Marantz SR6005/N1SG - Page 9

9
(2) Disconnect the connector wires then remove the screws.
(3) Disconnect the connector wires and FFC cable.
Direction of photograph: D
Direction of photograph: C
STYLEPIN : Loose
CP308
FFC cable N4401
cut
Please refer to "EXPLODED VIEW" for the disassembly method of each PCB included in FRONT PANEL ASSY.
