SR8500 / PS8500
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
171
P.C.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
CONV. Q107 90M-HT600050
R
90M-HT600050
R
TRS. TRPNPB-R2 HVTKTA2014GR
CONV. Q108 90M-HT800110
R
90M-HT800110
R
TRS. TRNPNB HVTKTC4075GR
CONV. Q109 90M-HT600050
R
90M-HT600050
R
TRS. TRPNPB-R2 HVTKTA2014GR
CONV. Q110 90M-HT800110
R
90M-HT800110
R
TRS. TRNPNB HVTKTC4075GR
CONV. Q111 90M-HT600050
R
90M-HT600050
R
TRS. TRPNPB-R2 HVTKTA2014GR
CONV. Q112 90M-HT800110
R
90M-HT800110
R
TRS. TRNPNB HVTKTC4075GR
CONV. Q113 90M-HT600050
R
90M-HT600050
R
TRS. TRPNPB-R2 HVTKTA2014GR
CONV. Q114 90M-HT800110
R
90M-HT800110
R
TRS. TRNPNB HVTKTC4075GR
CONV. Q115 90M-HT600050
R
90M-HT600050
R
TRS. TRPNPB-R2 HVTKTA2014GR
CONV. Q116 90M-HT800110
R
90M-HT800110
R
TRS. TRNPNB HVTKTC4075GR
CONV. Q117 90M-HT600050
R
90M-HT600050
R
TRS. TRPNPB-R2 HVTKTA2014GR
CONV. Q118 90M-HX800010
R
90M-HX800010
R
CHIP TRS. KRC102S HVTKRC102S
CONV. Q119 90M-HX800010
R
90M-HX800010
R
CHIP TRS. KRC102S HVTKRC102S
CONV. Q120 90M-HT800110
R
90M-HT800110
R
TRS. TRNPNB HVTKTC4075GR
CONV. Q121 90M-HY200040
R
90M-HY200040
R
CHIP FET HN1K05FU HVTHN1K05FU
CONV. R100 ns
p
00MNN0510261
0
CHIP RES. 1KOHM/1608/5% CRJ10DJ102
T
CONV. R101 ns
p
00MNN0582061
0
CHIP RES. 820 OHM/1608/5% CRJ10DJ821
T
CONV. R102 ns
p
00MNN0510261
0
CHIP RES. 1KOHM/1608/5% CRJ10DJ102
T
CONV. R103 ns
p
00MNN0515261
0
CHIP RES. 1.5KOHM/1608/5% CRJ10DJ152
T
CONV. R104 ns
p
00MNN0510261
0
CHIP RES. 1KOHM/1608/5% CRJ10DJ102
T
CONV. R105 ns
p
00MNN0582061
0
CHIP RES. 820 OHM/1608/5% CRJ10DJ821
T
CONV. R106 ns
p
00MNN0510261
0
CHIP RES. 1KOHM/1608/5% CRJ10DJ102
T
CONV. R107 ns
p
00MNN0515261
0
CHIP RES. 1.5KOHM/1608/5% CRJ10DJ152
T
CONV. R108 ns
p
00MNN0510561
0
CHIP RES. 1MOHM/1608/5% CRJ10DJ105
T
CONV. R109 ns
p
00MNN0510561
0
CHIP RES. 1MOHM/1608/5% CRJ10DJ105
T
CONV. R110 ns
p
00MNN0510561
0
CHIP RES. 1MOHM/1608/5% CRJ10DJ105
T
CONV. R111 ns
p
00MNN0510561
0
CHIP RES. 1MOHM/1608/5% CRJ10DJ105
T
CONV. R112 ns
p
00MNN0522461
0
CHIP RES. 220KOHM/1608/5% CRJ10DJ224
T
CONV. R113 ns
p
00MNN0522261
0
CHIP RES. 2.2KOHM/1608/5% CRJ10DJ222
T
CONV. R114 ns
p
00MNN0510261
0
CHIP RES. 1KOHM/1608/5% CRJ10DJ102
T
CONV. R115 ns
p
00MNN0510261
0
CHIP RES. 1KOHM/1608/5% CRJ10DJ102
T
CONV. R116 ns
p
00MNN0522261
0
CHIP RES. 2.2KOHM/1608/5% CRJ10DJ222
T
CONV. R117 ns
p
00MNN0510161
0
CHIP RES. 100 OHM/1608/5% CRJ10DJ101
T
CONV. R118 ns
p
00MNN0510161
0
CHIP RES. 100 OHM/1608/5% CRJ10DJ101
T
CONV. R119 ns
p
00MNN0582061
0
CHIP RES. 820 OHM/1608/5% CRJ10DJ821
T
CONV. R120 ns
p
00MNN0512361
0
CHIP RES. 12KOHM/1608/5% CRJ10DJ123
T
CONV. R121 ns
p
00MNN0510361
0
CHIP RES. 10KOHM/1608/5% CRJ10DJ103
T
CONV. R122 ns
p
00MNN0547161
0
CHIP RES. 470 OHM/1608/5% CRJ10DJ471
T
CONV. R123 ns
p
00MNN0547161
0
CHIP RES. 470 OHM/1608/5% CRJ10DJ471
T
CONV. R124 ns
p
00MNN0547161
0
CHIP RES. 470 OHM/1608/5% CRJ10DJ471
T
CONV. R125 ns
p
00MNN0510361
0
CHIP RES. 10KOHM/1608/5% CRJ10DJ103
T
CONV. R126 ns
p
00MNN0510261
0
CHIP RES. 1KOHM/1608/5% CRJ10DJ102
T
CONV. R127 ns
p
00MNN0510261
0
CHIP RES. 1KOHM/1608/5% CRJ10DJ102
T
CONV. R128 ns
p
00MNN0547161
0
CHIP RES. 470 OHM/1608/5% CRJ10DJ471
T
CONV. R129 ns
p
00MNN0547161
0
CHIP RES. 470 OHM/1608/5% CRJ10DJ471
T
CONV. R130 ns
p
00MNN0547161
0
CHIP RES. 470 OHM/1608/5% CRJ10DJ471
T
CONV. R131 ns
p
00MNN0510361
0
CHIP RES. 10KOHM/1608/5% CRJ10DJ103
T
CONV. R132 ns
p
00MNN0512361
0
CHIP RES. 12KOHM/1608/5% CRJ10DJ123
T
CONV. R133 ns
p
00MNN0510361
0
CHIP RES. 10KOHM/1608/5% CRJ10DJ103
T
CONV. R134 ns
p
00MNN0547161
0
CHIP RES. 470 OHM/1608/5% CRJ10DJ471
T
CONV. R135 ns
p
00MNN0547161
0
CHIP RES. 470 OHM/1608/5% CRJ10DJ471
T
CONV. R136 ns
p
00MNN0547161
0
CHIP RES. 470 OHM/1608/5% CRJ10DJ471
T
CONV. R137 ns
p
00MNN0510361
0
CHIP RES. 10KOHM/1608/5% CRJ10DJ103
T
CONV. R138 ns
p
00MNN0510261
0
CHIP RES. 1KOHM/1608/5% CRJ10DJ102
T
CONV. R139 ns
p
00MNN0510261
0
CHIP RES. 1KOHM/1608/5% CRJ10DJ102
T
CONV. R140 ns
p
00MNN0547161
0
CHIP RES. 470 OHM/1608/5% CRJ10DJ471
T
CONV. R141 ns
p
00MNN0547161
0
CHIP RES. 470 OHM/1608/5% CRJ10DJ471
T
CONV. R142 ns
p
00MNN0547161
0
CHIP RES. 470 OHM/1608/5% CRJ10DJ471
T
CONV. R143 ns
p
00MNN0510361
0
CHIP RES. 10KOHM/1608/5% CRJ10DJ103
T
CONV. R144 ns
p
00MNN0533361
0
CHIP RES. 33KOHM/1608/5% CRJ10DJ333
T
CONV. R145 ns
p
00MNN0533261
0
CHIP RES. 3.3KOHM/1608/5% CRJ10DJ332
T
CONV. R146 ns
p
00MNN0533161
0
CHIP RES. 330 OHM/1608/5% CRJ10DJ331
T
CONV. R147 ns
p
00MNN0510161
0
CHIP RES. 100 OHM/1608/5% CRJ10DJ101
T
CONV. R148 ns
p
00MNN0510161
0
CHIP RES. 100 OHM/1608/5% CRJ10DJ101
T
CONV. R149 ns
p
00MNN0510161
0
CHIP RES. 100 OHM/1608/5% CRJ10DJ101
T
CONV. R150 ns
p
00MNN0510161
0
CHIP RES. 100 OHM/1608/5% CRJ10DJ101
T
