Marantz SR5002N1B - Page 82

104
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.W.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
HDMI R970 ns
p
00MNN05682610 CHIP RES. 6.8K OHM 1/10W J CRJ10DJ682T
HDMI R971 ns
p
00MNN05242610 CHIP RES. 2.4K OHM CRJ10DJ242T
HDMI R972 ns
p
00MNN05242610 CHIP RES. 2.4K OHM CRJ10DJ242T
HDMI R973 ns
p
00MNN05242610 CHIP RES. 2.4K OHM CRJ10DJ242T
HDMI R974 ns
p
00MNN05242610 CHIP RES. 2.4K OHM CRJ10DJ242T
HDMI R977 ns
p
00MNN05220610 CHIP RES. 22 OHM 1/10W J CRJ10DJ220T
HDMI R982 ns
p
00MNN05000610 CHIP RES. 0 OHM 1/10W J CRJ10DJ0R0T
HDMI R983 ns
p
00MNN05473610 CHIP RES. 47K OHM 1/10W J CRJ10DJ473T
HDMI RN91 90M-BW000400R 90M-BW000400R RES. COMPO. 22 OHM X4 2012 CRJ104DJ220T
HDMI RN93 90M-BW000400R 90M-BW000400R RES. COMPO. 22 OHM X4 2012 CRJ104DJ220T
HDMI RN94 90M-BW000400R 90M-BW000400R RES. COMPO. 22 OHM X4 2012 CRJ104DJ220T
HDMI RN95 90M-BW000400R 90M-BW000400R RES. COMPO. 22 OHM X4 2012 CRJ104DJ220T
HDMI RN96 90M-BW000400R 90M-BW000400R RES. COMPO. 22 OHM X4 2012 CRJ104DJ220T
HDMI RN97 90M-BW000400R 90M-BW000400R RES. COMPO. 22 OHM X4 2012 CRJ104DJ220T
HDMI RN98 90M-BW000400R 90M-BW000400R RES. COMPO. 22 OHM X4 2012 CRJ104DJ220T
HDMI RN99 90M-BW000400R 90M-BW000400R RES. COMPO. 22 OHM X4 2012 CRJ104DJ220T
HDMI X901 90M-JX001330R 90M-JX001330R X'TAL 27MHZ COX27000E180TF
INPUT PWB
(
CUP11995Z
)
INPUT BK31 ns
p
ns
p
HEATSINK HEAT SINK IC CMY1A289
INPUT BN24 ns
p
ns
p
CORD WIRE ASSY CWB1C905150EN
INPUT BN44 ns
p
ns
p
CORD WIRE ASSY CWB1C905180EN
INPUT C101 ns
p
00MOA47602520 ELECT CAP. 47UF 25V CCEA1EH470T
INPUT C102 ns
p
00MDK96103300 CER. CAP. 0.01UF 50V KC CCUS1H103KC
INPUT C103 ns
p
00MOA47602520 ELECT CAP. 47UF 25V CCEA1EH470T
INPUT C104 ns
p
00MDK96103300 CER. CAP. 0.01UF 50V KC CCUS1H103KC
INPUT C105 ns
p
00MOA22605020 ELECT CAP. 22UF 50V CCEA1HH220T
INPUT C106 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
INPUT C107 ns
p
00MDD95101300 CER. CAP. 100PF 50V JA CCUS1H101JA
INPUT C108 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
INPUT C109 ns
p
00MDD95101300 CER. CAP. 100PF 50V JA CCUS1H101JA
INPUT C110 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
INPUT C112 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
INPUT C116 ns
p
00MDD95330300 CER. CAP. 33PF 50V JA CCUS1H330JA
INPUT C117 ns
p
00MDK96103300 CER. CAP. 0.01UF 50V KC CCUS1H103KC
INPUT C118 ns
p
00MOA47602520 ELECT CAP. 47UF 25V CCEA1EH470T
INPUT C119 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
INPUT C121 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
INPUT C122 ns
p
00MOA22605020 ELECT CAP. 22UF 50V CCEA1HH220T
INPUT C123 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
INPUT C124 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
INPUT C125 ns
p
00MDK98223300 CER. CAP. 0.022UF 50V KC CCUS1H223KC
INPUT C126 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
INPUT C127 ns
p
00MOA22605020 ELECT CAP. 22UF 50V CCEA1HH220T
INPUT C128 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
INPUT C129 ns
p
00MOA22605020 ELECT CAP. 22UF 50V CCEA1HH220T
INPUT C130 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
INPUT C131 ns
p
00MOA22605020 ELECT CAP. 22UF 50V CCEA1HH220T
INPUT C132 ns
p
00MDD95390300 CER. CAP. 39PF 50V JA CCUS1H390JA
INPUT C133 ns
p
00MDD95390300 CER. CAP. 39PF 50V JA CCUS1H390JA
INPUT C134 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
INPUT C135 ns
p
00MDD95101300 CER. CAP. 100PF 50V JA CCUS1H101JA
INPUT C136 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
INPUT C137 ns
p
00MOA22605020 ELECT CAP. 22UF 50V CCEA1HH220T
INPUT C138 ns
p
00MOA22605020 ELECT CAP. 22UF 50V CCEA1HH220T
INPUT C141 ns
p
00MDD95101300 CER. CAP. 100PF 50V JA CCUS1H101JA
INPUT C142 ns
p
00MDD95151300 CER. CAP. 150PF 50V JA CCUS1H151JA
INPUT C143 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
INPUT C144 ns
p
00MDK96272300 CER. CAP. 2700PF 50V KC CCUS1H272KC
INPUT C145 ns
p
00MOA22605020 ELECT CAP. 22UF 50V CCEA1HH220T
INPUT C148 ns
p
00MDD95101300 CER. CAP. 100PF 50V JA CCUS1H101JA
INPUT C149 ns
p
00MDD95151300 CER. CAP. 150PF 50V JA CCUS1H151JA
INPUT C150 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
INPUT C151 ns
p
00MDK96272300 CER. CAP. 2700PF 50V KC CCUS1H272KC
INPUT C152 ns
p
00MOA10701620 ELECT CAP. 100UF 16V CCEA1CH101T
INPUT C153 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
INPUT C154 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
INPUT C157 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
