Mark Audio AC SYSTEM 1 - Mono Mode Operation; Mono System Linking Diagram

13
MONO MODE (2 x AC System 1 or 2 x AC System 2) through LINK XLR;
Instrument
XLR Input
LEFT Aux Input
RIGHT Aux Input
DSP
AMPLIFIER
Satellite
AMPLIFIER
Sub
+
Link
LEFT + RIGHT LEFT + RIGHT
XLR cable
