RED WARNING LIGHT
KEYED ON-OFF SWITCH
AUTOCYCLE BUTTON
EMERGENCY STOP
BUTTON
MOTOR OVERLOAD
RESET BUTTON
(ON DOOR)
MANUAL UP BUTTON
MANUAL DOWN BUTTON
FEED GATE
TURNBUCKLE TO BALE
CHAMBER DOOR LATCH
BALE CHAMBER DOOR
CONTROL PANEL
PANEL BOX
NOTE: A fused disconnect is not provid-
ed on these models. The disconnect
must be provided, by the installer, per
the installation instructions in the
Installation section of this manual.
FRONT VIEW - VERTICAL BALER
1-4
