Marantz SR5002N1B - Page 120

142
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.W.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
XM BK51
/
U1B ns
p
ns
p
BRACKET BRACKET FOR PWB CMD1A569
XM BK52
/
U1B ns
p
ns
p
BRACKET BRACKET FOR PWB CMD1A569
XM BN96
/
U1B ns
p
ns
p
CORD WIRE ASSY CWB1C903150EN
XM C490
/
U1B ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
XM C501
/
U1B ns
p
00MOA47602520 ELECT CAP. 47UF 25V CCEA1EH470T
XM C502
/
U1B ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
XM C503
/
U1B ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
XM C504
/
U1B ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
XM C505
/
U1B ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
XM C506
/
U1B ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
XM C507
/
U1B ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
XM C508
/
U1B ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
XM C509
/
U1B ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
XM C510
/
U1B ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
XM C511
/
U1B ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
XM C512
/
U1B ns
p
00MDD95181300 CER. CAP. 180PF 50V J CCUS1H181JA
XM C514
/
U1B ns
p
00MDD95220300 CER. CAP. 22PF 50V JA CCUS1H220JA
XM C515
/
U1B ns
p
00MDD95220300 CER. CAP. 22PF 50V JA CCUS1H220JA
XM C517
/
U1B ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
XM C518
/
U1B ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
XM C519
/
U1B ns
p
00MDK96102300 CER. CAP. 1000PF 50V KC CCUS1H102KC
XM C520
/
U1B ns
p
00MDK96102300 CER. CAP. 1000PF 50V KC CCUS1H102KC
XM C521
/
U1B ns
p
00MDK96102300 CER. CAP. 1000PF 50V KC CCUS1H102KC
XM C522
/
U1B ns
p
00MDK96102300 CER. CAP. 1000PF 50V KC CCUS1H102KC
XM C523
/
U1B ns
p
00MDD95220300 CER. CAP. 22PF 50V JA CCUS1H220JA
XM C524
/
U1B ns
p
00MDD95220300 CER. CAP. 22PF 50V JA CCUS1H220JA
XM C601
/
U1B ns
p
00MDK96102300 CER. CAP. 1000PF 50V KC CCUS1H102KC
XM C602
/
U1B ns
p
00MDK96821300 CER. CAP. 820PF 50V J CCUS1H821JA
XM C604
/
U1B ns
p
00MDK96122300 CER. CAP. 1200PF 50V KC CCUS1H122KC
XM C606
/
U1B ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
XM C607
/
U1B ns
p
00MOA47701020 ELECT CAP. 470UF 10V CCEA1AH471T
XM C613
/
U1B ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
XM C614
/
U1B ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
XM C615
/
U1B ns
p
00MDK96821300 CER. CAP. 820PF 50V J CCUS1H821JA
XM C616
/
U1B ns
p
00MDK96122300 CER. CAP. 1200PF 50V KC CCUS1H122KC
XM C623
/
U1B ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
XM C624
/
U1B ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
XM C631
/
U1B ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
XM C632
/
U1B ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
XM C633
/
U1B ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
XM C634
/
U1B ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
XM C801
/
U1B ns
p
00MOA10701620 ELECT CAP. 100UF 16V CCEA1CH101T
XM C803
/
U1B ns
p
00MOA10701620 ELECT CAP. 100UF 16V CCEA1CH101T
XM C811
/
U1B ns
p
00MOA10701620 ELECT CAP. 100UF 16V CCEA1CH101T
XM C812
/
U1B ns
p
00MOA10701620 ELECT CAP. 100UF 16V CCEA1CH101T
XM C813
/
U1B ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
XM CN97
/
U1B ns
p
ns
p
CONN. 15P CARD CABLE CJP15GA115ZY
XM F801
/
U1B ns
p
90M-FC900340R FERRITE CORE HU-1H4516-600JT HLZ9Z014Z
XM F802
/
U1B ns
p
90M-FC900340R FERRITE CORE HU-1H4516-600JT HLZ9Z014Z
XM F803
/
U1B ns
p
90M-FC900460R EMI FILTER CHIP BEAD
(
EMC FILTER
)
CLZ9R007Z
XM F811
/
U1B ns
p
90M-FC900460R EMI FILTER CHIP BEAD
(
EMC FILTER
)
CLZ9R007Z
XM IC51
/
U1B ns
p
90M-HC110100R IC I.C XM V3B CVIXMDTIC
XM IC52
/
U1B ns
p
00MHC1004248Z IC AKM DAC AK4384VT CVIAK4384ET
XM IC62
/
U1B ns
p
00MHC10102090 IC NJM2068MD-TE1 HVINJM2068MDTE1
XM JK51
/
U1B ns
p
00D2051362009 TERMINAL CAM-D96 CJJ9L006Z
XM L501
/
U1B ns
p
00MFN21000080 EMI FILTER DLW21HN121SQ2L CLZ9R008Z
XM L502
/
U1B ns
p
90M-LU000280R CHIP INDUCT 2.7UH CLQ06E2R7KRZ
XM Q613
/
U1B ns
p
90M-HT300970R TRS. KTC2875B HVTKTC2875B
XM Q614
/
U1B ns
p
90M-HT300970R TRS. KTC2875B HVTKTC2875B
XM Q615
/
U1B ns
p
90M-HT300970R TRS. KTC2875B HVTKTC2875B
XM Q616
/
U1B ns
p
90M-HT300970R TRS. KTC2875B HVTKTC2875B
XM Q617
/
U1B ns
p
90M-BA001620R CHIP TRS. KRC103S CVTKRC103S
XM Q619
/
U1B ns
p
90M-BA001630R CHIP TRS. KRA103S HVTKRA103S
XM Q801
/
U1B ns
p
00MHC98520320 IC PQ20VZ51 CVIPQ20VZ51
XM Q811
/
U1B ns
p
90M-HC300940R IC LM1117-ADJ HVILM1117S-ADJ
XM R486
/
U1B ns
p
00MNN05103610 CHIP RES. 10K OHM 1/10W J CRJ10DJ103T
XM R501
/
U1B ns
p
00MNN05104610 CHIP RES. 100K OHM 1/10W J CRJ10DJ104T
