Mark Audio AC SYSTEM 1 User Manual

15
TECHNICAL DETAILS
AC SYSTEM 1
ACOUSTICAL SPECIFICATIONS
Frequency response: 50 Hz- 20 kHz
Max SPL: 126dB
Horizontal coverage angle: 90°
Vertical coverage angle: 30°
Satellite: 4x4.0”, 16 Ohm
Sub: 2 x 10”, 4 Ohm
INPUT/OUTPUT SECTION
Input connectors: Jack-XLR male-AUX
Output connectors: XLR female
Input sensitivity: -1.1 dBu (@1 kHz)
DSP PROCESSOR SECTION
Crossover frequencies: 180 Hz
Protections: Thermal, rms
Limiter: Soft limiter
Controls: Volume, EQ
AMPLIFIER
Total Power: 2000 W PEAK (@ 4 Ohm)
High frequencies: 1000 W PEAK (@ 4 Ohm)
Low frequencies: 1000 W PEAK (@ 4 Ohm)
Total Power: 1000 W RMS (@ 4 Ohm)
High frequencies: 500 W RMS (@ 4 Ohm)
Low frequencies: 500 W RMS (@ 4 Ohm)
Cooling: Convection
Power Connection: VDE connector
CABINET
Cabinet Material: multiply poplar
Handles: 2 side
Pole Mount/Cap: Yes
Colour: Black
PHYSICAL
Weight Satellite: 3Kg
Weight SUB: 23Kg
Fullrange Speaker Pole mount
Height: 1.25m (min) / 1.7m (max) with horizontal sub;
1.43m (min) / 1.88m (max) with vertical sub.

Mark Audio AC SYSTEM 1 Specifications

General

Brand	Mark Audio
Model	AC SYSTEM 1
Category	Stereo System
Language	English
