Connecting to a power source:
It is recommended that you install a two-amp fuse on the positive power lead
of the PRO and PRO2 models before connecting to a power source. Connect
the two amp fused Red wire to +12 volts DC and the Black wire to -12
volts DC. For PRO3 models connect the RED wire to +12 volts DC and the
Black wire to -12 volts DC. PRO3 models come with a thirty (30) amp fuse
installed.
Connecting the servo:
Connect the servo cable to the control cable with the brown wire aligned to
the white mark on the control cable plug. After the servo is plugged in, move
on to set the servo arm.
Set the servo arm:
Power the unit ON and leave the unit in IDLE mode. By removing the
Phillips head screw that holds the servo arm on the servo body you can
remove the servo arm by pulling it off of the servo body. Adjust the servo
arm to be in the position as shown in the installation manual photos and
place the servo arm back on the servo body and return the Phillips head
screw to its original location to hold the servo arm in place.
Testing the controller:
You do not have to run your outboard motor to test the TrollMaster unit.
Test the controller by powering the unit on and press the IDLE button to put
the unit into RUN mode. By turning the control knob with a clockwise
rotation the servo should move the carburetor from IDLE to FULL
THROTTLE.
NOTE: Full throttle can be adjusted by changing the position of the servo
arm on the servo motor.
