Marantz SR7500/A1B - Page 113

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
136
SR7500 / PS7500
P.C.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
INPUT R273 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101
T
INPUT R274 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101
T
INPUT R275 ns
p
ns
p
RES. 220 KOHM 1/5W J CRD20TJ224
T
INPUT R276 ns
p
ns
p
RES. 220 KOHM 1/5W J CRD20TJ224
T
INPUT R277 ns
p
ns
p
RES. 220 KOHM 1/5W J CRD20TJ224
T
INPUT R278 ns
p
ns
p
RES. 220 KOHM 1/5W J CRD20TJ224
T
INPUT R279 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473
T
INPUT R280 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473
T
INPUT R281 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473
T
INPUT R282 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473
T
INPUT R283 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101
T
INPUT R314 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473
T
INPUT R315 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473
T
INPUT R316 ns
p
ns
p
CONN. CORD SN95/PB5 , 0.6 C3A206
INPUT R317 ns
p
ns
p
CONN. CORD SN95/PB5 , 0.6 C3A206
INPUT R318 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473
T
INPUT R319 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473
T
INPUT R320 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473
T
INPUT R321 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473
T
INPUT R324 ns
p
ns
p
CONN. CORD SN95/PB5 , 0.6 C3A206
INPUT R325 ns
p
ns
p
CONN. CORD SN95/PB5 , 0.6 C3A206
INPUT R326 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473
T
INPUT R327 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473
T
INPUT R328 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473
T
INPUT R329 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473
T
INPUT R330 ns
p
ns
p
CONN. CORD SN95/PB5 , 0.6 C3A206
INPUT R331 ns
p
ns
p
CONN. CORD SN95/PB5 , 0.6 C3A206
INPUT R332 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473
T
INPUT R333 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473
T
INPUT R334 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473
T
INPUT R335 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473
T
INPUT R338 ns
p
ns
p
CONN. CORD SN95/PB5 , 0.6 C3A206
INPUT R339 ns
p
ns
p
CONN. CORD SN95/PB5 , 0.6 C3A206
INPUT R340 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473
T
INPUT R341 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473
T
INPUT R342 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473
T
INPUT R343 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473
T
INPUT R344 ns
p
ns
p
CONN. CORD SN95/PB5 , 0.6 C3A206
INPUT R345 ns
p
ns
p
CONN. CORD SN95/PB5 , 0.6 C3A206
INPUT R346 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473
T
INPUT R347 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473
T
INPUT R372 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101
T
INPUT R373 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101
T
INPUT R402 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101
T
INPUT R403 ns
p
ns
p
RES. 100K OHM 1/5W J CRD20TJ104
T
INPUT R404 ns
p
ns
p
RES. 100K OHM 1/5W J CRD20TJ104
T
INPUT R405 ns
p
ns
p
RES. 100K OHM 1/5W J CRD20TJ104
T
INPUT R406 ns
p
ns
p
RES. 100K OHM 1/5W J CRD20TJ104
T
INPUT R441 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101
T
INPUT R442 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473
T
INPUT R444 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473
T
INPUT R446 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101
T
INPUT R447 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101
T
INPUT R448 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473
T
INPUT R449 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473
T
INPUT R513 ns
p
ns
p
CONN. CORD SN95/PB5 , 0.6 C3A206
INPUT R514 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103
T
INPUT R517 ns
p
ns
p
RES. 1K OHM 1/5W J CRD20TJ102
T
INPUT R518 ns
p
ns
p
RES. 1K OHM 1/5W J CRD20TJ102
T
INPUT R520 ns
p
ns
p
RES. 100K OHM 1/5W J CRD20TJ104
T
INPUT R521 ns
p
ns
p
RES. 100K OHM 1/5W J CRD20TJ104
T
INPUT R522 ns
p
ns
p
RES. 1K OHM 1/5W J CRD20TJ102
T
INPUT R523 ns
p
ns
p
RES. 2.4K OHM 1/5W J CRD20TJ242
T
INPUT R527 ns
p
ns
p
RES. 100K OHM 1/5W J CRD20TJ104
T
INPUT R529 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103
T
INPUT R530 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103
T
