Marantz SR7500/A1B - Page 161

SR8500 / PS8500
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
184
P.C.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
DVI JK11 90M-YT004370R 90M-YT004370R TERMINAL YKF45-7017N HJJ9I001Z
DVI JK12 90M-YT004370R 90M-YT004370R TERMINAL YKF45-7017N HJJ9I001Z
DVI JK13 90M-YT004370R 90M-YT004370R TERMINAL YKF45-7017N HJJ9I001Z
DVI L101 90M-FC900370
R
90M-FC900370
R
FERRITE CORE HH-1M2012-221J
T
HLZ9R006Z
DVI L121 90M-FC900370
R
90M-FC900370
R
FERRITE CORE HH-1M2012-221J
T
HLZ9R006Z
DVI L181 90M-FC900370
R
90M-FC900370
R
FERRITE CORE HH-1M2012-221J
T
HLZ9R006Z
DVI L182 90M-FC900370
R
90M-FC900370
R
FERRITE CORE HH-1M2012-221J
T
HLZ9R006Z
DVI Q101 90M-HX600010
R
90M-HX600010
R
CHIP TRS. KRA102S HVTKRA102S
DVI Q102 90M-HX800010
R
90M-HX800010
R
CHIP TRS. KRC102S HVTKRC102S
DVI Q103 90M-HX600010
R
90M-HX600010
R
CHIP TRS. KRA102S HVTKRA102S
DVI Q104 90M-HX800010
R
90M-HX800010
R
CHIP TRS. KRC102S HVTKRC102S
DVI R101 ns
p
00MNN0500061
0
CHIP RES. 0 OHM/1608/5% CRJ10DJ0R0
T
DVI R102 ns
p
00MNN0510361
0
CHIP RES. 10KOHM/1608/5% CRJ10DJ103
T
DVI R103 ns
p
00MNN0510361
0
CHIP RES. 10KOHM/1608/5% CRJ10DJ103
T
DVI R104 ns
p
00MNN0510361
0
CHIP RES. 10KOHM/1608/5% CRJ10DJ103
T
DVI R105 ns
p
00MNN0500061
0
CHIP RES. 0 OHM/1608/5% CRJ10DJ0R0
T
DVI R106 ns
p
00MNN0539161
0
CHIP RES. 390 OHM/1608/5% CRJ10DJ391
T
DVI R107 ns
p
00MNN0510361
0
CHIP RES. 10KOHM/1608/5% CRJ10DJ103
T
DVI R108 ns
p
00MNN0510361
0
CHIP RES. 10KOHM/1608/5% CRJ10DJ103
T
DVI R121 ns
p
00MNN0500061
0
CHIP RES. 0 OHM/1608/5% CRJ10DJ0R0
T
DVI R122 ns
p
00MNN0510361
0
CHIP RES. 10KOHM/1608/5% CRJ10DJ103
T
DVI R123 ns
p
00MNN0510361
0
CHIP RES. 10KOHM/1608/5% CRJ10DJ103
T
DVI R124 ns
p
00MNN0510361
0
CHIP RES. 10KOHM/1608/5% CRJ10DJ103
T
DVI R125 ns
p
00MNN0500061
0
CHIP RES. 0 OHM/1608/5% CRJ10DJ0R0
T
DVI R126 ns
p
00MNN0539161
0
CHIP RES. 390 OHM/1608/5% CRJ10DJ391
T
DVI R127 ns
p
00MNN0510361
0
CHIP RES. 10KOHM/1608/5% CRJ10DJ103
T
DVI R128 ns
p
00MNN0510361
0
CHIP RES. 10KOHM/1608/5% CRJ10DJ103
T
DVI R181 ns
p
00MNN0510361
0
CHIP RES. 10KOHM/1608/5% CRJ10DJ103
T
DVI R182 ns
p
00MNN0500061
0
CHIP RES. 0 OHM/1608/5% CRJ10DJ0R0
T
DVI R183 ns
p
00MNN0551161
0
CHIP RES. 510 OHM/1608/5% CRJ10DJ511
T
DVI R184 ns
p
00MNN0510161
0
CHIP RES. 100 OHM/1608/5% CRJ10DJ101
T
DVI R185 ns
p
00MNN0510161
0
CHIP RES. 100 OHM/1608/5% CRJ10DJ101
T
DVI R191 ns
p
00MNN0510361
0
CHIP RES. 10KOHM/1608/5% CRJ10DJ103
T
DVI RN11 90M-BW000400
R
90M-BW000400
R
RES. COMPO. 22X4/2012 HRJ104DJ220
T
DVI RN12 90M-BW000400
R
90M-BW000400
R
RES. COMPO. 22X4/2012 HRJ104DJ220
T
DVI RN13 90M-BW000400
R
90M-BW000400
R
RES. COMPO. 22X4/2012 HRJ104DJ220
T
DVI RN14 90M-BW000400
R
90M-BW000400
R
RES. COMPO. 22X4/2012 HRJ104DJ220
T
DVI RN15 90M-BW000400
R
90M-BW000400
R
RES. COMPO. 22X4/2012 HRJ104DJ220
T
DVI RN16 90M-BW000400
R
90M-BW000400
R
RES. COMPO. 22X4/2012 HRJ104DJ220
T
DVI RN17 90M-BW000400
R
90M-BW000400
R
RES. COMPO. 22X4/2012 HRJ104DJ220
T
DVI RN18 90M-BW000400
R
90M-BW000400
R
RES. COMPO. 22X4/2012 HRJ104DJ220
T
DVI RN21 90M-BW000400
R
90M-BW000400
R
RES. COMPO. 22X4/2012 HRJ104DJ220
T
DVI RN22 90M-BW000400
R
90M-BW000400
R
RES. COMPO. 22X4/2012 HRJ104DJ220
T
DVI RN23 90M-BW000400
R
90M-BW000400
R
RES. COMPO. 22X4/2012 HRJ104DJ220
T
DVI RN24 90M-BW000400
R
90M-BW000400
R
RES. COMPO. 22X4/2012 HRJ104DJ220
T
DVI RN25 90M-BW000400
R
90M-BW000400
R
RES. COMPO. 22X4/2012 HRJ104DJ220
T
DVI RN26 90M-BW000400
R
90M-BW000400
R
RES. COMPO. 22X4/2012 HRJ104DJ220
T
DVI RN27 90M-BW000400
R
90M-BW000400
R
RES. COMPO. 22X4/2012 HRJ104DJ220
T
DVI RN28 90M-BW000400
R
90M-BW000400
R
RES. COMPO. 22X4/2012 HRJ104DJ220
T
DVI RY11 90M-LY000380
R
90M-LY000380
R
RELAY AXICOM HSL4C008ZE
DVI RY12 90M-LY000380
R
90M-LY000380
R
RELAY AXICOM HSL4C008ZE
DVI RY13 90M-LY000380
R
90M-LY000380
R
RELAY AXICOM HSL4C008ZE
DVI RY14 90M-LY000380
R
90M-LY000380
R
RELAY AXICOM HSL4C008ZE
FRONT PCB
(
CUP11759-1
)
FRONT BK11 ns
p
ns
p
BRACKET CMD1A468
FRONT BK12 ns
p
ns
p
BRACKET CMD1A468
FRONT BN14 ns
p
ns
p
CORD CWB1B907370EN
FRONT BN51 ns
p
ns
p
CORD CWB1B907050EN
FRONT BN52 ns
p
ns
p
CORD CWB1B907050EN
FRONT BN53 ns
p
ns
p
CORD CWB1B902550EN
FRONT C801 ns
p
00MOA10701020 ELECT CAP. 100UF 10V HCEA1AH101
T
FRONT C802 ns
p
00MOA10601620 ELECT CAP. 10UF 16V HCEA1CH100
T
FRONT C804 ns
p
ns
p
CER. CAP. 0.01UF 50V Z HCBS1H103ZFT
FRONT C805 ns
p
ns
p
CER. CAP. 100PF 50V
K
HCBS1H101KB
T
FRONT C806 ns
p
00MOA10703520 ELECT CAP. 100UF 35V HCEA1VH101
T
