Mark 8 - Heater Inclination; Minimum Safety Clearances

GAS INFRARED HEATERS
3
2. SAFETY RECOMMENDATIONS :
THESE HEATERS MUST BE INSTALLED AND MAINTAINED BY A QUALIFIED INSTALLER
IN ACCORDANCE WITH THE CURRENTLY APPLICABLE SAFETY REGULATIONS AND
WITH THE INSTALLER INSTRUCTIONS.
TO AVOID ABNORMAL MECHANICAL CONSTRAINTS ON THE RADIANT, IT IS
RECOMMENDED THAT IT BE CONNECTED TO THE GAS MAINS BY A FLEXIBLE TUBE.
TO BE INSTALLED IN WELL-VENTILATED PREMISES. NOT FOR DOMESTIC USE.
2.1 HEATER INCLINATION
2.2 MINIMUM SAFETY CLEARANCES (INFLAMMABLE MATERIALS: 
max
=70°C)
(*) For an minimum inclination of 20°
GAS SUPPLY
5 to 35°
5 to 35°
WRONG INCLINATION
CORRECT INCLINATION
1m
min.
2m
min.
HEATED
AREA
HEATED
AREA
1m
min.
0,6m
min.(*)
