Mark 8 - Product Specification

GAS INFRARED HEATERS
2
1. PRODUCT SPECIFICATION :
Refer to the heater rating plate on the gas supply cover panel (see example
below).
MODEL
MARK
6
MARK
8
MARK
10
MARK
12
MARK
16
MARK
20
MARK
20-2
MARK
24
MARK
24-2
MARK
32
MARK
32-2
MARK
64-2
Certificate Number
1312
AP 230
1312
AP 230
1312
AP 231
1312
AP 231
1312
AP 232
1312
AP 232
1312
AP 233
1312
AP 232
1312
AP 233
1312
AP 232
1312
AP 233
1312
AP 249
Class NOx 4
Weight
(kg)
2,5 2,9 3,1 3,4 4,1 5,0 5,0 5,5 5,5 6,7 6,7 12,2
Net calorific value
Qn (kW) Hi
2,50
3,30
3,80
5,10
6,75
7,60
7,60
10,20
10,20
13,50
13,50
27,00
G20 consumption
(Natural gas) (m
3
/h)
0.265
0.350
0.400
0.540
0.715
0.805
0.805
1.080
1.080
1.430
1.430
2.860
G31
consumption
(Propane) (kg/h)
0.195
0.260
0.300
0.400
0.530
0.595
0.595
0.800
0.800
1.055
1.055
2.110
Combustion air G20
2.60
3.40
3.90
5.30
7.00
7.90
7.90
10.50
10.50
13.90
13.90
27.80
(m
3
/h) G31
2.30
3.10
3.60
4.80
6.30
7.10
7.10
9.60
9.60
12.60
12.60
25.20
Required air
renewal rate (m
3
/h)
25 33 38 51 67.5
76 76 102 102 135 135 270
