIDEO CN41 ns
p
ns
p
CONN. 5P WAFER YMW025-05R CJP05GA01ZY
VIDEO CN42 ns
p
ns
p
CONN. 5P STRAIGHT CJP05GA19ZY
VIDEO CN43 ns
p
ns
p
CONN. 21P FPC WAFER CJP21GA117ZY
VIDEO CN44 ns
p
ns
p
CONN. 5P STRAIGHT CJP05GA19ZY
VIDEO CN45
/
N1B ns
p
ns
p
CONN. 17P WAFER CARD CABLE CJP17GA115ZY
VIDEO CN45
/
N1S ns
p
ns
p
CONN. 17P WAFER CARD CABLE CJP17GA115ZY
VIDEO CN45
/
U1B ns
p
ns
p
CONN. 15P CARD CABLE CJP15GA115ZY
VIDEO D401 00MHZ21303210 00MHZ21303210 DIODE 1SS355 CVD1SS355T
VIDEO D402 00MHZ21303210 00MHZ21303210 DIODE 1SS355 CVD1SS355T
VIDEO D403 00MHZ21303210 00MHZ21303210 DIODE 1SS355 CVD1SS355T
VIDEO D404 00MHZ21303210 00MHZ21303210 DIODE 1SS355 CVD1SS355T
VIDEO D407 00MHZ21303210 00MHZ21303210 DIODE 1SS355 CVD1SS355T
VIDEO D408 ns
p
90M-HD201750R DIODE 1N4003 CVD1N4003SRT
VIDEO IC41 90M-HC110080R 90M-HC110080R IC AN15881AV CVIAN15881AVT
VIDEO IC42 90M-HC400090R 90M-HC400090R IC M74HC4051RM13TR/SOP CVIM74HC4051RM13TR
VIDEO IC44 00MHC10224090 00MHC10224090 IC NJM2535M CVINJM2535MTE1
VIDEO IC45 00MHC10077090 00MHC10077090 IC NJM2264M CVINJM2264MTE1
VIDEO IC46 90M-HC109820R 90M-HC109820R IC NJM2244M HVINJM2244MTE1
VIDEO IC47
/
N1B 90M-HC109810R 90M-HC109810R IC LC74781M9017 HVILC74781M9017
VIDEO IC47
/
N1S 90M-HC109810R 90M-HC109810R IC LC74781M9017 HVILC74781M9017
VIDEO IC47
/
U1B ns
p
90M-HC109860R IC LC74782M8A13 CVILC74782M8A13
VIDEO IC48 90M-HC109820R 90M-HC109820R IC NJM2244M HVINJM2244MTE1
VIDEO IC49 00MHC3890599F 00MHC3890599F IC KIA7805API HVIKIA7805API
VIDEO IC54 90M-HC400060R 90M-HC400060R IC TC74HC4094AFN HVITC74HC4094FN
VIDEO IC71 00MHC10472050 00MHC10472050 IC TC90A49PG CVITC90A49PG
VIDEO IC72 90M-HC108830R 90M-HC108830R IC NJM2285M HVINJM2285MTE1
VIDEO IC73 90M-HC108850R 90M-HC108850R IC R59-4174 HVIMM1511XNRE
VIDEO IC74 90M-HC108810R 90M-HC108810R IC TA1270BF HVITA1270BF
VIDEO IC75 00MHC3890999F 00MHC3890999F IC KIA7809API HVIKIA7809API
VIDEO JK41 90M-YT005400R 90M-YT005400R TERMINAL S-VIDEO CVBS JACK CJJ9P003Z
VIDEO JK42 90M-YT005400R 90M-YT005400R TERMINAL S-VIDEO CVBS JACK CJJ9P003Z
VIDEO JK43 90M-YT005400R 90M-YT005400R TERMINAL S-VIDEO CVBS JACK CJJ9P003Z
VIDEO JK47 90M-YT004300R 90M-YT004300R TERMINAL JACK BOARD 6P G/B/R SILVER CJJ4R045Z
VIDEO JK48 90M-YT004300R 90M-YT004300R TERMINAL JACK BOARD 6P G/B/R SILVER CJJ4R045Z
VIDEO L401 00MLC13330140 00MLC13330140 COIL 33UH HLQ02C330KT
VIDEO L701 ns
p
ns
p
COIL 22UH,K HLQ02C220KT
VIDEO L702 ns
p
ns
p
COIL 10UH,K HLQ02C100KT
VIDEO L703 ns
p
ns
p
COIL 10UH,K HLQ02C100KT
VIDEO L704 ns
p
ns
p
COIL 10UH,K HLQ02C100KT
VIDEO L705 ns
p
ns
p
COIL 10UH,K HLQ02C100KT
VIDEO L706 ns
p
ns
p
COIL 22UH,K HLQ02C220KT
VIDEO L707 ns
p
ns
p
COIL 22UH,K HLQ02C220KT
VIDEO Q401 90M-HT600050R 90M-HT600050R TRS. KTA2014GR HVTKTA2014GR
VIDEO Q402 90M-HX600010R 90M-HX600010R CHIP TRS. KRA102S HVTKRA102S
VIDEO Q403 90M-HT800110R 90M-HT800110R TRS. KTC4075GR HVTKTC4075GR
VIDEO Q404 90M-HT800110R 90M-HT800110R TRS. KTC4075GR HVTKTC4075GR
VIDEO Q405
/
N1B 90M-HX800090R 90M-HX800090R CHIP TRS. KRC111S HVTKRC111S
