NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
140
SR7500 / PS7500
P.C.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
POWER Q611 00MBA20001000 00MBA20001000 TRS. KRC102M HVTKRC102M
T
POWER Q612 90M-HT600040
R
90M-HT600040
R
TRS. HVTKTA1267YT
POWER Q613 90M-HT800050
R
90M-HT800050
R
TRS. HVTKTC3198YT
POWER Q614 90M-HT800050
R
90M-HT800050
R
TRS. HVTKTC3198YT
POWER Q615 90M-HT600040
R
90M-HT600040
R
TRS. HVTKTA1267YT
POWER Q616 00MBA20001000 00MBA20001000 TRS. KRC102M HVTKRC102M
T
POWER R601 ns
p
ns
p
RES. 390 OHM 1W J KRG1SANJ391R
T
POWER R602 ns
p
ns
p
RES. 470 OHM 1W J KRG1SANJ471R
T
POWER R603 ns
p
ns
p
RES. 390 OHM 1W J KRG1SANJ391R
T
POWER R604 ns
p
ns
p
RES. 470 OHM 1W J KRG1SANJ471R
T
POWER R605 ns
p
ns
p
RES. 390 OHM 1W J KRG1SANJ391R
T
POWER R606 ns
p
ns
p
RES. 470 OHM 1W J KRG1SANJ471R
T
POWER R607 ns
p
ns
p
RES. 390 OHM 1W J KRG1SANJ391R
T
POWER R608 ns
p
ns
p
RES. 470 OHM 1W J KRG1SANJ471R
T
POWER R609 ns
p
ns
p
RES. 390 OHM 1W J KRG1SANJ391R
T
POWER R610 ns
p
ns
p
RES. 470 OHM 1W J KRG1SANJ471R
T
POWER R611 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103
T
POWER R612 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103
T
POWER R613 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103
T
POWER R614 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103
T
POWER R615 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103
T
POWER R616 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103
T
POWER R617 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103
T
POWER R618 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103
T
POWER R619 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103
T
POWER R620 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103
T
POWER R622 ns
p
ns
p
RES. 10 OHM 1W J KRG1SANJ100R
T
POWER R623 ns
p
ns
p
RES. 10 OHM 1W J KRG1SANJ100R
T
POWER R624 ns
p
ns
p
RES. 10 OHM 1W J KRG1SANJ100R
T
POWER R625 ns
p
ns
p
RES. 10 OHM 1W J KRG1SANJ100R
T
POWER R626 ns
p
ns
p
RES. 10 OHM 1W J KRG1SANJ100R
T
POWER R627 ns
p
ns
p
RES. CRG1ANJ331H
POWER R628 ns
p
ns
p
RES. CRG1ANJ331H
POWER R631 ns
p
ns
p
RES. 270 OHM 1W J KRG1SANJ271R
T
POWER R632 ns
p
ns
p
RES. 270 OHM 1W J KRG1SANJ271R
T
POWER R633 ns
p
ns
p
RES. 15K OHM 1/5W J CRD20TJ153
T
POWER R634 ns
p
ns
p
RES. 15K OHM 1/5W J CRD20TJ153
T
POWER R635 ns
p
ns
p
RES. 15K OHM 1/5W J CRD20TJ153
T
POWER R636 ns
p
ns
p
RES. 15K OHM 1/5W J CRD20TJ153
T
POWER R637 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103
T
POWER R638 ns
p
ns
p
RES. 33K OHM 1/5W J CRD20TJ333
T
POWER R639 ns
p
ns
p
RES. 100K OHM 1/5W J CRD20TJ104
T
POWER R640 ns
p
ns
p
RES. CRG1ANJ1R0H
POWER R641 ns
p
ns
p
RES. CRG1ANJ1R0H
POWER R642 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103
T
POWER R643 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103
T
POWER R644 ns
p
ns
p
RES. 22K OHM 1/5W J CRD20TJ223
T
POWER R645 ns
p
ns
p
RES. 22K OHM 1/5W J CRD20TJ223
T
POWER R646 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103
T
POWER R647 ns
p
ns
p
RES. CRD25TJ1R0
T
POWER R648 ns
p
ns
p
RES. 2.2K OHM 1W J KRG1SANJ222R
T
POWER R649 ns
p
ns
p
RES. 1.5K OHM 1W J KRG1SANJ152R
T
POWER R650 ns
p
ns
p
RES. 100 OHM 1/4
W
CRD25TJ101
T
POWER R651 ns
p
ns
p
RES. 100 OHM 1/4
W
CRD25TJ101
T
POWER R652 ns
p
ns
p
CONN. CORD SN95/PB5 , 0.6 C3A206
POWER R653 90M-NH000150
R
90M-NH000150
R
FUSE RES. 0.15 OHM , 1W J KRQ1AJR15H
POWER RY61 00MLY2024049
0
00MLY2024049
0
RELAY 5GPA-28 DC2
4
HSL3B013ZE
POWER RY62 00MLY2024049
0
00MLY2024049
0
RELAY 5GPA-28 DC2
4
HSL3B013ZE
POWER RY63 00MLY2024049
0
00MLY2024049
0
RELAY 5GPA-28 DC2
4
HSL3B013ZE
POWER RY64 00MLY2024049
0
00MLY2024049
0
RELAY 5GPA-28 DC2
4
HSL3B013ZE
POWER RY65 00MLY2024051
0
00MLY2024051
0
RELAY OSA-SS-224DM
3
HSL4B017ZU
POWER RY66 00MLY2024052
0
00MLY2024052
0
RELAY PCLH-203D1SP HSL4B018ZU
PREOUT PCB
(
CUP11764-4
)
PREOUT BN22 ns
p
ns
p
CORD CWB1B915350EN
PREOUT C170 ns
p
ns
p
CER. CAP. 470PF 50V KB CCKT1H471KB
PREOUT C171 ns
p
ns
p
CER. CAP. 470PF 50V KB CCKT1H471KB
