35
ref.no Descrpition Qty Spare part no.
19 Skimmer 1 P6661
20 O-ring 1 P6662
21 Strainer 1 P6663
22 Seal Ring 1 P6664
23 Strainer Cover 1 P6665
25 Hose (Ф32 mm 3 m) 2 P6022
26
Debris Screen 1 P61322
Debris Screen 1 P61318
SPECIFICATIONS (B)
Filter Diameter 270 mm
Eective Fiter Area 0,059 m
2
Max. Operating Pressure 0,042 MPa
Working sand lter pressure <0,025 MPa
Max. Water Temperature 35 °C
Sand Not included
Sand Size 20 silica sand, 0,45-0,85 mm
Sand Capacity Approximately 8,5 kg
Control valve overview (1)
WARNING: To prevent equipment damage and possible injury, always switch o the sand lter before changing the Control
Valve function. Changing valve positions while the pump is running can damage the Control Valve, which may cause personal
injury or property damage.
How to Use the Control Valve:
Press down on the Control Valve handle and rotate to desired function.
Control valve functions
The Control valve is used to select 6 dierent lter functions: Filter, Rinse, Circulate, Backwash, Closed and Drain.
Filter: This function is used to lter pool water and should be positioned here 99% of the time. Water is pumped
through the sand lter, where it is cleaned and returned to the pool.
Backwash: This function is used to clean the sand bed; water is pumped down through the Collector Hub, upwards
through the sand bed, and deposited out of Port D.
Rinse: This function for initial startup, cleaning, and sand bed leveling after Backwash; water is pumped downwards
through the sand bed, up through the Collector Hub and deposited out of the valve Port D.
NOTE:
Circulate: This function circulates pool water by passing the sand lter; use this function if the lter is broken to
collect debris in the Debris Screens.
Drain: This function drains water from the pool; another lter bypass setting, water is pumped and deposited out of
Port D, instead of returning it to the pool.
Closed: This function stops water owing between the sand lter and the pool.
NOTE:
• Be sure all provisions for wastewater disposal meet applicable local, state or national codes. Do not discharge water where it
will cause ooding or damage.
• When the Control Valve is set to the Backwash, Rinse, or Drain position, water will discharge from Port D on the Control Valve.
• Do not switch on or operate the sand lter with the Control Valve set to the Closed function or it will seriously damage the
sand lter.
• Do not set the Control Valve between two functions, or it will lead to leaking.
• To avoid water leakage, screw the Port D Cap onto the Control Valve Port D before operating the sand lter.
