Marantz SR6200 N2B - Sr6200

47 48
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
1 9965 000 10950 WINDOW-FL 322W158020
2
GOLD 9965 000 10608 KNOB AL VOL. / SURR.(GOLD) 313W154510
2
BLACK 9965 000 09311 KNOB AL VOL. / SURR.(BLACK) 313W154500
3
4822 454 13406 BADGE MARANTZ 185J251010
4
K, / NxG 9965 000 10918 PANEL FRONT AL(GOLD) 321W248120
4 /
NxB 9965 000 10917 PANEL FRONT AL(BLACK) 321W248020
4
U nsp PANEL FRONT AL(BLACK) 321W248010
5
9965 000 10951 INDICATOR POWER ON/OFF 322W355010
6
GOLD 9965 000 11029 DECORATION CAP FRONT
(GOLD)
322W053110
6
BLACK 9965 000 10952 DECORATION CAP FRONT
(BLACK)
322W053010
7
9965 000 10953 FILTER COVER LED
/NIGHT/ATT etc.
322W303010
8
K nsp BODY-FRONT FRONT PANEL
(GOLD)
nsp
8
N nsp BODY-FRONT FRONT PANEL
(BLACK)
nsp
9
GOLD 9965 000 11030 BUTTON MUTE (GOLD) 322W270140
9
BLACK 9965 000 10954 BUTTON MUTE (BLACK) 322W270040
10
GOLD 9965 000 11031 BUTTON CLEAR/MEMORY etc.
(GOLD)
322W270130
10
BLACK 9965 000 10955 BUTTON CLEAR/MEMORY etc.
(BLACK)
322W270030
11
GOLD 9965 000 11032 BUTTON TUNING/PRESET
(GOLD)
322W270120
11
BLACK 9965 000 10956 BUTTON TUNING/PRESET
(BLACK)
322W270020
12
GOLD 9965 000 11033 BUTTON DIMMER/SLEEP etc.
(GOLD)
322W270150
12
BLACK 9965 000 10957 BUTTON DIMMER/SLEEP etc.
(BLACK)
322W270050
13
GOLD 9965 000 11034 BUTTON TV/DVD etc. (GOLD) 322W270160
13
BLACK 9965 000 10958 BUTTON TV/DVD etc. (BLACK) 322W270060
14
GOLD 9965 000 11035 BUTTON POWER (GOLD) 322W270110
14
BLACK 9965 000 10959 BUTTON POWER (BLACK) 322W270010
15
U nsp P.C.B BY LED ASSY nsp
15
K,N nsp P.C.B BY LED ASSY nsp
16
U nsp P.C.B SUB ASSY POWER SW nsp
16
K,N nsp P.C.B SUB ASSY POWER SW nsp
17
K,N 9965 000 10960 SW PUSH / SDDL-005-S *SP001160R
18
K,N nsp BRACKET POWER SW nsp
19
nsp P.C.B SUB ASSY HEADPHONE nsp
20
9965 000 10961 HEAD PHONE JACK *YT002550R
21
nsp P.C.B SUB ASSY M-CONTROL nsp
22
9965 000 10605 SW ENCODER
EC16B12S00D4-ZZZ
*SR000190R
23
nsp P.C.B SUB ASSY FRONT nsp
24
9965 000 10962 CINCH JACK TER RCA 3PIN *YT000870R
25
9965 000 10963 JACK D6.5 C40160250N *YT002530R
26
9965 000 10964 SW ENCODER
EC16B24T01D4-ZZZ
*SR000200R
27
4822 130 11515 SENSOR REMOTE
RPM6936-H4
*HW100530R
28
ns HOLDER FL-TUBE nsp
29
9965 000 10965 DISPLAY FL-TUBE /
HNA-15MM19 59P
*HQ300510R
30
nsp P.C.B SUB ASSY AMP nsp
31
nsp BRACKET HEAT SINK nsp
32
nsp HEAT SINK AMP nsp
33
ns CHASSIS ASSY
R956(A)CH-MAIN+BKT-PCB
nsp
34
9965 000 10966 FOOT HOT STAMPING 322W057010
35
nsp P.C.B SUB ASSY GUIDE (L) nsp
36
nsp P.C.B SUB ASSY GUIDE (R) nsp
37
nsp SPACER MAIN PCB SUPPORT nsp
38
U nsp MAIN P.C.B SUB ASSY nsp
38
N nsp MAIN P.C.B SUB ASSY nsp
38
K nsp MAIN P.C.B SUB ASSY nsp
39
nsp HEAT SINK ALL R925
ANODIZING=NO/REG TR
nsp
40
nsp HEAT SINK AVC1500(N) AL
46(W)X70(H) /REG TR
nsp
41
GOLD nsp TOP COVER (GOLD) nsp
41
BLACK nsp TOP COVER (BLACK) nsp
42
ns CUSHION-BUFFER nsp
43
U ns TUNER FM/AM
KST-M9014MA0-3
*AV000180R
43
K ns TUNER FM/MW
KST-M9014MA1-3
*AV000190R
43
N 9965 000 10967 TUNER AM/LW/MW
KST-M9014LA1-3
*AV000170R
44
nsp P.C.B-VOL. SUB ASSY nsp
45
9965 000 10968 CINCH JACK JK0400450N TER
RCA 4PIN
*YT001600R
45
9965 000 10968 CINCH JACK JK0400450N TER
RCA 4PIN
*YT001600R
46
9965 000 10969 CINCH JACK JK060046EN TER
RCA 6PIN
*YT002650R
47
nsp P.C.B-DSP SUB ASSY
(SR5200 / SR6200)
nsp
48
9965 000 10970 CINCH JACK JC030012ZN TER
RCA 3PIN
*YT002620R
49
9965 000 10971 MODULE
GP1FA502RZ /OPTICAL RX
*YT002570R
49
9965 000 10971 MODULE
GP1FA502RZ /OPTICAL RX
*YT002570R
50
9965 000 10972 MODULE
GP1FA502TZ /OPTICAL TX
*YT002580R
51
U nsp P.C.B-INPUT2 SUB ASSY nsp
51
K,N nsp P.C.B-INPUT2 SUB ASSY nsp
52
9965 000 10973 CINCH JACK JK060046CN TER
RCA 6PIN
*YT002640R
53
9965 000 10974 CINCH JACK JK020044HN TER
RCA 2PIN
*YT002600R
54
U nsp P.C.B-INPUT1 SUB ASSY nsp
54
K,N nsp P.C.B-INPUT1 SUB ASSY nsp
55
9965 000 10968 CINCH JACK JK0400450N TER
RCA 4PIN
*YT001600R
56
9965 000 10973 CINCH JACK JK060046CN TER
RCA 6PIN
*YT002640R
57
nsp P.C.B-VIDEO SUB ASSY
V-COMPOSITE
nsp
58
9965 000 10975 CINCH JACK JC030012FN TER
RCA 3PIN
*YT002630R
59
9965 000 10976 CINCH JACK JC0200095N TER
RCA 2PIN
*YT002610R
60
U nsp P.C.B-S VIDEO SUB ASSY
S-VIDEO
nsp
60
K,N nsp P.C.B-S VIDEO SUB ASSY
S-VIDEO
nsp
61
9965 000 10977 JACK D6.5 ALL R945
YKF51-5516/S-VHS 2P
*YT002540R
62
9965 000 10978 JACK DIN AVP9080 DOM
YKF51-5512 3P
*YT002560R
63
U nsp P.C.B-SPKR SUB ASSY nsp
63
N nsp P.C.B-SPKR SUB ASSY nsp
64
9965 000 10979 SPEAKER TERMINAL
SH0810360P
TER BOARD SCREW 8P
*YT001290R
65
9965 000 10980 SPEAKER TERMINAL
SH0410370P
TER BOARD SCREW 4P
*YT002590R
66
N nsp BUSHING SPKR TERMINAL nsp
p
p
p
p
p
67
U nsp P.C.B SUB ASSY POWER nsp
67
N nsp P.C.B SUB ASSY POWER nsp
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
67
K nsp P.C.B SUB ASSY POWER nsp
68 U nsp SOCKET AC OUTLET
CCT1304-0212
*YT000910R
68 N 9965 000 10981 SOCKET AC OUTLET
YKE31-0090
*YT000920R
69 K nsp MAINS TRANSF. FOR K *TS001580R
69 N 9965 000 11059 MAINS TRANSF. FOR N *TS001570R
69 U nsp MAINS TRANSF. FOR U *TS001560R
70 K nsp CHASSIS REAR PANEL nsp
70 N nsp CHASSIS REAR PANEL nsp
70 U nsp CHASSIS REAR PANEL nsp
71
nsp STOPPER CORD HOLDER 323W259030
72 K nsp MAINS CORD KP-10MM
RVVBWITH CORE
*ZC000140R
72 N 9965 000 10983 MAINS CORD
6A/250V 2M+CORE D
*ZC000160R
72 U ns MAINS CORD
SPT2 10A/125V +CORE
*ZC000150R
S1
nsp SCREW TAP TITE
+2S 3*8 B-TYPE ZNY/BH
nsp
S1
nsp SCREW TAP TITE
+2S 3*8 B-TYPE ZNY/BH
nsp
S2
nsp SCREW TAP TITE
+2S 3*8 B-TYPE BK/FH
nsp
S3
nsp SCREW TAP TITE
3X18 B-TYPE ZNY/BH
nsp
S4
nsp SCREW TAP TITE ASSY
+3S4*10P+S-WASHER ZNY/BH
nsp
S5
nsp SCREW TAP TITE
+2S 4*8 B-TYPE Bsbm/BH
nsp
S6
nsp SCREW +2S 3*16 P
+S-WASHER ZNY/HH
nsp
S7
nsp SCREW TAP TITE +2S 3*10
B-TYPE(DOT)BH Bsbm
nsp
PACKING
001T K nsp USER GUIDE FOR SR6200 321W851350
001T N 9965 000 11060 USER GUIDE FOR SR6200 321W851310
001T U nsp USER GUIDE FOR SR6200 321W851250
001Z
SR6200 9965 000 11061 REMOTE CONTROLLER
(RC6200SR)
ZK321W0010
-
nsp ANTENNA AM LOOP nsp
-
nsp ANT WIRE DIPOLE nsp
-
nsp BATTERY DRY
R03NE(1.5V)-AAA
nsp
-
K nsp AC PLUG ADAPTER nsp
NOT STANDARD SPARE
PARTS
-
N ns CARD Important nsp
-
N nsp Surround Addendum Sheet nsp
-
U ns CARD Warranty(USA) nsp
-
U ns CARD Warranty(CANADA) nsp
-
U nsp Surround Addendum Sheet nsp
-
SR6200 ns PACKING CASE
SR6200(Marantz)
nsp
-
ns CUSHION nsp
-
nsp PE SHEET FOR SET nsp
p
p
p
p
p
p
SR6200
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS. NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
