Marantz SR7500/A1B - Page 75

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
98
SR7500 / PS7500
P.C.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
AMP PCB
(
CUP11760
)
AMP BN23 ns
p
ns
p
CORD CWZSR7500BN23
AMP BN24 ns
p
ns
p
CORD CWZSR7500BN24
AMP BN25 ns
p
ns
p
JACK CJP05GA19ZY
AMP BN68 ns
p
ns
p
CORD CWZSR7400BN68
AMP BN83 ns
p
ns
p
CORD CWZSR7400BN83
AMP C401 ns
p
00MOA10605020 ELECT CAP. 10UF 50V HCEA1HH100
T
AMP C402 ns
p
00MOA10605020 ELECT CAP. 10UF 50V HCEA1HH100
T
AMP C403 ns
p
ns
p
CER. CAP. 330PF 50V KB CCKT1H331KB
AMP C404 ns
p
ns
p
CER. CAP. 330PF 50V KB CCKT1H331KB
AMP C405 ns
p
ns
p
CER. CAP. 10PF 50V DC CCCT1H100D
C
AMP C406 ns
p
ns
p
CER. CAP. 10PF 50V DC CCCT1H100D
C
AMP C407 90M-OF100350R 90M-OF100350R FILM CAP 2200PF 50V J HCQI1H222JZT
AMP C408 90M-OF100350R 90M-OF100350R FILM CAP 2200PF 50V J HCQI1H222JZT
AMP C409 ns
p
00MOA22605020 ELECT CAP. 22UF 50V HCEA1HH220
T
AMP C410 ns
p
00MOA22605020 ELECT CAP. 22UF 50V HCEA1HH220
T
AMP C411 ns
p
00MOA10710020 ELECT CAP. 100UF 100V HCEA2AH101E
AMP C412 ns
p
00MOA10710020 ELECT CAP. 100UF 100V HCEA2AH101E
AMP C413 ns
p
00MOA10710020 ELECT CAP. 100UF 100V HCEA2AH101E
AMP C414 ns
p
00MOA10710020 ELECT CAP. 100UF 100V HCEA2AH101E
AMP C419 ns
p
00MOA10705020 ELECT CAP. 100UF 50V HCEA1HH101
T
AMP C420 ns
p
00MOA10705020 ELECT CAP. 100UF 50V HCEA1HH101
T
AMP C421 ns
p
00MOA10702520 ELECT CAP. 100UF 25V HCEA1EH101
T
AMP C422 ns
p
00MOA10702520 ELECT CAP. 100UF 25V HCEA1EH101
T
AMP C501 ns
p
00MOA10605020 ELECT CAP. 10UF 50V HCEA1HH100
T
AMP C502 ns
p
00MOA10605020 ELECT CAP. 10UF 50V HCEA1HH100
T
AMP C503 ns
p
ns
p
CER. CAP. 330PF 50V KB CCKT1H331KB
AMP C504 ns
p
ns
p
CER. CAP. 330PF 50V KB CCKT1H331KB
AMP C505 ns
p
ns
p
CER. CAP. 10PF 50V DC CCCT1H100D
C
AMP C506 ns
p
ns
p
CER. CAP. 10PF 50V DC CCCT1H100D
C
AMP C507 90M-OF100350R 90M-OF100350R FILM CAP 2200PF 50V J HCQI1H222JZT
AMP C508 90M-OF100350R 90M-OF100350R FILM CAP 2200PF 50V J HCQI1H222JZT
AMP C509 ns
p
00MOA22605020 ELECT CAP. 22UF 50V HCEA1HH220
T
AMP C510 ns
p
00MOA22605020 ELECT CAP. 22UF 50V HCEA1HH220
T
AMP C511 ns
p
00MOA10710020 ELECT CAP. 100UF 100V HCEA2AH101E
AMP C512 ns
p
00MOA10710020 ELECT CAP. 100UF 100V HCEA2AH101E
AMP C513 ns
p
00MOA10710020 ELECT CAP. 100UF 100V HCEA2AH101E
AMP C514 ns
p
00MOA10710020 ELECT CAP. 100UF 100V HCEA2AH101E
AMP C519 ns
p
00MOA10705020 ELECT CAP. 100UF 50V HCEA1HH101
T
AMP C520 ns
p
00MOA10705020 ELECT CAP. 100UF 50V HCEA1HH101
T
AMP C521 ns
p
00MOA10702520 ELECT CAP. 100UF 25V HCEA1EH101
T
AMP C522 ns
p
00MOA10702520 ELECT CAP. 100UF 25V HCEA1EH101
T
AMP C601 ns
p
00MOA10605020 ELECT CAP. 10UF 50V HCEA1HH100
T
AMP C602 ns
p
00MOA10605020 ELECT CAP. 10UF 50V HCEA1HH100
T
AMP C603 ns
p
ns
p
CER. CAP. 330PF 50V KB CCKT1H331KB
AMP C604 ns
p
ns
p
CER. CAP. 330PF 50V KB CCKT1H331KB
AMP C605 ns
p
ns
p
CER. CAP. 10PF 50V DC CCCT1H100D
C
AMP C606 ns
p
ns
p
CER. CAP. 10PF 50V DC CCCT1H100D
C
AMP C607 90M-OF100350R 90M-OF100350R FILM CAP 2200PF 50V J HCQI1H222JZT
AMP C608 90M-OF100350R 90M-OF100350R FILM CAP 2200PF 50V J HCQI1H222JZT
AMP C609 ns
p
00MOA22605020 ELECT CAP. 22UF 50V HCEA1HH220
T
AMP C610 ns
p
00MOA22605020 ELECT CAP. 22UF 50V HCEA1HH220
T
AMP C611 ns
p
00MOA10710020 ELECT CAP. 100UF 100V HCEA2AH101E
AMP C612 ns
p
00MOA10710020 ELECT CAP. 100UF 100V HCEA2AH101E
AMP C613 ns
p
00MOA10710020 ELECT CAP. 100UF 100V HCEA2AH101E
AMP C614 ns
p
00MOA10710020 ELECT CAP. 100UF 100V HCEA2AH101E
AMP C619 ns
p
00MOA10705020 ELECT CAP. 100UF 50V HCEA1HH101
T
AMP C620 ns
p
00MOA10705020 ELECT CAP. 100UF 50V HCEA1HH101
T
AMP C621 ns
p
00MOA10702520 ELECT CAP. 100UF 25V HCEA1EH101
T
AMP C622 ns
p
00MOA10702520 ELECT CAP. 100UF 25V HCEA1EH101
T
AMP C701 ns
p
00MOA10605020 ELECT CAP. 10UF 50V HCEA1HH100
T
AMP C703 ns
p
ns
p
CER. CAP. 330PF 50V KB CCKT1H331KB
AMP C706 ns
p
ns
p
CER. CAP. 10PF 50V DC CCCT1H100D
C
AMP C707 90M-OF100350R 90M-OF100350R FILM CAP 2200PF 50V J HCQI1H222JZT
AMP C709 ns
p
00MOA22605020 ELECT CAP. 22UF 50V HCEA1HH220
T
AMP C711 ns
p
00MOA10710020 ELECT CAP. 100UF 100V HCEA2AH101E
