Installation Instructions
The range must be level to operate safely and properly. There are four
leveling legs located at the corners on the bottom of the range. The
legs are easily adjusted by tuning them clockwise or counter clockwise.
Leveling the Range
Anti-tip Bracket
The range will not tip during normal use. However, the range can tip
if you apply too much force or weight to the open door without the
anti-tip bracket fastened down properly. To reduce the risk of
tipping the appliance, the appliance must be secured by properly
installing the Anti-tip bracket included with your Marathon range.
WARNING
• A child or adult can tip the range and be killed or seriously injured.
• Install the Anti-tip bracket to the range and structure per installation
instructions.
• Engage the range to the Anti-tip bracket installed on the structure.
• Re-engage the anti-tip bracket if the range is removed.
• Failure to follow these instructions can result in death or serious burns
to children and adults.
TIP OVER HAZARD
Installing the Anti-tip Bracket
To reduce the risk of the range tipping by abnormal usage or improper door loading, the range must be
secured by installing the anti-tip bracket included with this appliance.
• The Anti-tip bracket can be installed on either the right or left back leg. Place the anti-tip bracket
on the floor as shown below.
• Make the locations of 2 holes of ant-tip bracket on the floor.
• Use a 5/16” masonry drill bit and insert plastic anchor. (not supplied)
• Secure bracket to floor using screws
supplied.
• Slide the range back into place so that the rear foot is under
the anti-tip device
Rear foot of range
