Marantz SR5002N1B - Page 97

119
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.W.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
IR FLASH BN54 ns
p
ns
p
CORD WIRE ASSY CWB2B905250EN
IR FLASH C950 ns
p
ns
p
CER. CAP. 0.01UF 50V Z HCBS1H103ZFT
IR FLASH C951 ns
p
ns
p
CER. CAP. 0.01UF 50V Z HCBS1H103ZFT
IR FLASH C952 ns
p
ns
p
CER. CAP. 33PF 50V J HCBS1H330JT
IR FLASH C953 ns
p
ns
p
CER. CAP. 0.1UF 50V Z HCBS1H104ZFT
IR FLASH C954 ns
p
00MOA47602520 ELECT CAP. 47UF 25V CCEA1EH470T
IR FLASH C955 ns
p
ns
p
CER. CAP. 0.1UF 50V Z HCBS1H104ZFT
IR FLASH D805 90M-HI200020R 90M-HI200020R L.E.D. SIR-34ST3F BVDSIR34ST3F
IR FLASH D806 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
IR FLASH D807 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
IR FLASH D808 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
IR FLASH IC16 90M-HW100690R 90M-HW100690R PHOTO UNIT RPM674CBR-S CRVRPM6936
IR FLASH J956 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
IR FLASH J957 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
IR FLASH J958 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
IR FLASH J959 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
IR FLASH JK87 90M-YT003120R 90M-YT003120R TERMINAL CINCH 2P
(
GOLD
)
REMOTE CJJ4N036Z
IR FLASH JK88 90M-YT004860R 90M-YT004860R TERMINAL 3.5MM JACK STEREO CJJ2D008Z
IR FLASH JK89 90M-YT004860R 90M-YT004860R TERMINAL 3.5MM JACK STEREO CJJ2D008Z
IR FLASH R971 ns
p
ns
p
RES. 200 OHM 1/5 W CRD20TJ201T
IR FLASH R972 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101T
IR FLASH R973 ns
p
ns
p
RES. 200 OHM 1/5 W CRD20TJ201T
IR FLASH R974 ns
p
ns
p
RES. 47 OHM 1/5W J CRD20TJ470T
MAIN PWB
(
CUP11999Z
)
MAIN BN20 ns
p
ns
p
CORD WIRE ASSY CWB3FB03280UP
MAIN BN22 ns
p
ns
p
CORD WIRE ASSY CWZSR4001BN22
MAIN BN81 ns
p
ns
p
CORD WIRE ASSY CWB1C902050EN
MAIN BN87 ns
p
ns
p
CORD WIRE ASSY CWZSR4001BN87
MAIN BN90
/
N1B ns
p
ns
p
CORD WIRE ASSY CWB4F232550PU
MAIN BN90
/
N1S ns
p
ns
p
CORD WIRE ASSY CWB4F232550PU
MAIN BN93 ns
p
ns
p
CORD WIRE ASSY CWB1C903250EN
MAIN C501 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
MAIN C502 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
MAIN C503 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
MAIN C504 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
MAIN C505 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
MAIN C506 ns
p
ns
p
CER. CAP. 330PF 50V KB CCKT1H331KB
MAIN C507 ns
p
ns
p
CER. CAP. 330PF 50V KB CCKT1H331KB
MAIN C508 ns
p
ns
p
CER. CAP. 330PF 50V KB CCKT1H331KB
MAIN C509 ns
p
ns
p
CER. CAP. 330PF 50V KB CCKT1H331KB
MAIN C510 ns
p
ns
p
CER. CAP. 330PF 50V KB CCKT1H331KB
MAIN C561 ns
p
00MOA47602520 ELECT CAP. 47UF 25V CCEA1EH470T
MAIN C562 ns
p
00MOA47602520 ELECT CAP. 47UF 25V CCEA1EH470T
MAIN C563 ns
p
00MOA47602520 ELECT CAP. 47UF 25V CCEA1EH470T
MAIN C564 ns
p
00MOA47602520 ELECT CAP. 47UF 25V CCEA1EH470T
MAIN C565 ns
p
00MOA47602520 ELECT CAP. 47UF 25V CCEA1EH470T
MAIN C566 ns
p
00MOA10701620 ELECT CAP. 100UF 16V CCEA1CH101T
MAIN C569 ns
p
00MOA10701620 ELECT CAP. 100UF 16V CCEA1CH101T
MAIN C570 ns
p
00MOA10701620 ELECT CAP. 100UF 16V CCEA1CH101T
MAIN C571 ns
p
ns
p
CER. CAP. 100PF 50V KB CCKT1H101KB
MAIN C572 ns
p
ns
p
CER. CAP. 100PF 50V KB CCKT1H101KB
MAIN C573 ns
p
ns
p
CER. CAP. 100PF 50V KB CCKT1H101KB
MAIN C574 ns
p
ns
p
CER. CAP. 100PF 50V KB CCKT1H101KB
MAIN C575 ns
p
ns
p
CER. CAP. 100PF 50V KB CCKT1H101KB
MAIN C576 ns
p
ns
p
FILM CAP. 0.047UF 100V J HCQI1H473JZT
MAIN C578 ns
p
ns
p
FILM CAP. 5600PF 100V J HCQI1H562JZT
MAIN C579 ns
p
ns
p
FILM CAP. 5600PF 100V J HCQI1H562JZT
MAIN C580 ns
p
ns
p
FILM CAP. 220PF 50V KB CCKT1H221KB
MAIN C581 ns
p
ns
p
FILM CAP. 220PF 50V KB CCKT1H221KB
MAIN C582 ns
p
ns
p
FILM CAP. 220PF 50V KB CCKT1H221KB
MAIN C583 ns
p
ns
p
FILM CAP. 220PF 50V KB CCKT1H221KB
MAIN C584 ns
p
ns
p
FILM CAP. 220PF 50V KB CCKT1H221KB
MAIN C585 ns
p
ns
p
FILM CAP. 220PF 50V KB CCKT1H221KB
MAIN C586 ns
p
ns
p
FILM CAP. 220PF 50V KB CCKT1H221KB
MAIN C587 ns
p
ns
p
FILM CAP. 220PF 50V KB CCKT1H221KB
MAIN C601 ns
p
ns
p
CER. CAP. 12PF 50V JC CCCT1H120JC
MAIN C602 ns
p
ns
p
CER. CAP. 12PF 50V JC CCCT1H120JC
