Remote Control of the Nº360S
The Nº360S includes both an infrared receiver and an infrared trans-
mitter. With this capability, it can “teach” a learning remote control any
commands that might be needed for remote operation. These include
input selection, mode, polarity, etc.
Specifically, the Nº360S can send all of the necessary IR commands
from its display window, enabling you to teach a learning remote any or
all of its pre-programmed commands, as well as some optional special
commands that are available to solve specific installation-related prob-
lems.
The Nº360S has two special modes of operation into which is may be
placed in order to facilitate the “teaching” of remote control commands
to a learning remote control. The first allows you to easily teach the
commands for which there are corresponding front panel buttons. The
second allows you to teach “special” commands to the remote control
for which there are no corresponding front panel buttons.
Teaching Nº360S Front
Panel Commands
1 Press the “teach IR” button to enter the teaching mode
The LED above the teach ir button will illuminate and the display
will read < IR MODE to indicate that the Nº360S is ready to teach a
learning remote control the infrared commands that correspond
to the its front panel buttons. (Pressing the teach ir button a sec-
ond time will return the Nº360S to normal operation if you
change your mind.)
2 Press any front panel button to cause the Nº360S to send
the corresponding IR command
Line up the IR window of your remote control with the left side of
the Nº360S display (being pointed at by the < IR MODE in the dis-
play), at a distance of approximately 1"-3". Select the to-be-
learned button on the remote, then press the corresponding but-
ton on the Nº360S to fire the appropriate IR code. The display will
change to read ^ IR MODE to indicate that the IR code is being emit-
ted, then will revert to < IR MODE when it is ready to teach the next
command. (Tip: most learning remotes need to be held fairly still
while they learn new IR commands; movement can garble the re-
ceived IR.)
If you are uncertain as to how to prepare your remote control for
learning new commands, refer to the instructions provided with
the remote control.
