RS232C Control Spec. Page: 9 / 17
SR7400/8400 Document Version [1.00]
MENU OFF ZA "@1ZA",0x0D
MENU
MENU (OK) ZB "@1ZB",0x0D
CURSOL UP ZC "@1ZC",0x0D
CURSOL DOWN ZD "@1ZD",0x0D
CURSOL LEFT ZE "@1ZE",0x0D
CURSOL
CURSOL RIGHT ZF "@1ZF",0x0D
FREQ. UP PB "@1PB",0x0D
FREQ. DOWN PC "@1PC",0x0D
AUTO UP START/STOP PD "@1PD",0x0D
TUNER FREQUENCY
AUTO DOWN START/STOP PE "@1PE",0x0D
PRESET INFO. QA "@1QA",0x0D
P-SCAN QB "@1QB",0x0D
PRESET UP QC "@1QC",0x0D
TUNER PRESET
PRESET DOWN QD "@1QD",0x0D
F-DIRECT OFF RA "@1RA",0x0D
F-DIRECT
F-DIRECT ON RB "@1RB",0x0D
STEREO RC "@1RC",0x0D
TUNER MODE
MONO RD "@1RD",0x0D
CLR RE "@1RE",0x0D
MEMO/CLR
MEMO RF "@1RF",0x0D
DIRECT KEY 0 SA "@1SA",0x0D
DIRECT KEY 1 SB "@1SB",0X0D
DIRECT KEY 2 SC "@1SC",0x0D
DIRECT KEY 3 SD "@1SD",0x0D
DIRECT KEY 4 SE "@1SE",0x0D
DIRECT KEY 5 SF "@1SF",0x0D
DIRECT KEY 6 SG "@1SG",0x0D
DIRECT KEY 7 SH "@1SH”,0x0D
DIRECT KEY 8 SI "@1SI",0x0D
DIRECT KEY
DIRECT KEY 9 SJ "@1SJ",0x0D
RDS DISP MODE TA "@1TA",0x0D
RDS
RDS PTY TB "@1TB",0x0D
AUTO U0 "@1U0",0x0D
DOLBY U6 "@1U6",0x0D
DD+PLⅡx MOVIE
U7 "@1U7”,0x0D
DD+PLⅡx MUSIC
U8 "@1U8”,0x0D
AAC+PLⅡx MOVIE
U9 "@1U9”,0x0D
AAC+PLⅡx MUSIC
UA "@1UA”,0x0D
DOLBY PLⅡx MOVIE
UB "@1UB”,0x0D
DOLBY PLⅡx MUSIC
UC "@1UC”,0x0D
DOLBY PLⅡx GAME
UD "@1UD”,0x0D
DOLBY PLⅡ MOVIE
UE "@1UE”,0x0D
DOLBY PLⅡ MUSIC
UF "@1UF”,0x0D
DOLBY PLⅡ GAME
UG "@1UG”,0x0D
DOLBY PROLOGIC UH "@1UH",0x0D
EX/ES UI "@1UI",0x0D
VIRTUAL6.1 UJ "@1UJ",0x0D
DOLBY DIGITAL EX UK "@1UK",0x0D
DTS ES UL "@1UL",0x0D
NEO6 CINEMA UO "@1UO",0x0D
NEO6 MUSIC UP "@1UP",0x0D
Mch-STEREO UQ "@1UQ",0x0D
CSⅡ CINEMA
UR "@1UR",0x0D
CSⅡ MUSIC
US "@1US",0x0D
CSⅡ MONO
UT "@1UT",0x0D
SURROUND MODE
VIRTUAL Uc "@1Uc",0x0D
