MAR45W/MAR45BLS
Reverse the door swing
9.Stand up the refrigerator upright and put the door
on the bottom hinge. Make sure the bottom hinge
core is inserted in the door hole. Then move the
hinge hole ''plug'' of bottom door left side to right side.
5.Lay the refrigerator down on it's back onto in a
soft pad. Unscrew the bottom hinge and levelling
foot.
6.Unscrew and remove the bottom hinge pin, turn
the bracket over (insert) and re-install to the
same location.
7.Install the hinge and leg from the right side to
the left side with all original parts
8.Make sure the leveling leg from the left side
gets transfered to the right side as well and adjust
accordingly.
10. Install upper hinge to connect the top portion
of door to the unit. Clap in the hinge cover and
hold cover on top of the unit.
4
