Example connections when using surround Dolby Atmos Enabled speakers
This 7.1-channel surround system is the same as a basic 5.1-channel system but with surround Dolby Atmos Enabled speakers.
.
C
FL FR
SW
SL SR
SDL SDR
0
Set “Assign Mode” to “Surround Dolby” in the menu. (v p. 186)
.
SW
FLFR C SR SL
SDR SDL
